Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 1 | 12361-300-000 | CAP, VALVE ADJ. | 1 |
| 1 | 12361-371-980 | CAP, VALVE ADJ. | 1 |
| 41300-HC4-000 | GEAR ASSY., FINAL | ||
| 41301-HC4-000 | (SOURCE: VINTAGE PARTS INC.) | ||
| 41310-HC4-300 | GEAR SET, FINAL | ||
| 41321-HC4-000 | COVER, FINAL GEAR CASE | ||
| 1 | 41405-HA7-670 | RING, STOPPER | 1 |
| 41411-HA0-000 | JOINT, PINION | ||
| 1 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 |
| 1 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 |
| 1 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 |
| 1 | 41451-HA0-000 | SHIM A, PINION GEAR (1.82) | 1 |
| 41452-HA0-000 | SHIM B, PINION GEAR (1.88) | ||
| 41453-HA0-000 | SHIM C, PINION GEAR (1.94) | ||
| 1 | 41454-HA0-000 | SHIM D, PINION GEAR (2.00) | 1 |
| 41455-HA0-000 | SHIM E, PINION GEAR (2.06) | ||
| 41456-HA0-000 | SHIM F, PINION GEAR (2.12) | ||
| 41457-HA0-000 | SHIM G, PINION GEAR (2.18) | ||
| 2 | 41540-HC4-000 | SPACER A, RING GEAR (1.26) | 2 |
| 2 | 41541-HC4-000 | SPACER B, RING GEAR (1.32) | 2 |
| 2 | 41542-HC4-000 | SPACER C, RING GEAR (1.38) | 2 |
| 2 | 41543-HC4-000 | SPACER D, RING GEAR (1.44) | 2 |
| 2 | 41544-HC4-000 | SPACER E, RING GEAR (1.50) | 2 |
| 2 | 41545-HC4-000 | SPACER F, RING GEAR (1.56) | 2 |
| 2 | 41546-HC4-000 | SPACER G, RING GEAR (1.62) | 2 |
| 2 | 41547-HC4-000 | SPACER H, RING GEAR (1.68) | 2 |
| 2 | 41548-HC4-000 | SPACER I, RING GEAR (1.74) | 2 |
| 2 | 41549-HC4-000 | SPACER J, RING GEAR (1.80) | 2 |
| 2 | 41550-HC4-000 | SPACER K, RING GEAR (1.86) | 2 |
| 41535-HC4-000 | SPACER U, RING GEAR (0.96) | ||
| 41536-HC4-000 | SPACER V, RING GEAR (1.02) | ||
| 41537-HC4-000 | SPACER W, RING GEAR (1.08) | ||
| 41538-HC4-000 | SPACER X, RING GEAR (1.14) | ||
| 41539-HC4-000 | SPACER Y, RING GEAR (1.20) | ||
| 41551-HC4-000 | SPACER L, RING GEAR (1.92) | ||
| 41552-HC4-000 | SPACER M, RING GEAR (1.98) | ||
| 41553-HC4-000 | SPACER N, RING GEAR (2.04) | ||
| 41554-HC4-000 | SPACER O, RING GEAR (2.10) | ||
| 41555-HC4-000 | SPACER P, RING GEAR (2.16) | ||
| 41556-HC4-000 | SPACER Q, RING GEAR (2.22) | ||
| 41557-HC4-000 | SPACER R, RING GEAR (2.28) | ||
| 41558-HC4-000 | SPACER S, RING GEAR (2.34) | ||
| 41559-HC4-000 | SPACER T, RING GEAR (2.40) | ||
| 42310-HC4-000 | AXLE, RR. | ||
| 43133-HC4-000 | TUBE, BREATHER (3.5X1200) | ||
| 2 | 50352-428-000 | RUBBER A, STOPPER | 2 |
| 2 | 50354-428-000 | RUBBER B, STOPPER | 2 |
| 1 | 50355-HC4-670 | PLATE, SKID | 1 |
| 1 | 50355-HM5-730 | (SOURCE: VINTAGE PARTS INC.) | 1 |
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 90116-965-000 | BOLT, FLANGE (8X10) | ||
| 6 | 90133-MB0-000 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HA0-000 | BOLT, FLANGE (10X35) | 2 |
| 90137-HA7-770 | BOLT, STUD (10X25) | ||
| 1 | 90244-HA0-000 | NUT, LOCK (60MM) | 1 |
| 1 | 90307-HC4-000 | NUT, RR. AXLE | 1 |
| 1 | 90307-HM5-930 | NUT, RR. AXLE | 1 |
| 1 | 90308-HC4-000 | NUT A, RR. AXLE | 1 |
| 1 | 90308-HM5-930 | NUT A, RR. AXLE | 1 |
| 1 | 90381-HA0-000 | NUT, HEX. (16MM) | 1 |
| 1 | 90471-580-000 | GASKET (8MM) | 1 |
| 1 | 90481-HC4-000 | WASHER, TAPER | 1 |
| 2 | 91051-HC4-003 | BEARING, RADIAL BALL (43X68X13) | 2 |
| 1 | 91061-HA7-672 | BEARING, NEEDLE (14X24.5X15) (KOYO) | 1 |
| 1 | 91061-HC4-003 | BEARING, NEEDLE (14X24.5X15) (NTN) | 1 |
| 91063-HC4-771 | BEARING, RADIAL BALL (22X56X16) | ||
| 1 | 91251-HA0-013 | OIL SEAL (38X64X11) (ARAI) | 1 |
| 1 | 91251-HC5-005 | OIL SEAL (38X64X11) (KOYO) | 1 |
| 1 | 91252-HC4-003 | DUST SEAL (42X58X11) | 1 |
| 1 | 91271-HC4-004 | OIL SEAL (42X51X7) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 1 | 91354-HC4-003 | O-RING (30.5X2.6) | 1 |
| 1 | 95002-02070 | CLIP, TUBE (B7) | 1 |
| 2 | 95701-08016-07 | BOLT, FLANGE (8X16) | 2 |
