Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5AH-14901-01-00 | Carburetor Assy 1 CA (5AHC) | ||
| 4TV-14901-11-00 | Carburetor Assy 1 U49 (5AHB) | ||
| 5AH-14902-01-00 | Carburetor Assy 2 CA (5AHC) | ||
| 4TV-14902-11-00 | Carburetor Assy 2 U49 (5AHB) | ||
| 5AH-14903-01-00 | Carburetor Assy 3 CA (5AHC) | ||
| 4TV-14903-11-00 | Carburetor Assy 3 U49 (5AHB) | ||
| 5AH-14904-01-00 | Carburetor Assy 4 CA (5AHC) | ||
| 4TV-14904-11-00 | Carburetor Assy 4 U49 (5AHB) | ||
| 3 | 4JH-14216-00-00 | . Screw UR 3 | 3 |
| 4 | 4JH-14216-00-00 | . . . Screw UR 1, 2, 4 | 4 |
| 4TV-14933-00-00 | . Spring, Diaphragm | ||
| 4TV-14940-00-00 | . Diaphragm Assy | ||
| 4JH-14515-00-00 | . Jet | ||
| 1 | 4JH-14936-00-00 | . ..Seat, Spring | 1 |
| 1 | 4TV-14916-00-00 | . Needle UR 1, 4 | 1 |
| 1 | 4TV-14916-10-00 | . Needle UR 2, 3 | 1 |
| 4TV-1414G-00-00 | . Pipe, Main Bleed | ||
| 1 | 3TJ-14943-87-00 | . . . Jet, Main (#148) CA (5AHC) | 1 |
| 3TJ-14943-38-00 | . . .Jet, Main (#155) (5AHB) | ||
| 1 | 4JH-14948-02-00 | . Jet (#38) | 1 |
| 1 | 4JH-14105-00-00 | . Pilot Screw Set | 1 |
| 1 | 4JH-14107-00-00 | . Needle Valve Set | 1 |
| 1 | 3TJ-14216-40-00 | . Screw | 1 |
| 4JH-14985-00-00 | . Float | ||
| 1 | 663-14548-00-00 | . Pin, Float Arm | 1 |
| 1 | 98580-04008-00 | . Screw, Pan Head | 1 |
| 1 | 4JH-14984-00-00 | . Gasket, Float Chamber | 1 |
| 1 | 3TJ-14191-40-00 | . .Plug, Drain | 1 |
| 3 | 98580-04014-00 | . Screw, Pan Head UR 2, 3 CA (5AHC) | 3 |
| 4 | 98580-04014-00 | . Screw, Pan Head UR 1, 4 | 4 |
| 4TV-1410A-01-00 | . Starter Set | ||
| 1 | 4MM-14118-00-00 | . Cap | 1 |
| 1 | 4JH-14922-00-00 | Screw, Throttle | 1 |
| 4JH-14934-00-00 | Spring, Throttle Stop | ||
| 1 | 4JH-14429-00-00 | Screw | 1 |
| 4JH-14162-00-00 | Bolt, Holding | ||
| 1 | 4JH-14358-00-00 | .Nut | 1 |
| 8 | 4JH-14325-00-00 | Screw, Pan Head | 8 |
| 3 | 4JH-14121-00-00 | ..Screw, Throttle Stop | 3 |
| 3 | 7A9-14555-00-00 | ..Spring | 3 |
| 3 | 4JH-14133-00-00 | Spring, Throttle Stop | 3 |
| 2 | 4JH-14487-00-00 | .Spring | 2 |
| 6 | 90202-06056-00 | Washer, Plate | 6 |
| 3 | 3TJ-14245-40-00 | Screw, Guide | 3 |
| 1 | 4JH-14565-00-00 | Screw | 1 |
| 1 | 4JH-14264-00-00 | .Collar | 1 |
| 4JH-14935-00-00 | Spring | ||
| 2 | 4JH-14350-00-00 | Pipe Adaptor Assy | 2 |
| 1 | 4JH-13918-00-00 | Pipe T | 1 |
| 2 | 4JH-14197-00-00 | Pipe | 2 |
| 4JH-14294-00-00 | Hose | ||
| 1 | 4JH-14298-00-00 | Pipe | 1 |
| 4JH-14137-00-00 | Clip | ||
| 1 | 4TV-14349-00-00 | Pipe | 1 |
| 4 | 3TJ-14937-40-00 | .Clip | 4 |
| 4TV-1440F-00-00 | Joint, Air Filter 1 | ||
| 4 | 4JH-14561-00-00 | O-Ring | 4 |
| 8 | 4JH-14245-00-00 | Screw, Guide | 8 |
| 8 | 4TV-14561-00-00 | O-Ring | 8 |
| 1 | 4TV-85885-00-00 | Throttle Position Sensor Assy | 1 |
| 1 | 4TV-14562-00-00 | .O-Ring | 1 |
| 4TV-14216-00-00 | Screw | ||
| 1 | 4TV-14534-00-00 | .Collar | 1 |
| 4 | 4TV-12446-00-00 | Joint U49 (5AHB) | 4 |
| 8 | 4TV-12439-00-00 | O-Ring U49 (5AHB) | 8 |
| 4 | 4TV-12573-00-00 | Flange, Hose Joint 1 U49 (5AHB) | 4 |
| 4 | 4TV-14567-00-00 | Screw U49 (5AHB) | 4 |
| 2 | 4TV-12576-00-00 | Hose 1 U49 (5AHB) | 2 |
| 4TV-12577-00-00 | Hose 2 U49 (5AHB) | ||
| 6 | 4TV-12486-00-00 | . Clip U49 (5AHB) | 6 |
| 1 | 4TV-14465-00-00 | Pipe | 1 |
| 2 | 4TV-14557-00-00 | Washer | 2 |
| 4 | 4NC-14561-00-00 | O-Ring CA (5AHC) | 4 |
| 4NC-14568-00-00 | Joint CA (5AHC) | ||
| 4NC-14527-00-00 | Plate CA (5AHC) | ||
| 4NC-14325-00-00 | Screw, Pan Head CA (5AHC) |
