Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705501415 | Rear Propeller Shaft Ass'y Incldues 1 to 5 | 1 |
| 1 | 705501372 | Differential Fixed Joint | 1 |
| 703500255 | Rubber Boot Kit | ||
| 2 | 703000022 | Unit Pack Kit | 2 |
| 1 | 705501123 | Protector | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 705501419 | Rear Differential Ass'y Includes 12 to 31 | ||
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705500987 | Nut | 1 |
| 1 | 705500260 | Ball Bearing | 1 |
| 705500075 | Pinion Gear Shim .022" | ||
| 1 | 703500049 | Pinion Shim Kit | 1 |
| 705501163 | Pinion Gear Shim 2.12mm | ||
| 1 | 703500548 | Differential Shim Kit | 1 |
| 1 | 705501570 | 10 Teeth Pinion | 1 |
| 1 | 705501408 | Needle Bearing | 1 |
| 1 | 705500749 | Ball Bearing | 1 |
| 1 | 705501389 | Ball Bearing | 1 |
| 1 | 705501403 | 36 Teeth Pinion | 1 |
| 4 | 705500892 | SCREW | 4 |
| 1 | 705501507 | REAR DIFFERENTIAL COVER | 1 |
| 1 | 705500265 | Seal | 1 |
| 1 | 705501395 | PINION REAR COVER | 1 |
| 1 | 705500893 | VENT VALVE | 1 |
| 1 | 705500894 | Drain Plug | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 2 | 705501196 | Oil Seal | 2 |
| 1 | 250400041 | Screw Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 2 | 705501264 | Wheel Hub | 2 |
| 8 | 250300048 | Wheel Stud Tightening Torque: See Bulletin ATV 2020-4 | 8 |
| 250000378 | HEX FLANGED SCREW M12 X 16, SCOTCH GRIP | ||
| 1 | 250200102 | Flat Washer M12 | 1 |
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 2 | 705500685 | Rear Tire STD | 2 |
| 2 | 705500940 | Rear Tire XT | 2 |
| 2 | 705500606 | Rear Tire XT Europe | 2 |
| 2 | 705501460 | Silver Rear Rim STD | 2 |
| 2 | 705501458 | Black Rear Rim XT | 2 |
| 2 | 705501493 | Black, Rear Rim XT CAMO | 2 |
| 2 | 705400193 | Rim Valve With Cap | 2 |
| 1 | 219704465 | 1/2 Oz Weight | 1 |
| 2 | 293000110 | Valve Cap | 2 |
| 8 | 250100042 | Steel Wheel Nut STD | 8 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 XT | 8 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400036 | Cotter Pin | 2 |
| 1 | 705500979 | LH CV Joint Ass'y Includes 48 to 51 | 1 |
| 705500980 | CV JOINT | ||
| 2 | 705500870 | Boot Kit | 2 |
| 1 | 705500845 | CIRCLIP | 1 |
| 1 | 705500983 | RH CV Joint Ass'y Includes 52 to 55 | 1 |
| 2 | 705501124 | Wear Ring | 2 |
| 5 | 250000508 | Hex. Flange Screw M10 x 135 | 5 |
| 5 | 233201436 | Hex. Flange Elastic Nut M10 | 5 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 705400928 | Wheel Cap | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 250200049 | Spring Washer | 2 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
