Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 708300674 | Rear Storage Box | 1 |
| 1 | 708300150 | Rear Panel Except Model Europe | 1 |
| 1 | 708300511 | Rear Panel Model Europe | 1 |
| 1 | 708301212 | Rear Storage Box Cover Except Max, Except XMR 1000 | 1 |
| 1 | 715002635 | Rear Storage Box Cover Out Max North America | 1 |
| 1 | 715002638 | Rear Storage Box Cover Out Max Except North America | 1 |
| 1 | 715004097 | Rear Storage Box Cover Package XMR 1000 North America | 1 |
| 1 | 715004099 | Rear Storage Box Cover Package XMR 1000 International | 1 |
| 1 | 707002102 | Heat Shield | 1 |
| 1 | 219704369 | Was 293200163 Neoprene Seal | 1 |
| 1 | 708200272 | Handle | 1 |
| 1 | 704700168 | Tool Kit Includes 90 to 90a | 1 |
| 1 | 529000085 | Socket Wrench 14/16MM | 1 |
| 1 | 529000035 | Adjustment Wrench | 1 |
| 1 | 715001564 | Rear Bumper Ass'y North America Except Black | 1 |
| 1 | 715002241 | Rear Bumper Ass'y International Except Black | 1 |
| 1 | 715002242 | Rear Bumper Ass'y Europe Except Black | 1 |
| 1 | 715002242 | Rear Bumper Ass'y T3 Except Black | 1 |
| 1 | 715004101 | Black Rear Bumper Ass'y North America Black | 1 |
| 1 | 715004103 | Black Rear Bumper Ass'y International Black | 1 |
| 1 | 715004104 | Black Rear Bumper Ass'y Europe Black | 1 |
| 1 | 715004104 | Black Rear Bumper Ass'y T3 Black | 1 |
| 293450274 | Insert | ||
| 293450274 | Insert Model Europe | ||
| 2 | 233251434 | Flange Elastic Nut M5 Except Model Europe | 2 |
| 8 | 250000048 | Panel Nut M6 X 1.0 | 8 |
| 2 | 250000807 | Torx Truss Screw M6 X 25 Except Model XMR 1000 | 2 |
| 1 | 705006997 | LH Cargo Support | 1 |
| 1 | 705006998 | RH Cargo Support | 1 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 6 | 207662544 | Hex. Flange Screw M6 X 25 | 6 |
| 4 | 207661644 | Hex. Flange Screw M6 X 16 Except Model Europe | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 Except Model Europe | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 207561646 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 4 | 207661634 | Hex. Flange Screw M6 X 16 Model Europe | 4 |
| 1 | 705004563 | LH Support | 1 |
| 1 | 705004564 | RH Support | 1 |
| 4 | 207682044 | Hex. Flange Screw M8 X 20 | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 4 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 4 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 705004806 | Plate Support | 1 |
| 1 | 205951046 | Socket Head Screw M5 X 10 Model Europe | 1 |
| 1 | 206252044 | Socket Set Screw M5 X 20 Model Europe | 1 |
| 2 | 705202576 | Reflector Support Except Model Europe | 2 |
| 2 | 705011221 | Red Reflector Except Model Europe | 2 |
| 1 | 708200408 | Box Ass'y Outlander Max | 1 |
| 2 | 269501945 | Clip Outlander Max | 2 |
| 1 | 219704452 | Was 715900411 Neoprene Seal Outlander Max | 1 |
