Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 207-23117-00-00 | Guide, Spring | ||
| 232-23100-60-55 | Front Fork Assembly ADRIAN BLUE | ||
| 232-23100-61-56 | Front Fork Assembly BRILLIANT RED | ||
| 209-23126-40-35 | Tube, Outer 1 | ||
| 207-23134-01-00 | Tube, Inner 2 | ||
| 232-23132-60-00 | Cover, Outer 2 | ||
| 215-23126-40-00 | Tube, Outer 1 ISO | ||
| 215-23100-40-63 | Front Fork Assembly BRILLIANT RED ISO | ||
| 209-23136-40-35 | Tube, Outer 2 | ||
| 215-23136-40-00 | Tube, Outer 2 ISO | ||
| 2 | 207-23147-00-00 | . O-Ring | 2 |
| 122-23147-00-00 | . O-Ring | ||
| 207-23124-01-00 | Tube, Inner 1 | ||
| 206-23124-00-00 | Tube, Inner 1 | ||
| 109-23125-00-00 | . Metal, Slide 1 | ||
| 357-23125-90-00 | Metal, Slide 1 | ||
| 209-23150-40-00 | Outer Nut | ||
| 196-23150-41-00 | Outer Nut | ||
| 2 | 109-23145-01-00 | . . Oil Seal | 2 |
| 122-23145-51-00 | . . Unavailable In Price Book | ||
| 2 | 276-23145-51-00 | . . Oil Seal | 2 |
| 122-23143-00-00 | Seat, Spring Lower | ||
| 109-23143-00-00 | Seat, Spring Lower | ||
| 206-23118-00-00 | Spacer | ||
| 355-23141-00-00 | . Spring Front Fork | ||
| 215-23141-40-00 | Spring, Front Fork | ||
| 209-23142-40-00 | Seat, Spring Upper | ||
| 215-23142-41-00 | Seat, Spring Upper | ||
| 232-23122-60-00 | Cover, Outer 1 | ||
| 196-23122-40-00 | Cover, Outer 1 | ||
| 183-23163-00-00 | Gasket | ||
| 207-23163-00-00 | Gasket | ||
| 207-23116-01-00 | Guide, Cover Lower | ||
| 196-23116-40-00 | Guide, Cover Lower | ||
| 206-23121-60-33 | Cover, Upper 1 YAMAHA BLACK | ||
| 207-23121-00-63 | Cover, Upper 1 BRILLIANT RED | ||
| 207-23121-00-62 | Cover, Upper 1 ADRIAN BLUE | ||
| 206-23131-60-63 | Cover, Upper 2 BRILLIANT RED | ||
| 2 | 307-23114-00-00 | . Gasket | 2 |
| 2 | 205-23111-40-00 | . Bolt, Cap | 2 |
| 2 | 207-23112-00-00 | . Washer, Cap | 2 |
| 207-23340-00-33 | Under Bracket | ||
| 206-23340-00-33 | Under Bracket | ||
| 2 | 5J0-23346-00-00 | . Bolt 1 | 2 |
| 2 | 92990-10100-00 | . Washer, Spring | 2 |
| 183-23318-00-00 | Holder, Cable 1 | ||
| 196-23191-40-00 | . Boot, Front Fork | ||
| 1 | 97001-08025-00 | . Bolt (1Nv) | 1 |
| 1 | 92990-08100-00 | . Washer, Spring | 1 |
| 1 | 156-23412-00-00 | . Race, Ball 2 | 1 |
| 38 | 93501-04011-00 | Ball | 38 |
| 1 | 156-23411-00-00 | Race, Ball 1 | 1 |
| 1 | 183-23411-00-00 | Race, Ball 1 | 1 |
| 1 | 183-23412-00-00 | Race, Ball 2 | 1 |
| 1 | 136-23415-00-00 | Cover, Ball Race 1 | 1 |
| 1 | 90179-25051-00 | Nut | 1 |
| 207-23435-00-35 | Crown, Handle | ||
| 1 | 90209-10021-00 | Washer, Spec''l Shap | 1 |
| 1 | 90105-10006-00 | Bolt, Flange | 1 |
| 1 | 164-23462-00-00 | Seal, Dust | 1 |
| 462-23441-00-00 | Holder, Handle Upr (122-23441-0 | ||
| 122-23442-02-98 | Unavailable In Price Book (122- | ||
| 4 | 97013-06035-00 | Bolt | 4 |
| 4 | 92995-06100-00 | Washer, Spring | 4 |
| 2 | 95303-10600-00 | Nut (95301-10600-00) | 2 |
| 2 | 92990-10100-00 | Washer, Spring | 2 |
| 2 | 92990-10200-00 | Washer, Plain | 2 |
| 137-23480-00-00 | Steering Lock Assembly | ||
| 2 | 98780-06016-00 | Screw, Flat Head (92603-06016) | 2 |
| 124-21510-00-35 | Fender, Front SILVER | ||
| 220-21510-00-35 | Fender, Front SILVER | ||
| 4 | 97313-08012-00 | Bolt, Hexagon | 4 |
| 4 | 92990-08100-00 | Washer, Spring | 4 |
| 2 | 97001-06018-00 | Bolt | 2 |
| 2 | 92995-06100-00 | Washer, Spring | 2 |
| 2 | 95380-06600-00 | .Nut, Hexagon | 2 |
| 174-21518-00-00 | Holder, Cable | ||
| 1 | 92995-06100-00 | Washer, Spring | 1 |
| 1 | 95380-06600-00 | .Nut, Hexagon | 1 |
| 233-85111-00-00 | Reflector, Front 1 | ||
| 2 | 92990-05100-00 | .Washer, Spring | 2 |
| 92990-05200-00 | .Washer, Plain |
