Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705200196 | WINCH LATCH, BLACK | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 705000591 | Front Bumper, Black STD | ||
| 705000585 | FRONT BUMPER, BLACK LE & XT | ||
| 6 | 207682044 | Hex. Flange Screw M8 X 20 STD | 6 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 LE & XT | 2 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 LE & XT | 4 |
| 6 | 233281414 | Hex. Flange Elastic Nut M8 | 6 |
| 705000671 | RH footrest cover | ||
| 705000672 | LH footrest cover | ||
| 705000631 | Footrest, Black | ||
| 250000032 | PHILLIPS SCREW M6 X 30 | ||
| 8 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 8 |
| 703500276 | Front fender kit (Viper red) Includes 12 - 15. STD & LE | ||
| 703500293 | Front fender kit XT | ||
| 704900451 | Warning Label (Inguries and death) | ||
| 1 | 704900515 | Warning Label (Under 16 years old) | 1 |
| 1 | 704900007 | Caution Decal, Transmission Selector (Transmission selector) | 1 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 705000708 | Front Fascia, Slate Gray | ||
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 4 | 224060201 | Flat Washer | 4 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 703500264 | Front Luggage Rack, Black Includes 23 - 25. | ||
| 704900037 | Warning Label, Front Load (Front load) | ||
| 704900038 | Warning Label, Tray Cover (Fasten cover) | ||
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 4 | 250000035 | TRUSS PHILLIPS SCREW M6 X 25 | 4 |
| 705000710 | Tank Cover, Slate Gray | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 705000711 | LH Front Mudguard | ||
| 705000712 | RH Front Mudguard | ||
| 705000755 | Mudguard Extension | ||
| 4 | 293150089 | Tuflok Plastic Rivet | 4 |
| 4 | 234082410 | Flat Washer 8 mm | 4 |
| 12 | 207162044 | Hex. Screw M6 X 20 | 12 |
| 4 | 207162544 | Hex. Screw M6 X 25 | 4 |
| 16 | 224060201 | Flat Washer | 16 |
| 2 | 705000754 | PLATE | 2 |
| 16 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 16 |
| 1 | 705000713 | PROTECTOR PLATE, SLATE GRAY | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 STD & LE | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" XT | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 STD & LE | 2 |
| 705000675 | Skid Plate | ||
| 6 | 705200533 | CUP | 6 |
| 6 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 6 |
| 705000081 | Lever Indicator | ||
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 570041600 | Rubber Cover | ||
| 705000184 | Mouting plate XT | ||
| 705000185 | WINCH XT | ||
| 1 | 705000194 | CABLE GUIDE XT | 1 |
| 1 | 705000618 | Hook XT | 1 |
| 1 | 250400022 | Cotter Pin XT | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 XT | 2 |
| 4 | 234081410 | Flat Washer 8 mm XT | 4 |
| 4 | 234181401 | Lock Washer 8 mm XT | 4 |
| 1 | 250400021 | Clevis Pin XT | 1 |
