Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 732610072 | Push Nut | 2 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 207603044 | Hex. Flange Screw M10 X 30 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705001827 | Front Bumper | 1 |
| 1 | 705001981 | RH Footboard Ass'y | 1 |
| 1 | 705001940 | LH Footboard | 1 |
| 705001462 | ENGINE COVER | ||
| 2 | 210261280 | Hex. Flange Screw M6 X 12 | 2 |
| 1 | 705000657 | Engine Cover Support | 1 |
| 1 | 705001826 | Engine Cover Support | 1 |
| 705002121 | ENGINE COVER SUPPORT | ||
| 1 | 705005156 | Oval Washer | 1 |
| 1 | 210261280 | Hex. Flange Screw M6 X 12 | 1 |
| 4 | 705000428 | Footrest | 4 |
| 12 | 207662584 | Hex. Flange Screw M6 X 25 | 12 |
| 4 | 234161471 | Lock Washer M6, Black | 4 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 12 |
| 12 | 250000261 | Torx Screw M6 X 16 | 12 |
| 1 | 705001910 | Black LH Cap | 1 |
| 1 | 703500588 | FRONT FENDER KIT, RED Includes 23 to 29, Viper Red B-176 | 1 |
| 703500589 | FRONT FENDER KIT, YELLOW Includes 23 to 29, Yellow B-190 | ||
| 1 | 703500590 | FRONT FENDER KIT, GREEN Includes 23 to 29, Laurentian Green B-241 | 1 |
| 1 | 704901089 | Warning Decal, Load | 1 |
| 1 | 704900642 | Warning Decal, Under 16 Years Old | 1 |
| 704900904 | Warning Decal, Death And Injuries | ||
| 704901090 | Warning Decal, Load | ||
| 1 | 704900436 | WARNING DECAL, UNDER 16 YEARS OLD | 1 |
| 704900905 | Warning Decall, Death And Injuries | ||
| 703500581 | REAR FENDER, RED Includes 30 to 40, Viper Red B-176 | ||
| 1 | 703500582 | Rear Fender, Yellow Includes 30 to 40, Yellow B-190 | 1 |
| 703500583 | REAR FENDER, GREEN Includes 30 to 40, Laurentian Green B-241 | ||
| 704901113 | WARNING DECAL, UNDER 12 YEARS OLD English Version | ||
| 1 | 704901089 | Warning Decal, Load English Version | 1 |
| 1 | 704901119 | WARNING DECAL, TIRE PRESSURE English Version | 1 |
| 704901090 | Warning Decal, Load French Version | ||
| 704901122 | WARNING DECAL, UNDER 12 YEARS OLD French Version | ||
| 704901159 | Warning Decal, Tire Pressure French Version | ||
| 1 | 705002085 | REFLECTIVE SHEET | 1 |
| 1 | 705002014 | REFLECTIVE SHEET | 1 |
| 1 | 705002189 | REFLECTIVE SHEET | 1 |
| 1 | 705002191 | REFLECTIVE SHEET | 1 |
| 703500594 | REAR FENDER, RED Includes 41 to 54, Viper Red B-176, Europe | ||
| 1 | 703500595 | REAR FENDER, YELLOW Includes 41 to 54, Yellow B-190, Europe | 1 |
| 1 | 703500596 | REAR FENDER, GREEN Includes 41 to 54, Laurentian Green B-241, Europe | 1 |
| 1 | 704901112 | Warning Decal, Road Use English Version | 1 |
| 704901177 | WARNING DECAL, MULTILINGUAL | ||
| 704901158 | Warning Decal, Public Roads Use French Version | ||
| 1 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 1 |
