Демо
PowerCatalog
Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 278001760 | Electric Box Base | ||
| 1 | 278001433 | ELECTRIC BOX COVER | 1 |
| 278001173 | GASKET | ||
| 1 | 278001802 | Relay Starter | 1 |
| 2 | 210261040 | Hex. Flange Screw M6 X 10 | 2 |
| 2 | 232561600 | Hex. Elastic Stop Nut M6 | 2 |
| 278001451 | IGNITION COIL | ||
| 2 | 278001470 | PROTECTOR CAP | 2 |
| 4 | 209463840 | SCREW-TAPP.HEX.ISO.1479F | 4 |
| 1 | 207361660 | Hex. Screw M6 X 16, Scotch Grip | 1 |
| 250100029 | U Type Nut M6 | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 204470286 | POSITIVE CABLE ASS'Y Includes 13 to 16 | 1 |
| 278000100 | Electric Wire Cap | ||
| 278000098 | GROMMET | ||
| 1 | 204470269 | RED BOOT | 1 |
| 278001458 | Box Harness Includes 17 to 25 | ||
| 1 | 270000137 | Female Connector, 6 Circuits | 1 |
| 1 | 278000735 | Female Lock, 6 Circuits | 1 |
| 6 | 278000631 | Male Terminal | 6 |
| 2 | 278001467 | MALE TERMINAL HOUSING, 3 CIRCUITS | 2 |
| 6 | 278001468 | FEMALE TERMINAL | 6 |
| 1 | 278001113 | Male Connector, 2 Circuits | 1 |
| 2 | 278001114 | Female Terminal | 2 |
| 1 | 278001392 | Open Barrel Terminal | 1 |
| 278001494 | ELECTRIC BOX HARNESS ASS'Y Includes 26 to 30 | ||
| 1 | 278001477 | FEMALE HOUSING, 4 CIRCUITS | 1 |
| 3 | 515175261 | MALE TERMINAL | 3 |
| 1 | 278001478 | MALE WEDGE, 4 CIRCUITS | 1 |
| 2 | 293000052 | Sealing Cap | 2 |
| 1 | 278001454 | COIL CABLE, 735 MM Includes 31 to 33 | 1 |
| 278000682 | Grommet | ||
| 1 | 278001466 | COIL CABLE, 635MM Includes 34 to 36 | 1 |
| 278001453 | Fuse Harness, 30 Amperes Includes 37 to 41 | ||
| 1 | 410917200 | Fuse, 30 Amperes | 1 |
| 515175259 | Deutsch Joint Housing | ||
| 1 | 515175260 | FEMALE TERMINAL | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 293200055` | Gasket | ||
| 1 | 278001437 | STARTER RED CABLE Includes 44 to 47 | 1 |
| 278000020 | PROTECTION CAP | ||
| 1 | 278001443 | Fuse, 25 Amperes | 1 |
| 3 | 234062600 | Flat Washer M6, Stainless | 3 |
| 3 | 232561600 | Hex. Elastic Stop Nut M6 | 3 |
| 278001426 | Electric Box Support Ass'y | ||
| 3 | 293150037 | Avdel Rivet 3/16" | 3 |
| 2 | 278001650 | Spark Plug NGK ZFR4F-11 | 2 |
| 278000346 | 4 Wire Support | ||
| 1 | 278000559 | COLLAR SUPPORT | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 204470199 | RH GROUND CABLE | 1 |
| 1 | 204471008 | BATTERY SUPPORT | 1 |
| 1 | 204470909 | Top Battery Support | 1 |
| 8 | 204100069 | FLAT WASHER | 8 |
| 8 | 205062560 | Socket Head Screw M6 X 25 | 8 |
| 8 | 211200029 | FLAT WASHER, PLASTIC | 8 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 204470349 | POSITIVE BATTERY POLE | ||
| 1 | 211100063 | HEX. NUT 3/8-16 | 1 |
| 1 | 204470348 | NEGATIVE BATTERY POLE | 1 |
| 1 | 204470813 | SWITCH ADAPTOR | 1 |
| 204470814 | BATTERY SWITCH | ||
| 204470259 | SWITCH SUPPORT | ||
| 205455060 | SOCKET HEAD SCREW M5 X 50 | ||
| 8 | 234051600 | Flat Washer M5, Stainless | 8 |
| 4 | 204470330 | NYLON SPACER | 4 |
| 4 | 232051600 | Hex. Nut M5 | 4 |
| 4 | 234151601 | Helical Lock Washer M5 | 4 |
| 209642560 | PHILLIPS SCREW M4.2 X 25 | ||
| 4 | 234041600 | Flat Washer 4 mm, Stainless | 4 |
| 204470250 | POSITIVE SWITCH CABLE | ||
| 1 | 278000343 | Fuse, 15 Amperes | 1 |
| 1 | 204100052 | HEX. NUT 5/16?-18 | 1 |
