Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 703500144 | Front Fender Kit Includes 1 - 7. (English Warn Labels Installed) Quest. | ||
| 703500138 | Front Fender Kit (Green - English Warn Labels Installed) Quest. | ||
| 703500140 | Front Fender Kit (Yellow) (English Warn Labels Installed) Quest XT. | ||
| 704900034 | Warning Label Includes 2 - 3. (Injuries-Death) | ||
| XXXX | Not Available As Spare Part - English Warning Label (Under 16) | ||
| 1 | 704900007 | Caution Decal, Transmission Selector (Transmission Selector) | 1 |
| 704900002 | Warning Decal, Death And Injuries (Injuries-Death) | ||
| 1 | 704900012 | Warning Decal, Under 16 Years Old (Under 16) | 1 |
| 704900008 | Caution Decal, Transmission Selector (Transmission Selector) | ||
| 703500152 | Front fascia Includes 8 - 9. | ||
| 1 | 704900130 | Bombardier Logo 68 mm | 1 |
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 224060201 | Flat Washer | 4 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 703500157 | Console Kit Includes 14 - 16. | ||
| 1 | 704900247 | CAUTION DECAL, CONSOLE LOAD (Max. Dash Cargo) | 1 |
| 704900250 | Caution Decal, Console Load (Max. Dash Cargo) | ||
| 250000043 | Phillips Screw M6 X 20, Scotch Grip (Scotch Grip) | ||
| 705000369 | HOOK, BLACK | ||
| 705000203 | LH cover Quest. | ||
| 705000334 | LH cover Quest. | ||
| 705000405 | LH Panel, yellow Quest XT. | ||
| 703500154 | RH cover Includes 20 - 22. ( English Warn Labels Installed) Quest. | ||
| 703500155 | RH cover (English Warn Labels Installed) Quest. | ||
| 703500156 | RH panel (English Warn Labels Installed) Quest XT. | ||
| XXXX | Not Available As Spare Part - English Warning Label (Transmission Selector - See item 4) | ||
| XXXX | Not Available As Spare Part - French Warning Label (Transmission Selector - See item 7) | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 703500148 | LH front mudguard Includes 24 - 25. | ||
| 703500149 | RH front mudguard | ||
| 1 | 705000083 | LH FRONT REFLECTOR | 1 |
| 705000026 | RH FRONT REFLECTOR | ||
| 16 | 207162044 | Hex. Screw M6 X 20 | 16 |
| 16 | 224060201 | Flat Washer | 16 |
| 16 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 16 |
| 1 | 705000133 | LH TANK PROTECTOR | 1 |
| 1 | 705000134 | RH TANK PROTECTOR | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 705000340 | Protector plate | ||
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 Quest. | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" Quest XT. | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 Quest. | 2 |
| XXXX | Not Available As Spare Part - Plate Ass'y Includes 37 - 40. | ||
| 705000308 | Motor Protector | ||
| 293830092 | Rubber Protector | ||
| 293830012 | Rubber Strip | ||
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip (Scotch Grip) | 2 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip (Scotch Grip) | 4 |
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 570041600 | Rubber Cover | ||
| 705000311 | Bracket, Black | ||
| 2 | 210261080 | Hex. Flange Screw M6 X 10 | 2 |
| 705000367 | LH Rear Grill, Black | ||
| 705000366 | RH Rear Grill, Black | ||
| 705000368 | LH Front Grill | ||
| 10 | 517302183 | Clip | 10 |
| 705000184 | Mouting plate Quest XT. | ||
| 705000185 | WINCH Quest XT. | ||
| 1 | 705000194 | CABLE GUIDE Quest XT. | 1 |
| 1 | 705000195 | Winch Hook Quest XT. | 1 |
| 1 | 250400018 | Cotter Pin Quest XT. | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 Quest XT. | 2 |
| 2 | 234081410 | Flat Washer 8 mm Quest XT. | 2 |
| 2 | 234181401 | Lock Washer 8 mm Quest XT. | 2 |
