Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3FH-24110-00-00 | Fuel Tank | ||
| 1HX-24181-00-00 | Damper, Locating 1 | ||
| 90387-06380-00 | Collar | ||
| 1 | 95811-06080-00 | Bolt, Flange | 1 |
| 1WG-21346-00-00 | Bracket, Tank Ftng | ||
| 4 | 95811-06016-00 | Bolt, Flange | 4 |
| 1WG-21345-00-00 | Bracket, Tank Fitting | ||
| 2 | 95811-08016-00 | Bolt, Flange | 2 |
| 1HX-24182-00-00 | Damper, Locating 2 | ||
| 2 | 90465-13169-00 | Clamp | 2 |
| 1WG-21348-00-00 | Bracket, Tank Fitting | ||
| 2 | 95811-06016-00 | Bolt, Flange | 2 |
| 1WG-24185-00-00 | Damper, Locating 5 | ||
| 3FH-24602-00-00 | Cap Assembly | ||
| 1WG-24500-00-00 | Fuel Cock Assembly 1 | ||
| 1 | 4X8-24534-00-00 | . Seal, Cock | 1 |
| 1 | 4X8-24512-00-00 | . O-Ring | 1 |
| 2 | 98580-03008-00 | . Screw, Pan Head | 2 |
| 1WG-24524-00-00 | Lever, Cock | ||
| 1 | 98606-04016-00 | Screw, Oval Head | 1 |
| 2 | 90202-05187-00 | Washer, Plate | 2 |
| 2 | 90149-06011-00 | Screw | 2 |
| 1 | 1FK-24560-00-00 | Filter Assy | 1 |
| 26H-24568-00-00 | Band, Filter | ||
| 1WG-24566-00-00 | Bracket, Filter | ||
| 1WG-24398-01-00 | Band 1 | ||
| 1WG-24491-01-00 | Bracket, Fuel Pump | ||
| 3 | 98906-05014-00 | Screw, Bind | 3 |
| 1 | 90480-14229-00 | Grommet | 1 |
| 1 | 90387-07391-00 | Collar | 1 |
| 1 | 90179-06500-00 | Nut | 1 |
| 1 | 90480-11454-00 | Grommet | 1 |
| 1WG-24311-00-00 | Pipe, Fuel 1 | ||
| 1WG-24312-00-00 | Pipe 2 | ||
| 2 | 90467-10091-00 | Clip, Scissor | 2 |
| 2 | 90467-11044-00 | Clip | 2 |
| 1WG-W217A-00-0X | Cover, Top SILKY WHITE FINE RED | ||
| 2 | 99224-00040-00 | . Emblem, Yamaha Yamaha (Black | 2 |
| 3FH-24364-00-00 | Stay | ||
| 3BF-24158-00-00 | Stay, Fuel Tank 2 | ||
| 95811-06012-00 | Bolt, Flange | ||
| 2 | 1WG-24183-00-00 | Damper, Locating 3 | 2 |
| 90154-06040-00 | Screw, Binding | ||
| 1WG-24184-00-00 | Damper, Locating 4 | ||
| 1WG-2414H-00-00 | Trim, Cover Panel | ||
| 90387-112R6-00 | Collar | ||
| 90149-06246-00 | Screw, Specl Shape | ||
| 2 | 90480-18495-00 | Grommet | 2 |
| 2 | 90201-06697-00 | Washer, Plate | 2 |
| 2 | 98511-06025-00 | Screw Pan Head | 2 |
| 1WG-24614-00-00 | Plate, Cap | ||
| 3 | 90110-06134-00 | .Bolt, Hexagon Socket Head | 3 |
| 1WG-24665-00-00 | Damper | ||
| 90110-06133-00 | Bolt, Hexagon Socket Head | ||
| 3 | 90201-06067-00 | Washer, Plate | 3 |
| 3 | 95380-06600-00 | Nut, Hexagon | 3 |
| 90110-06132-00 | Bolt, Hex Skt Headsocket Head | ||
| 1WG-2414A-00-00 | Cover, Filler | ||
| 1WG-24622-00-00 | Washer, Ring | ||
| 90560-03220-00 | Spacer | ||
| 1 | 90445-070F1-00 | Hose (L950) | 1 |
| 3FH-24170-00-00 | Canister Assembly | ||
| 1 | 2JU-2419E-00-00 | Cover, Canister | 1 |
| 3FH-24190-00-00 | Canister Holder | ||
| 2 | 98516-05012-00 | Screw, Pan Head | 2 |
| 2 | 92906-05100-00 | Washer, Spring | 2 |
| 2 | 97016-06020-00 | Bolt | 2 |
| 2 | 92906-06100-00 | Washer, Spring | 2 |
| 2 | 90201-06067-00 | Washer, Plate | 2 |
| 2 | 90480-15058-00 | Grommet | 2 |
| 2 | 90387-060E7-00 | Collar | 2 |
| 25H-24180-00-00 | Roll Over Valve Assy | ||
| 1 | 90461-15100-00 | Clamp | 1 |
| 1 | 98580-05010-00 | .Screw, Pan Head | 1 |
| 92901-05600-00 | Washer | ||
| 1 | 3FH-24313-00-00 | Pipe 3 | 1 |
| 6 | 90467-10008-00 | Clip | 6 |
| 90445-11706-00 | Hose (L500) | ||
| 1 | 90445-11501-00 | Hose (L205) | 1 |
| 42H-24119-00-00 | Tube, Connecting | ||
| 1 | 90464-12089-00 | Clamp | 1 |
| 2 | 90467-10008-00 | Clip | 2 |
| 1 | 90445-11735-00 | Hose (L320) | 1 |
| 1WG-13907-00-00 | Fuel Pump Comp | ||
| 1 | 90445-126E7-00 | Hose (L220) | 1 |
| 2 | 90460-12256-00 | Clamp, Hose | 2 |
