Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 710000053 | HEADLAMP | ||
| 1 | 410504401 | Halogen Bulb | 1 |
| 732600009 | PAN HEAD FORMING SCREW M6 X 18 | ||
| 2 | 732600030 | Screw | 2 |
| 3 | 232561414 | Elastic Stop Nut M6 | 3 |
| 710000102 | Tail Light Housing | ||
| 710000055 | TAIL LIGHT LENS, RED | ||
| 1 | 410504100 | Bulb | 1 |
| 1 | 710000129 | GASKET | 1 |
| 2 | 517245900 | Bushing | 2 |
| 4 | 414036300 | Grommet | 4 |
| 4 | 233251414 | Hex. Flange Elastic Nut M5 | 4 |
| 2 | 224060201 | Flat Washer | 2 |
| 1 | 710000101 | BLANK KEY (B TYPE) | 1 |
| 710000137 | BLANK KEY (A TYPE) | ||
| 8 | 293830083 | PROTECTOR | 8 |
| 2 | 250200002 | RUBBER WASHER | 2 |
| 2 | 207683544 | Hex. Flange Screw M8 X 35 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 3 | 517124300 | Washer | 3 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 414806900 | Nut | ||
| 1 | 515175321 | FEMALE TERMINAL | 1 |
| 409202700 | FEMALE TERMINAL HOUSING, 3 CIRCUITS | ||
| 409204300 | Female Housing | ||
| 1 | 561503100 | FEMALE TERMINAL | 1 |
| 2 | 278001326 | Fuse Holder Cap | 2 |
| 2 | 278001325 | Fuse Holder | 2 |
| 2 | 278000805 | Cushion | 2 |
| 1 | 278000343 | Fuse, 15 Amperes | 1 |
| 1 | 278001443 | Fuse, 25 Amperes | 1 |
| 1 | 278001554 | Rectifier Ass’Y Includes 30 - 34. | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 5 | 409007300 | Female Terminal | 5 |
| 5 | 278000218 | Wire Seal | 5 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 1 | 409004300 | Male Terminal | 1 |
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 1 | 710000048 | Wire Seal | 1 |
| 1 | 409010700 | Female Terminal | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278000992 | Open Barrel | 1 |
| 1 | 409012600 | Terminal Ring | 1 |
| 1 | 278001007 | Insulated Sheath | 1 |
| 1 | 278001009 | Female Terminal | 1 |
| 710000071 | Harness Ass'y(Not Shown) | ||
| 250200000 | Serrated Lock Washer M6 | ||
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 7 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 7 |
| 710000283 | BATTERY_12 VOLT 13AH | ||
| 710000087 | RUBBER STRAP, BLACK | ||
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 710000086 | Ground Cable | ||
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 710000066 | Positive Cable | ||
| 2 | 207663544 | Hex. Flange Screw M6 X 35 | 2 |
| 2 | 224060251 | Washer | 2 |
| 4 | 250200002 | RUBBER WASHER | 4 |
| 710000069 | POSITIVE CABLE | ||
| 1 | 710000111 | Starter Relay | 1 |
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 710000060 | DASHBOARD | ||
| 1 | 710000075 | IGNITION SWITCH | 1 |
| 710000062 | Pilot Lamp, Red | ||
| 710000063 | Pilot Lamp | ||
| 1 | 208656091 | PAN HEAD PHILLIPS SCREW M5 X 60 | 1 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 2 | 208657041 | PHILLIPS SCREW M5 X 70 | 2 |
