Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 732610072 | Push Nut | 2 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 207603044 | Hex. Flange Screw M10 X 30 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705001827 | Front Bumper | 1 |
| 1 | 705001981 | RH Footboard Ass'y | 1 |
| 1 | 705001940 | LH Footboard | 1 |
| 1 | 705001518 | Engine Cover | 1 |
| 5 | 210261280 | Hex. Flange Screw M6 X 12 | 5 |
| 2 | 705000657 | Engine Cover Support | 2 |
| 4 | 705000428 | Footrest | 4 |
| 12 | 207662584 | Hex. Flange Screw M6 X 25 | 12 |
| 4 | 234161471 | Lock Washer M6, Black | 4 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 12 |
| 1 | 703500531 | Front Fender, Red Includes 16 to 22, Viper Red | 1 |
| 1 | 703500528 | Front Fender, Green Includes 16 to 22, Laurentian Green | 1 |
| 1 | 703500526 | Front Fender, Yellow Includes 16 to 22, Yellow | 1 |
| 1 | 704901089 | Warning Decal, Load English Version | 1 |
| 704900453 | Warning Decal, Front Load English Version, Yellow | ||
| 1 | 704900642 | Warning Decal, Under 16 Years Old English Version | 1 |
| 704900904 | Warning Decal, Death And Injuries English Version | ||
| 704901090 | Warning Decal, Load French Version | ||
| 1 | 704900436 | WARNING DECAL, UNDER 16 YEARS OLD French Version | 1 |
| XXXX | Not Available As Spare Part - Warning Label, Death And Injuries French Version | ||
| 1 | 293000103 | PLASTIC CAP STD | 1 |
| 12 | 250000261 | Torx Screw M6 X 16 | 12 |
| 2 | 705001999 | FRONT CAP | 2 |
| 1 | 705001900 | RH CAP | 1 |
| 703500559 | REAR FENDER KIT, RED Includes 28 to 36, Viper Red | ||
| 703500560 | REAR FENDER KIT, YELLOW Includes 28 to 36 Yellow | ||
| 1 | 703500561 | REAR FENDER KIT, GREEN Includes 28 to 36, Laurentian Green | 1 |
| 1 | 703500565 | Rear Fender Kit, Red Includes 28 to 38, Viper Red, Europe | 1 |
| 703500566 | REAR FENDER, YELLOW Includes 28 to 38, Yellow, Europe | ||
| 703500567 | Rear Fender, Green Includes 28 to 38, Laurentian Green, Europe | ||
| 704901113 | WARNING DECAL, UNDER 12 YEARS OLD English Version | ||
| 1 | 704901120 | Warning Decal Tire Pressure English Version | 1 |
| 704901122 | WARNING DECAL, UNDER 12 YEARS OLD French Version | ||
| 704901121 | WARNING DECAL TIRE PRESSURE French Version | ||
| 1 | 705000809 | Reflective Sheet | 1 |
| 1 | 705002043 | REFLECTIVE SHEET | 1 |
| 1 | 704901112 | Warning Decal, Road Use English Version | 1 |
| 704901158 | Warning Decal, Public Roads Use French Version | ||
| 705002190 | Reflective Sheet | ||
| 705002188 | Reflective Sheet | ||
| 1 | 219704365 | Was 293200017 Neoprene Seal | 1 |
