Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06910-HM7-610 | BEARING SET, NEEDLE | 1 |
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 1 | 12361-300-000 | CAP, VALVE ADJ. | 1 |
| 1 | 12361-371-980 | CAP, VALVE ADJ. | 1 |
| 1 | 41300-HN5-670 | GEAR ASSY., RR. FINAL | 1 |
| 1 | 41300-HN5-671 | GEAR ASSY., RR. FINAL | 1 |
| 1 | 41311-HN5-670 | CASE SET, FINAL | 1 |
| 1 | 41311-HN5-671 | CASE SET, FINAL | 1 |
| 1 | 41320-HN5-670 | COVER SET, GEAR CASE | 1 |
| 1 | 41320-HN5-671 | COVER SET, GEAR CASE | 1 |
| 1 | 41405-HA7-670 | RING, STOPPER | 1 |
| 1 | 41421-HN5-670 | GEAR, PINION | 1 |
| 1 | 41431-HN5-670 | GEAR, RING | 1 |
| 1 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 |
| 1 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 |
| 1 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 |
| 1 | 41447-HM8-000 | SHIM A, PINION GEAR (1.64) | 1 |
| 1 | 41448-HM8-000 | SHIM B, PINION GEAR (1.70) | 1 |
| 1 | 41449-HM8-000 | SHIM C, PINION GEAR (1.76) | 1 |
| 1 | 41451-HM8-000 | SHIM D, PINION GEAR (1.82) | 1 |
| 1 | 41452-HM8-000 | SHIM E, PINION GEAR (1.88) | 1 |
| 1 | 41453-HM8-000 | SHIM F, PINION GEAR (1.94) | 1 |
| 1 | 41454-HM8-000 | SHIM G, PINION GEAR (2.00) | 1 |
| 1 | 41455-HM8-000 | SHIM H, PINION GEAR (2.06) | 1 |
| 1 | 41456-HM8-000 | SHIM I, PINION GEAR (2.12) | 1 |
| 1 | 41457-HM8-000 | SHIM J, PINION GEAR (2.18) | 1 |
| 1 | 41540-HA0-000 | SPACER A, RING GEAR (1.82) | 1 |
| 1 | 41541-HA0-000 | SPACER B, RING GEAR (1.88) | 1 |
| 1 | 41542-HA0-000 | SPACER C, RING GEAR (1.94) | 1 |
| 1 | 41543-HA0-000 | SPACER D, RING GEAR (2.00) | 1 |
| 1 | 41544-HA0-000 | SPACER E, RING GEAR (2.06) | 1 |
| 1 | 41545-HA0-000 | SPACER F, RING GEAR (2.12) | 1 |
| 1 | 41546-HA0-000 | SPACER G, RING GEAR (2.18) | 1 |
| 1 | 41547-HA0-000 | SPACER H, RING GEAR (2.24) | 1 |
| 1 | 41548-HA0-000 | SPACER I, RING GEAR (2.30) | 1 |
| 1 | 41540-HC4-000 | SPACER A, RING GEAR (1.26) | 1 |
| 1 | 41541-HC4-000 | SPACER B, RING GEAR (1.32) | 1 |
| 1 | 41542-HC4-000 | SPACER C, RING GEAR (1.38) | 1 |
| 1 | 41543-HC4-000 | SPACER D, RING GEAR (1.44) | 1 |
| 1 | 41544-HC4-000 | SPACER E, RING GEAR (1.50) | 1 |
| 1 | 41545-HC4-000 | SPACER F, RING GEAR (1.56) | 1 |
| 1 | 41546-HC4-000 | SPACER G, RING GEAR (1.62) | 1 |
| 1 | 41547-HC4-000 | SPACER H, RING GEAR (1.68) | 1 |
| 1 | 41548-HC4-000 | SPACER I, RING GEAR (1.74) | 1 |
| 1 | 41549-HC4-000 | SPACER J, RING GEAR (1.80) | 1 |
| 1 | 41550-HC4-000 | SPACER K, RING GEAR (1.86) | 1 |
| 1 | 42311-HN5-671 | SHAFT, RR. AXLE | 1 |
| 1 | 42311-HN5-672 | SHAFT, RR. AXLE | 1 |
| 1 | 44121-HN4-670 | TUBE, BREATHER (3.5X1100) | 1 |
| 1 | 50355-HN5-670 | PLATE, SKID | 1 |
| 1 | 50356-HM7-300 | RUBBER, STOPPER | 1 |
| 1 | 52112-HA0-000 | STOPPER, L. BEARING | 1 |
| 2 | 90109-371-000 | BOLT, SEALING (8MM) | 2 |
| 6 | 90133-MB0-000 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HA0-000 | BOLT, FLANGE (10X35) | 2 |
| 2 | 90135-HA7-770 | BOLT, STUD (10X22) | 2 |
| 3 | 90190-MG3-000 | BOLT, FLANGE (8X12) | 3 |
| 1 | 90242-MB0-000 | NUT, LOCK (64MM) | 1 |
| 2 | 90471-580-000 | GASKET (8MM) | 2 |
| 1 | 91051-HC4-003 | BEARING, RADIAL BALL (43X68X13) | 1 |
| 1 | 91061-HA7-672 | BEARING, NEEDLE (14X24.5X15) (KOYO) | 1 |
| 1 | 91061-HC4-003 | BEARING, NEEDLE (14X24.5X15) (NTN) | 1 |
| 1 | 91251-HM8-003 | OIL SEAL (34X70X11) | 1 |
| 1 | 91252-HA0-004 | OIL SEAL (35X49X6) (NOK) | 1 |
| 1 | 91271-HC4-004 | OIL SEAL (42X51X7) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 2 | 92900-10028-0E | BOLT, STUD (10X28) | 2 |
| 1 | 95002-35000 | CLIP, TUBE (C6.5) | 1 |
| 1 | 96100-62060-00 | BEARING, RADIAL BALL (6206) | 1 |
| 1 | 96100-60073-00 | BEARING, RADIAL BALL (6007) | 1 |
