Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 5 | 233201436 | Hex. Flange Elastic Nut M10 | 5 |
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 1 | 250000615 | Screw-Hex.Flange M10 X 16 | 1 |
| 5 | 250000508 | Hex. Flange Screw M10 x 135 | 5 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 | 8 |
| 2 | 250200049 | Spring Washer | 2 |
| 1 | 250200014 | Flat Washer M10 | 1 |
| 8 | 250300048 | Wheel Stud Tightening Torque: See Bulletin ATV 2020-4 | 8 |
| 2 | 250400036 | Cotter Pin | 2 |
| 2 | 293000110 | Valve Cap | 2 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 2 | 705400193 | Rim Valve With Cap | 2 |
| 2 | 705401318 | Wheel Cap | 2 |
| 1 | 705500504 | Fill Level Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 705400962 | TIRE_30X9R14 | ||
| 1 | 705500894 | Drain Plug | 1 |
| 1 | 705501123 | Protector | 1 |
| 2 | 705501124 | Wear Ring | 2 |
| 1 | 715900118 | Rubber Boot | 1 |
| 2 | 715900184 | Grease Fitting | 2 |
| 1 | 715900271 | Joint | 1 |
| 1 | 715900106 | Spline Yoke | 1 |
| 1 | 703500858 | Rear Propeller Shaft Ass'y | 1 |
| 1 | 705501847 | Performance CV Axle - Rear Left | 1 |
| 1 | 705501848 | Performance CV Axle - Rear Right | 1 |
| 1 | 705502179 | Rear Cover | 1 |
| 1 | 705502180 | Rear Pinion Cover | 1 |
| 1 | 703500848 | Kit Gear 10/36 Teeth | 1 |
| XXXX | Not Available As Spare Part - Ball Bearing | ||
| 1 | 705501549 | Nut | 1 |
| 1 | 705501550 | Nut | 1 |
| 1 | 705501554 | O-Ring | 1 |
| 2 | 705501556 | Oil Seal | 2 |
| 1 | 705501557 | Oil Seal | 1 |
| 4 | 705502063 | Screw | 4 |
| 1 | 705501711 | O-Ring | 1 |
| 2 | 705501716 | Wheel Hub Ass'y 703501191 won't fit this unit - please order 705501716 or 705501900 | 2 |
| 1 | 705502178 | Rear Differential Ass'y | 1 |
| 705501761 | INNER RING | ||
| 1 | 703500836 | Needle Bearing Ass'y | 1 |
| 1 | 705401552 | Matte Black Rim | 1 |
| 715900270 | Universal Joint | ||
| 1 | 509000045 | Oetiker Gear Clamp 36.1MM | 1 |
| 1 | 715900187 | COVER | 1 |
| 1 | 715900296 | Fixe Yoke | 1 |
| 705501776 | JOINT_CV EXT | ||
| 2 | 705501864 | Boot Kit | 2 |
| 2 | 715900242 | Oetiker Clamp, 27.3 mm | 2 |
| 2 | 715900241 | Oetiker Clamp, 82.1 mm | 2 |
| 2 | 705501842 | Joint Protector | 2 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| XXXX | Not Available As Spare Part - Differential Shim | ||
| 1 | 705501584 | Breather Tube | 1 |
| 1 | 705501724 | Plug Drain | 1 |
| 1 | 703500835 | Differential Shim Kit | 1 |
| 705501780 | PLUNGING JOINT | ||
| 2 | 705501781 | Circlip | 2 |
