Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204560326 | FUEL TANK ASS'Y | ||
| 2 | 204560181 | FUEL TANK STRAP | 2 |
| 2 | 204560185 | PROTECTOR PAD | 2 |
| 4 | 207183060 | Hex. Screw M8 X 30 | 4 |
| 4 | 234181601 | Lock Washer 8 mm, Stainless | 4 |
| 4 | 234082600 | Flat Washer 8 mm, Stainless | 4 |
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 2 | 275500252 | TANK BRACKET | 2 |
| 207183560 | HEX. SCREW M8 X 35 | ||
| 2 | 232581600 | Hex. Elastic Nut M8 | 2 |
| 1 | 204560265 | COUPLER | 1 |
| 204560263 | Pipe Cap | ||
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 275500205 | HOSE 16 MM | ||
| 2 | 293650069 | NORMA CLAMP | 2 |
| 1 | 275500206 | VENT BOAT | 1 |
| 1 | 219704357 | Was 275500549 Hose 1/4" | 1 |
| 2 | 293650121 | NORMA CLAMP | 2 |
| 275500247 | Filler Neck | ||
| 1 | 293250029 | Gasket | 1 |
| 1 | 211100012 | Filler Neck Nut, Fuel | 1 |
| 275500015 | Oil Cap Chain | ||
| 293150057 | Rivet 1/8” | ||
| 1 | 234032600 | Flat Washer M3, Stainless | 1 |
| 1 | 241140060 | Screw K40 X 10 | 1 |
| 1 | 275500430 | Fuel Tank Cap, Black Includes 26 to 27 | 1 |
| 1 | 293000034 | Black, Snap Cap | 1 |
| 293250017 | Gasket | ||
| 219700374 | NECK FILLER HOSE | ||
| 4 | 293650081 | Norma Clamp | 4 |
| 204560289 | FUEL MODULE ASS'Y Includes 31 to 35 | ||
| 1 | 204560290 | SUPPLY HOSE ASS'Y Includes 32 to 33 | 1 |
| 2 | 293650030 | Oetiker Clamp | 2 |
| 204560291 | Return Hose Ass'y | ||
| 4 | 293650030 | Oetiker Clamp | 4 |
| 204560266 | Sensor Lever | ||
| 9 | 232551200 | Elastic Stop Nut 5 mm | 9 |
| 9 | 234052400 | Flat Washer 5 mm, Stainless | 9 |
| 1 | 293250088 | Gasket | 1 |
| 1 | 275500616 | C-Ring | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 2 | 293370002 | Circlip 5 mm | 2 |
| 204560177 | Hose 5/16”, Meter | ||
| 2 | 293650070 | NORMA CLAMP | 2 |
| 2 | 275500633 | Air Injector Includes 45 to 48 | 2 |
| 293300084 | O-Ring | ||
| 270600030 | INJECTOR RING | ||
| 293300076 | O-Ring | ||
| 293300083 | O-Ring | ||
| 2 | 234181601 | Lock Washer 8 mm, Stainless | 2 |
| 2 | 234081600 | Stainless, Flat Washer 8 mm | 2 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 207087060 | HEX. SCREW M8 X 70 | ||
| 204560300 | FUEL DISTRIBUTOR ASS'Y Includes 54 to 77 | ||
| 3 | 205061260 | Socket Head Screw M6 X 12 | 3 |
| 205051260 | SOCKET HEAD SCREW M5 X 12 | ||
| XXXX | Not Available As Spare Part - Cover | ||
| XXXX | Not Available As Spare Part - Spacer | ||
| 293300069 | O-RING | ||
| 275500598 | O-Ring | ||
| XXXX | Not Available As Spare Part - O-Ring | ||
| 275500464 | FUEL REGULATOR | ||
| 275500463 | Air Regulator | ||
| 204560304 | Fuel Plug | ||
| XXXX | Not Available As Spare Part - Air Passage Plug | ||
| 2 | 275500460 | Fuel Injector | 2 |
| 204560307 | Fuel Supply Hose Ass'y Includes 67 to 68 | ||
| 204560313 | Fuel Return Hose Ass'y Includes 69 to 70 | ||
| XXXX | Not Available As Spare Part - Air Intake Hose Ass'y Includes 71 to 72 | ||
| XXXX | Not Available As Spare Part - Air Return Adaptor | ||
| XXXX | Not Available As Spare Part - Retainer Plate | ||
| 291001399 | Clamp Tie | ||
| 2 | 293650139 | CLAMP | 2 |
| 2 | 234051500 | Flat Washer 5 mm | 2 |
| 2 | 232551600 | Hex. Elastic Nut M5 | 2 |
| 1 | 204560191 | NEOPRENE PAD | 1 |
| 270000569 | Noise Reducer | ||
| 1 | 293830027 | SEAL WASHER | 1 |
| 1 | 219704458 | Was 293800041 Loctite Primer 7649 | 1 |
| 1 | 211100020 | SPECIAL NUT M27 | 1 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 1 | 276000084 | HOSE-8MM. | 1 |
| 2 | 293650170 | Tridon Gear Clamp | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 270000469 | HOSE 3 MM | 1 |
| 1 | 293650105 | Clamp | 1 |
| 5 | 293750001 | Tie Wrap 94 mm | 5 |
| 1 | 219704352 | Was 420660574 Pressure Hose 280 mm | 1 |
| 1 | 275500444 | STRAIGHT FITTING | 1 |
