Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705600238 | RH caliper Includes 1 - 9. | 1 |
| 1 | 705600349 | Brake Pad Kit | 1 |
| 705600294 | Piston Set | ||
| 2 | 705600079 | Spring | 2 |
| 2 | 705600080 | Bleeding Screw | 2 |
| 2 | 705600081 | Pin Set (2) | 2 |
| 2 | 705600082 | Compression Boot | 2 |
| 2 | 705600083 | Compression Boot | 2 |
| 705600297 | LH Caliper Support | ||
| 1 | 705600240 | LH caliper Includes 10 - 18. | 1 |
| 1 | 705600350 | Brake Pad Kit | 1 |
| XXXX | Not Available As Spare Part - LH Caliper support | ||
| 1 | 705600242 | Front Master Cylinder Includes 19 - 26. | 1 |
| 1 | 705600243 | Lever Arm | 1 |
| 705600244 | PISTON KIT | ||
| 1 | 705600084 | Cap Set | 1 |
| 1 | 705600246 | Brake Lever Bolt Kit | 1 |
| 705600087 | BRACKET KIT | ||
| 705600088 | CIRCLIP | ||
| 1 | 705600089 | COMPRESSION BOOT | 1 |
| 705600209 | Front brake handle hose | ||
| 705600206 | Vertical tube | ||
| 705600211 | Brake hose | ||
| 705600252 | Union tube | ||
| 705600210 | Rear rigid tube | ||
| 1 | 250000081 | Torx Screw M6 X 25 | 1 |
| 4 | 705600056 | Banjo Bolt | 4 |
| 705600253 | Hose retainer | ||
| 8 | 414920600 | Washer | 8 |
| 1 | 413710300 | Loctite 17914, Sealant, 80 ml | 1 |
| 3 | 390406500 | Pop Rivet 3/16" | 3 |
| 705600208 | Flexible hose | ||
| 1 | 705600254 | Rear Master Cylinder Includes 39 - 47. | 1 |
| 1 | 705600255 | PISTON SET | 1 |
| 1 | 705600064 | PUSHER BRACKET, HOSE CONNECTOR | 1 |
| 705600154 | REAR MASTER CYLINDER ASS'Y | ||
| 705600068 | Circlip | ||
| 705600090 | Compression Boot | ||
| XXXX | Not Available As Spare Part - Grease, therma lube, 2 g | ||
| 1 | 705600182 | Oil Tank, Brake Fluid Reservoir | 1 |
| 1 | 705600262 | OIL HOUSING HOSE | 1 |
| 1 | 250400007 | Pin | 1 |
| 705600100 | Yoke | ||
| 1 | 232081414 | Hex. Nut M8 | 1 |
| 710000099 | BRAKE SWITCH | ||
| 1 | 705600098 | BREAK PEDAL SPRING | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 705600263 | REAR CALIPER Includes 54 - 62. | ||
| 1 | 705600014 | Brake Pad Kit | 1 |
| 705600295 | Piston Set | ||
| 1 | 705600079 | Spring | 1 |
| 1 | 705600080 | Bleeding Screw | 1 |
| 1 | 705600081 | Pin Set (2) | 1 |
| 1 | 705600082 | Compression Boot | 1 |
| 1 | 705600083 | Compression Boot | 1 |
| 705600298 | LH CALIPER SUPPORT | ||
| 1 | 207661644 | Hex. Flange Screw M6 X 16 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 2 | 207582544 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 1 | 705600265 | BRAKE PEDAL | 1 |
| 1 | 705600283 | SPACER | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 2 | 293300053 | O-RING | 2 |
| 8 | 207581244 | Hex. Flange Screw M8 X 12, Scotch Grip | 8 |
| 2 | 705600279 | Front Brake Disc | 2 |
| 4 | 235381646 | Torx Screw M8 X 16, Scotch Grip | 4 |
| 1 | 705600271 | Brake Disc | 1 |
| 1 | 207605544 | Hex. Flange Screw M10 X 55 | 1 |
| 1 | 233201414 | Hex. Flange Elastic Nut M10 | 1 |
| 235382546 | Torx Screw Scotch Grip M8 X 25 | ||
| 705600308 | Open clamp | ||
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| XXXX | Not Available As Spare Part - Bracket | ||
| 293600063 | BRAKE FLUID, SRF, DOT 4 | ||
| 293600062 | BRAKE FLUID, GTLMA, DOT 4, 12 X 354 ML |
