Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705400166 | Drive axle | ||
| 705400146 | Stopper | ||
| 703500255 | Rubber Boot Kit Includes 3 - 5. | ||
| 705400148 | Collar | ||
| 2 | 293650138 | Oetiker Gear Clamp 44.0MM | 2 |
| 1 | 705400036 | Wear Ring | 1 |
| 705400150 | Front differential ass'y Includes 7 - 30. | ||
| 705400133 | Front Cover | ||
| 705400131 | Differential Carrier | ||
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705400212 | Differential | 1 |
| 293250137 | Oil Seal | ||
| 2 | 293350044 | Ball Bearing | 2 |
| 1 | 705500245 | Drain Plug | 1 |
| 2 | 705500259 | Ball Bearing | 2 |
| 1 | 705500260 | Ball Bearing | 1 |
| 1 | 705500261 | Needle Bearing | 1 |
| 1 | 705500262 | Vent Valve | 1 |
| 6 | 705500264 | Screw | 6 |
| 1 | 705500265 | Seal | 1 |
| 8 | 705400101 | RING GEAR SCREW | 8 |
| 1 | 705500266 | Nut | 1 |
| 1 | 705400192 | GEAR, 36 TEETH | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 705500268 | GEAR, 10 TEETH | ||
| 1 | 705500269 | RETAINING RING | 1 |
| 705500246 | Protector Plug | ||
| 2 | 705500255 | Oil Seal | 2 |
| 1 | 705600311 | CLAMP | 1 |
| 1 | 703500288 | Differential Shim Spool Kit | 1 |
| 705400097 | RH CV Joint Includes 31 - 40. | ||
| 1 | 705400154 | CV JOINT | 1 |
| 1 | 705400127 | Boot Wheel Kit Includes 33 - 35. | 1 |
| 2 | 705400064 | CLAMP | 2 |
| 705400180 | Clamp | ||
| 1 | 705400126 | Boot Differential Kit Includes 36 - 38. | 1 |
| 705400181 | Clamp | ||
| 1 | 705400156 | RH PLUNGING JOINT | 1 |
| 1 | 705400042 | CIRCLIP | 1 |
| 705400096 | LH CV Joint Includes 41 - 50. | ||
| 1 | 705400127 | Boot Wheel Kit Includes 43 - 45. | 1 |
| 1 | 705400126 | Boot Differential Kit Includes 46 - 48. | 1 |
| 1 | 705400155 | PLUNGING JOINT | 1 |
| 2 | 293350040 | Cone Bearing | 2 |
| 1 | 705400149 | Coupling Sleeve | 1 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 230602546 | Hex. Flange Screw M10 X 125 | 2 |
| 2 | 233201416 | Hex. Flange Elastic Nut M10 | 2 |
| 2 | 705500372 | Wear Sleeve | 2 |
| 705500361 | WHEEL HUB ASS'Y Includes 57 - 58. | ||
| 8 | 250300020 | Wheel Stud | 8 |
| 2 | 250200019 | WASHER | 2 |
| 2 | 232291413 | Hex. Flange Castellated Nut M18 | 2 |
| 2 | 250400016 | Cotter Pin | 2 |
| 1 | 705400066 | Rubber Bellow | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 705400012 | WHEEL CAP | ||
| 705400213 | Front Tire | ||
| 705400160 | Front Rim | ||
| 2 | 705400193 | Rim Valve With Cap | 2 |
| 8 | 250100042 | Steel Wheel Nut | 8 |
| 2 | 293250090 | Oil Seal | 2 |
| 2 | 705400179 | WEAR SLEEVE | 2 |
| 1 | 250200014 | Flat Washer M10 | 1 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip | 1 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| XXXX | Not Available As Spare Part - Shifting unit Includes 75 - 94. | ||
| 705400169 | HOUSING | ||
| 1 | 705400171 | Actuator | 1 |
| 3 | 250000137 | Hex. Flange Screw M8 X 20, Scotch Grip | 3 |
| 1 | 705400172 | Union Shaft | 1 |
| 1 | 206580890 | Pressure Screw M8 X 8 | 1 |
| 293370031 | Circlip | ||
| 1 | 250400020 | Pin dowell | 1 |
| 1 | 705400249 | Ball Bearing | 1 |
| 1 | 705400175 | Slider | 1 |
| 705400176 | Fork | ||
| 1 | 293370029 | Circlip | 1 |
| 1 | 293370030 | Circlip | 1 |
| 1 | 710000324 | SWITCH | 1 |
| 1 | 705400177 | Sleeve Coupling | 1 |
| 1 | 293250138 | Oil Seal | 1 |
| 1 | 705400182 | Shifter Plate | 1 |
| 1 | 705600310 | Copper Washer | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 293600037 | Engine oil 5W/30 | ||
| 3 | 250000136 | Socket Head Screw M8 X 20, Scotch Grip | 3 |
| 1 | 293300091 | O-Ring | 1 |
| 705500228 | Fill level plug | ||
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
