Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 715002374 | Protective Plate Kit | 1 |
| 2 | 207662054 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 705006812 | Cargo Rack Center Support | 1 |
| 6 | 207682044 | Hex. Flange Screw M8 X 20 | 6 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 2 | 207582544 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 12 | 233281434 | Hex. Flange Elastic Nut M8 | 12 |
| 1 | 705011540 | LH Structural Footboard Includes 70 to 70a | 1 |
| 4 | 232862412 | Square Nut M6 | 4 |
| 1 | 705011542 | RH Structural Footboard Includes 80 to 80a | 1 |
| 5 | 232862412 | Square Nut M6 | 5 |
| 8 | 207763554 | Carriage Bolt M6 X 35 | 8 |
| 8 | 234062410 | Flat Washer 6 mm | 8 |
| 1 | 705007040 | LH Step | 1 |
| 1 | 705007039 | RH Step | 1 |
| 9 | 207661654 | Hex. Flange Screw M6 X 16 | 9 |
| 4 | 224061201 | Flat Washer | 4 |
| 4 | 250000957 | Extruded Panel Nut M6 | 4 |
| 1 | 715003984 | Dash Support Kit | 1 |
| 2 | 293830005 | Rubber Bumper | 2 |
| 1 | 715004087 | Indicator | 1 |
| 1 | 705005003 | Shiftgate Trim | 1 |
| 2 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 2 |
| 1 | 705012822 | Fascia | 1 |
| 705009253 | Black, Front Bumper Support | ||
| 2 | 705004565 | Lower Fender Support | 2 |
| 2 | 715002784 | Rack Kit | 2 |
| 1 | 705013222 | ESD Bracket | 1 |
| 2 | 705005469 | Tube | 2 |
| 2 | 705005470 | Tube | 2 |
| 1 | 705004523 | Lugage Rack Moulding | 1 |
| 1 | 705011553 | LH Support Luggage Rack Ass'y Includes 350 to 350c | 1 |
| 2 | 269501943 | Elastic Nut Housing M8 | 2 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 705011555 | RH Support Luggage Rack Ass'y Includes 360 to 360c | 1 |
| 16 | 250000646 | Black, Torx Screw M6 X 35 | 16 |
| 2 | 235564054 | Screw-torx Button Head M6 X 40 | 2 |
| 8 | 250100199 | Insert Half Hex Body M6 x 1.0 | 8 |
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 4 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 4 | 241140060 | Screw K40 X 10 | 4 |
| 2 | 207567044 | Hex. Flange Screw M6x70, Scotch Grip | 2 |
| 2 | 250000886 | Torx Screw M8 X 30 | 2 |
| 2 | 207683534 | Hex. Flange Screw M8 X 35 | 2 |
| 8 | 517302785 | Edge Clip | 8 |
| 2 | 250000101 | Plastite Screw Type K-40, M4 X 25 | 2 |
| 1 | 707002456 | Heat Shield | 1 |
| 1 | 707002457 | Heat Shield | 1 |
| 1 | 707002458 | Heat Shield | 1 |
| 1 | 707002459 | Heat Shield | 1 |
| 1 | 707002460 | Heat Shield | 1 |
| 1 | 707002461 | Heat Shield | 1 |
| 1 | 707002462 | Heat Shield | 1 |
| 707002463 | Heat Shield | ||
| 1 | 707002464 | Heat Shield | 1 |
| 1 | 705006651 | LH Rear Facia | 1 |
| 1 | 707002103 | Heat Shield | 1 |
| 1 | 707002107 | Heat Shield | 1 |
| 1 | 707002293 | Heat Shield | 1 |
| 1 | 705006652 | RH Rear Facia | 1 |
| 1 | 705007277 | LH Support | 1 |
| 1 | 705007278 | RH Support | 1 |
| 4 | 732610072 | Push Nut | 4 |
| 7 | 250000722 | Torx Screw M6 X 20 | 7 |
| 1 | 207661654 | Hex. Flange Screw M6 X 16 | 1 |
| 1 | 705006300 | Front Guard Plate | 1 |
| 2 | 705004497 | Ring | 2 |
| 1 | 705009760 | Squadron Green, LH Lateral Panel | 1 |
| 1 | 707002467 | Heat Shield | 1 |
| 1 | 705009764 | Squadron Green, RH Lateral Panel | 1 |
| 2 | 250000723 | Phillips Screw K40 X 16 | 2 |
| 1 | 705004147 | LH Extension Pannel | 1 |
| 1 | 705003444 | Engine Cover | 1 |
| 1 | 715002783 | Dash Kit T3<>P-WIN | 1 |
| 1 | 705012572 | Gauge Support Includes 700 to 700a | 1 |
| 4 | 705003264 | Grommet | 4 |
| 1 | 705011462 | RH Rear Inner Fender | 1 |
| 1 | 705011463 | RH Front Inner Fender | 1 |
| 1 | 705013111 | LH Rear Inner Fender | 1 |
| 1 | 705011465 | LH Front Inner Fender | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 2 | 293250242 | Rubber Cover | 2 |
