Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705001313 | FRONT FASCIA, RED Viper Red | 1 |
| 1 | 705001991 | FRONT FASCIA, YELLOW Yellow | 1 |
| 1 | 705001992 | FRONT FASCIA, GREEN Laurentian Green | 1 |
| 6 | 293150089 | Tuflok Plastic Rivet | 6 |
| 2 | 506151252 | Washer | 2 |
| 1 | 705001679 | LOWER GRILL | 1 |
| 1 | 705001901 | UPPER GRILL | 1 |
| 8 | 517302674 | Clip | 8 |
| 1 | 703500668 | DASH-BOARD, RED Includes 7 to 10, Viper Red | 1 |
| 703500674 | Dash-board, Green Includes 7 to 10, Laurentian Green | ||
| 703500670 | DASH-BOARD, YELLOW Includes 7 to 10, Yellow | ||
| 703500671 | Dash-board, Red Includes 7 to 10, Viper Red (Europe) | ||
| 703500672 | DASH-BOARD, GREEN Includes 7 to 10, Laurentian Green (Europe) | ||
| 703500673 | DASH-BOARD, YELLOW Includes 7 to 10, Yellow (Europe) | ||
| 1 | 704900434 | Caution Decal, Lever And 4wd Switch | 1 |
| 1 | 704900475 | Caution Decal, Shifting Lever | 1 |
| 704900476 | CAUTION DECAL, 4WD SWITCH | ||
| 2 | 210261680 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 391302000 | Flat Washer | 2 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 705001780 | Rear Luggage Rack | 1 |
| 1 | 705001769 | Front Luggage Rack | 1 |
| 2 | 250000239 | Torx Truss Screw M6 X 50 | 2 |
| 8 | 207665044 | Hex. Flange Screw M6 X 50 | 8 |
| 10 | 224061201 | Flat Washer | 10 |
| 10 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 10 |
| 2 | 705002042 | RUBBER CAP | 2 |
| 2 | 365901100 | HEX. SCREW 12 X 3/4 | 2 |
| 705001944 | LH Handle | ||
| 705001945 | RH Handle | ||
| 250000197 | Torx Truss Screw M8 X 30 | ||
| 2 | 250000198 | TORX TRUSS SCREW M8 X 16 | 2 |
| 4 | 705002153 | Bushing | 4 |
| 1 | 414859400 | CAP | 1 |
| 1 | 705001459 | Rear Support | 1 |
| 2 | 705001180 | U Reinforcement | 2 |
| 2 | 207685044 | Hex. Flange Screw M8 X 50 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 234082410 | Flat Washer 8 mm | 2 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 1 | 705001455 | Front Support | 1 |
| 1 | 705000692 | LH ANCHOR PLATE | 1 |
| 4 | 390402300 | Pop Rivet 3/16" | 4 |
| 1 | 705000693 | RH Anchor Plate | 1 |
| 4 | 207684544 | Hex. Flange Screw M8 X 45 | 4 |
| 4 | 234082410 | Flat Washer 8 mm | 4 |
| 4 | 232581414 | Hex. Elastic Stop Nut M8 | 4 |
| 4 | 207582084 | Hex. Flange Screw M8 X 20, Scotch Grip STD (Europe) | 4 |
| 705001075 | ATTACHMENT PLATE STD (Europe) |
