Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 0 | 13S-2117V-00-P0 | COVER 7 UR FOR DPBMC | 0 |
| 1 | 13S-2117V-00-P3 | COVER 7 UR FOR SMX | 1 |
| 13S-2117V-00-P4 | COVER 7 UR FOR S3 | ||
| 1 | 90480-12613-00 | GROMMET | 1 |
| 1 | 90387-067K8-00 | COLLAR | 1 |
| 1 | 90480-14003-00 | GROMMET | 1 |
| 1 | 90387-06057-00 | COLLAR | 1 |
| 1 | 90183-05076-00 | NUT, SPRING | 1 |
| 1 | 90338-06134-00 | PLUG | 1 |
| 1 | 90111-05003-00 | BOLT, HEXAGON SOCKET HEAD | 1 |
| 1 | 90202-05180-00 | WASHER, PLATE | 1 |
| 1 | 90111-06063-00 | BOLT, HEX. SOCKET BUTTON | 1 |
| 1 | 90111-06040-00 | BOLT, HEX. SOCKET BUTTON | 1 |
| 0 | 13S-2117W-00-P4 | COVER 8 UR FOR S3 | 0 |
| 0 | 13S-2117W-00-P0 | COVER 8 UR FOR DPBMC | 0 |
| 1 | 13S-2117W-00-P3 | COVER 8 UR FOR SMX | 1 |
| 1 | 90464-20014-00 | CLAMP | 1 |
| 13S-28385-00-P2 | COVER, LOWER UR FOR S3 | ||
| 13S-W2838-00-P1 | UNDER COVER COMP 1 UR SMX FOR DPBMC | ||
| 1 | 13S-28385-00-P1 | COVER, UNDER UR FOR SMX | 1 |
| 1 | 13S-28301-00-00 | GRAPHIC SET, LOWER COVER 1 FOR DPBMC | 1 |
| 2 | 90480-14003-00 | GROMMET | 2 |
| 2 | 90387-06057-00 | COLLAR | 2 |
| 1 | 13S-2838G-00-00 | SEAT 1 | 1 |
| 1 | 13S-2836U-00-00 | DAMPER, LOCATING 2 | 1 |
| 2 | 90111-06040-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 13S-W283U-10-P0 | PANEL ASSY 1 UR FOR DPBMC | ||
| 1 | 13S-2835U-00-P3 | PANEL 1 UR MBL2 FOR SMX | 1 |
| 13S-W283U-00-P4 | PANEL ASSY 1 UR MT1 FOR S3 | ||
| 1 | 13S-28328-30-00 | EMBLEM UR FOR S3 | 1 |
| 1 | 13S-28391-30-00 | GRAPHIC 1 UR FOR DPBMC | 1 |
| 1 | 13S-28328-20-00 | EMBLEM FOR SMX | 1 |
| 1 | 13S-28219-00-00 | COVER 1 | 1 |
| 2 | 90183-05M02-00 | NUT, SPRING | 2 |
| 1 | 13S-28415-00-00 | DAMPER 1 | 1 |
| 1 | 13S-24183-00-00 | DAMPER, LOCATING 3 | 1 |
| 1 | 97707-50016-00 | SCREW, TRUSS HEAD TAPPING | 1 |
| 1 | 90269-07007-00 | RIVET | 1 |
| 1 | 13S-2137U-00-00 | GUIDE, AIR 1 | 1 |
| 1 | 13S-2137K-00-00 | GUIDE, AIR 3 | 1 |
| 4 | 97702-50016-00 | SCREW, TAPPING | 4 |
| 2 | 90480-01558-00 | GROMMET | 2 |
| 1 | 13S-28217-00-00 | DAMPER 1 | 1 |
| 2 | 90269-06008-00 | RIVET | 2 |
| 2 | 90269-06081-00 | RIVET | 2 |
| 6 | 97707-50016-00 | SCREW, TRUSS HEAD TAPPING | 6 |
| 2 | 97702-50020-00 | SCREW, TAPPING | 2 |
| 13S-W2839-00-P1 | UNDER COVER COMP 2 UR SMX FOR DPBMC | ||
| 0 | 13S-28395-00-P2 | COVER, UNDER UR FOR S3 | 0 |
| 1 | 13S-28395-00-P1 | COVER, UNDER 2 UR FOR SMX | 1 |
| 13S-28303-00-00 | GRAPHIC SET, LOWER COVER 2 FOR DPBMC | ||
| 1 | 13S-2848K-00-00 | SEAT 2 | 1 |
| 1 | 13S-2847R-00-00 | DAMPER 10 | 1 |
| 1 | 13S-2835V-00-P3 | PANEL 2 UR MBL2 FOR SMX | 1 |
| 13S-W283V-10-P0 | PANEL 2 UR SMX FOR DPBMC | ||
| 0 | 13S-W283V-00-P4 | PANEL 2 UR MT1 FOR S3 | 0 |
| 0 | 13S-28392-30-00 | GRAPHIC 2 UR FOR DPBMC | 0 |
| 0 | 13S-28338-30-00 | EMBLEM UR FOR S3 | 0 |
| 1 | 13S-28338-20-00 | EMBLEM FOR SMX | 1 |
| 1 | 13S-28229-00-00 | COVER 2 | 1 |
| 2 | 97707-50016-00 | SCREW, TRUSS HEAD TAPPING | 2 |
| 1 | 90109-06207-00 | BOLT | 1 |
| 1 | 90202-10024-00 | WASHER, PLATE | 1 |
| 1 | 13S-2836G-00-00 | BRACKET 4 | 1 |
| 1 | 90179-06059-00 | NUT | 1 |
| 1 | 90105-06020-00 | BOLT, FLANGE | 1 |
| 1 | 13S-2137V-00-00 | GUIDE, AIR 2 | 1 |
| 1 | 13S-2137L-00-00 | GUIDE, AIR 4 | 1 |
| 1 | 13S-2836L-00-00 | PANEL, INNER 2 | 1 |
| 5 | 90269-06008-00 | RIVET | 5 |
| 2 | 90269-06002-00 | RIVET | 2 |
| 1 | 13S-2836M-00-00 | PANEL, INNER 3 | 1 |
| 1 | 90269-06008-00 | RIVET | 1 |
| 2 | 13S-2153A-00-00 | EMBLEM, YAMAHA UR FOR SMX | 2 |
| 13S-2153E-30-00 | EMBLEM, YAMAHA UR FOR DPBMC | ||
| 0 | 13S-2153E-40-00 | EMBLEM, YAMAHA UR FOR S3 | 0 |
| 1 | 13S-2834C-00-00 | EMBLEM 1 FOR SMX | 1 |
| 13S-2835C-00-00 | EMBLEM 2 FOR SMX | ||
| 2 | 4P6-28338-00-00 | EMBLEM FOR SMX | 2 |
| 4P6-28328-00-00 | EMBLEM FOR SMX | ||
| 1 | 13S-21737-00-00 | EMBLEM FOR SMX | 1 |
| 13S-21737-10-00 | EMBLEM FOR SMX |
