Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Engine 947 Di Includes 1 to 7 | ||
| 707000031 | Adaptor Ass'y Includes 2 to 5 | ||
| 1 | 270000137 | Female Connector, 6 Circuits | 1 |
| 293300033 | Gasket | ||
| 293200055` | Gasket | ||
| 6 | 278000631 | Male Terminal | 6 |
| 1 | 278000735 | Female Lock, 6 Circuits | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 270000421 | Rubber Mount, Black | ||
| 207181660 | Hex. Screw M8 X 16 | ||
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 3 | 207184060 | Hex. Screw M8 X 40 | 3 |
| 1 | 207184560 | HEX. SCREW M8 X 45 | 1 |
| 4 | 234081600 | Stainless, Flat Washer 8 mm | 4 |
| 270000122 | Shim 0.3 mm | ||
| 270000123 | SHIM 1.3 MM | ||
| 270000422 | Rubber Mount, Black | ||
| 207182060 | HEX. SCREW M8 X 20 | ||
| 1 | 234082600 | Flat Washer 8 mm, Stainless | 1 |
| 3 | 270000024 | SHIM 0.4 MM | 3 |
| 1 | 270000024 | SHIM 0.4 MM | 1 |
| 2 | 207184060 | Hex. Screw M8 X 40 | 2 |
| 2 | 234081600 | Stainless, Flat Washer 8 mm | 2 |
| 1 | 204250048 | Shim 0.3 mm | 1 |
| 1 | 204250049 | SHIM 1.3 MM | 1 |
| 3 | 293730018 | Mount Dart | 3 |
| 3 | 414115200 | Tie-Rap 180 mm | 3 |
| 1 | 219704353 | Protection Trim 1000mm Long | 1 |
| 1 | 207302060 | Hex. Screw M10 X 20, Scotch Grip | 1 |
| 1 | 207162560 | Hex. Screw M6 X 25 | 1 |
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 1 | 234161601 | Lock Washer Helical M6 | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 1 | 234001600 | Flat Washer 10 mm, Stainless | 1 |
| 1 | 278001512 | INSULATOR | 1 |
| 1 | 293710066 | MALE CONNECTOR | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 1 | 278001937 | Starter Ass'y, Black | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 1 | 273000227 | AIR SILENCER SUPPORT | 1 |
| 2 | 205063560 | Socket Head Screw M6 X 35 | 2 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 1 | 278001662 | GROUND PLATE | 1 |
| 293700016 | Elbow Fitting | ||
| 293710082 | STRAIGHT FITTING | ||
| 205003060 | Socket Screw M10 X 30 | ||
| 232001600 | HEX. NUT M10 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 270000515 | Engine Support, Black | ||
| 5 | 205582560 | Socket Head Screw M8 X 25, Scotch Grip | 5 |
| 2 | 270000453 | BUSHING | 2 |
| 5 | 234081600 | Stainless, Flat Washer 8 mm | 5 |
| 1 | 270600019 | VALVE ADAPTOR | 1 |
| 243041660 | HEX. PLASTITE SCREW M5.28 X 16 | ||
| 1 | 211200035 | Flat Washer | 1 |
| 2 | 278001650 | Spark Plug NGK ZFR4F-11 | 2 |
