Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705600122 | REAR CALIPER Includes 1 - 9. | ||
| 1 | 705600150 | Brake Pad Kit | 1 |
| 1 | 705600078 | Piston Set | 1 |
| 1 | 705600079 | Spring | 1 |
| 1 | 705600080 | Bleeding Screw | 1 |
| 1 | 705600081 | Pin Set (2) | 1 |
| 1 | 705600082 | Compression Boot | 1 |
| 1 | 705600083 | Compression Boot | 1 |
| 705600149 | Lining Support | ||
| 705600154 | REAR MASTER CYLINDER ASS'Y Includes 10 - 19. | ||
| 705600063 | Piston Set | ||
| 1 | 705600064 | PUSHER BRACKET, HOSE CONNECTOR | 1 |
| 705600155 | Rod Ass'y Includes 13 - 15. | ||
| 705600068 | Circlip | ||
| 705600090 | Compression Boot | ||
| 705600117 | Master Cylinder | ||
| XXXX | Not Available As Spare Part - Grease, 2 g | ||
| 1 | 705600067 | Oil Tank | 1 |
| 1 | 705600169 | OIL HOUSING HOSE | 1 |
| 705600269 | Brake Handle Includes 20 - 29. | ||
| 250000030 | Cable Screw | ||
| 1 | 705600270 | CLAMP KIT | 1 |
| 1 | 705600186 | LEVER | 1 |
| 705600187 | Pivot Kit | ||
| 705600188 | Lever Lock Kit | ||
| 705600224 | Lock lever | ||
| 1 | 705600225 | SPRING | 1 |
| 208032291 | Screw M3 X 22 | ||
| 1 | 232531423 | Elastic Stop Nut M3 | 1 |
| 205351646 | SOCKET HEAD SCREW M5 X 16 | ||
| 1 | 250400007 | Pin | 1 |
| 705600100 | Yoke | ||
| 1 | 232081414 | Hex. Nut M8 | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 710000099 | BRAKE SWITCH | ||
| 705600092 | BANJO BOLT | ||
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 1 | 210261680 | Hex. Flange Screw M6 X 16 | 1 |
| 1 | 705600056 | Banjo Bolt | 1 |
| 4 | 414920600 | Washer | 4 |
| 1 | 705600163 | Rear brake flexible hose | 1 |
| 2 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip (Scotch Grip) | 2 |
| 2 | 250000058 | Hex. screw M10 x 15 (Scotch Grip) | 2 |
| 1 | 705600147 | NUT | 1 |
| 1 | 207102544 | Hex. Screw M10 X 25 | 1 |
| 2 | 232006414 | Hex. Nut M10 X 1.5 | 2 |
| 1 | 705600125 | BRAKE PEDAL, BLACK | 1 |
| 1 | 705600107 | BRAKE PEDAL SPRING | 1 |
| 1 | 503107800 | WASHER | 1 |
| 1 | 293370012 | CIRCLIP | 1 |
| 2 | 293300053 | O-RING | 2 |
| 3 | 414115200 | Tie-Rap 180 mm | 3 |
| 2 | 278001009 | Female Terminal | 2 |
| 1 | 278001007 | Insulated Sheath | 1 |
| 1 | 705600272 | Circlip | 1 |
| 4 | 235381646 | Torx Screw M8 X 16, Scotch Grip | 4 |
| 705600167 | Brake disc | ||
| 705600173 | Spring | ||
| 705600124 | REAR BRAKE CABLE | ||
| 1 | 705600146 | CABLE BARREL | 1 |
| 1 | 705600145 | FLAT WASHER | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 414351600 | CLIP | 1 |
| 705600191 | Cable Support | ||
| 3 | 207661644 | Hex. Flange Screw M6 X 16 | 3 |
| 3 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 3 |
