Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705400337 | Front Drive Axle Ass'y 4X4 / Includes 1 to 5 | 1 |
| XXXX | Not Available As Spare Part - Stopper 4X4 | ||
| 703500255 | Rubber Boot Kit 4X4 / Includes 3 to 5 | ||
| 705400148 | Collar 4X4 | ||
| 2 | 293650138 | Oetiker Gear Clamp 44.0MM 4X4 | 2 |
| 1 | 705400149 | Coupling Sleeve 4X4 | 1 |
| 1 | 705400036 | Wear Ring 4X4 | 1 |
| 705400260 | Front Differential Ass'y 4X4 / Includes 8 to 30 | ||
| 1 | 705400027 | Oil Seal 4X4 | 1 |
| 1 | 705500266 | Nut 4X4 | 1 |
| 1 | 705500260 | Ball Bearing 4X4 | 1 |
| 705500268 | GEAR, 10 TEETH 4X4 | ||
| 1 | 705500261 | Needle Bearing 4X4 | 1 |
| 2 | 705500259 | Ball Bearing 4X4 | 2 |
| 2 | 293350044 | Ball Bearing 4X4 | 2 |
| 1 | 705400212 | Differential 4X4 | 1 |
| 1 | 705400192 | GEAR, 36 TEETH 4X4 | 1 |
| 8 | 705400101 | RING GEAR SCREW 4X4 | 8 |
| 6 | 705500264 | Screw 4X4 | 6 |
| 705400133 | Front Cover 4X4 | ||
| 1 | 705500265 | Seal 4X4 | 1 |
| 705400261 | Front Cover 4X4 | ||
| 1 | 705500262 | Vent Valve 4X4 | 1 |
| 1 | 703500288 | Differential Shim Spool Kit 4X4 | 1 |
| 1 | 705500245 | Drain Plug 4X4 | 1 |
| 293250137 | Oil Seal 4X4 | ||
| 1 | 705500269 | RETAINING RING 4X4 | 1 |
| 1 | 705500267 | O-Ring 4X4 | 1 |
| 2 | 705500255 | Oil Seal 4X4 | 2 |
| 1 | 705600311 | CLAMP 4X4 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml 4X4 | 1 |
| 1 | 705500504 | Fill Level Plug 4X4 | 1 |
| 1 | 705500506 | Copper Washer 4X4 | 1 |
| 705400349 | RH CV JOINT 4X4 / Includes 34 to 43 | ||
| 1 | 705400154 | CV JOINT 4X4 | 1 |
| 1 | 705400127 | Boot Wheel Kit 4X4 / Includes 36 to 38 | 1 |
| 1 | 705400064 | CLAMP 4X4 | 1 |
| 705400180 | Clamp 4X4 | ||
| 1 | 705400126 | Boot Differential Kit 4X4 / Includes 39 to 41 | 1 |
| 2 | 705400064 | CLAMP 4X4 | 2 |
| 705400181 | Clamp 4X4 | ||
| 1 | 705400156 | RH PLUNGING JOINT 4X4 | 1 |
| 1 | 705400042 | CIRCLIP 4X4 | 1 |
| 705400361 | Shaft Stub 2X4 | ||
| 1 | 709400132 | LH KNUCKLE 4X4 | 1 |
| 709400182 | LH Knuckle 2X4 | ||
| 1 | 709400133 | RH KNUCKLE 4X4 | 1 |
| 1 | 709400184 | RH KNUCKLE 2X4 | 1 |
| 705400350 | LH CV Joint 4X4 / Includes 46 to 55 | ||
| 1 | 705400127 | Boot Wheel Kit 4X4 / Includes 48 to 50 | 1 |
| 1 | 705400126 | Boot Differential Kit 4X4 / Includes 51 to 53 | 1 |
| 1 | 705400155 | PLUNGING JOINT 4X4 | 1 |
| 2 | 705400187 | COVER 2X4 | 2 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 230602546 | Hex. Flange Screw M10 X 125 4X4 | 2 |
| 2 | 233201416 | Hex. Flange Elastic Nut M10 4X4 | 2 |
| 2 | 705500372 | Wear Sleeve 2X4 | 2 |
| 2 | 705500564 | Wear Sleeve 4X4 | 2 |
| 2 | 705400286 | Wheel Hub Ass'y 2X4 / Includes 63 to 64 | 2 |
| 4 | 250300020 | Wheel Stud 2X4 | 4 |
| 705500596 | WHEEL HUB ASS'Y 4X4 / Includes 65 to 66 | ||
| 4 | 250300020 | Wheel Stud 4X4 | 4 |
| 2 | 250200049 | Spring Washer | 2 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 250400016 | Cotter Pin | 2 |
| 1 | 705400066 | Rubber Bellow 4X4 | 1 |
| 1 | 293750001 | Tie Wrap 94 mm 4X4 | 1 |
| 705400012 | WHEEL CAP | ||
| 705400213 | Front Tire Outlander XT | ||
| 705400243 | FRONT RIM Outlander STD & XT (Camo) | ||
| 705400355 | RIM_12 INCH X 6 Outlander STD & XT | ||
| 1 | 705400193 | Rim Valve With Cap | 1 |
| 8 | 250100042 | Steel Wheel Nut | 8 |
| 2 | 293250090 | Oil Seal 4X4 | 2 |
| 2 | 705400179 | WEAR SLEEVE 4X4 | 2 |
| 1 | 250200014 | Flat Washer M10 4X4 | 1 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip 4X4 | 1 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz 4X4 | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| XXXX | Not Available As Spare Part - Shifting Unit Ass'y 4X4 / Includes 83 to 101 | ||
| 705400169 | HOUSING 4X4 | ||
| 1 | 705400252 | Actuator 4X4 / Includes 85 to 88 | 1 |
| 1 | 705400274 | Fork 4X4 | 1 |
| 1 | 293370042 | Circlip 4X4 | 1 |
| 293300108 | O-Ring 4X4 | ||
| 3 | 250000137 | Hex. Flange Screw M8 X 20, Scotch Grip 4X4 | 3 |
| 1 | 705400172 | Union Shaft 4X4 | 1 |
| 1 | 206580890 | Pressure Screw M8 X 8 4X4 | 1 |
| 1 | 250400025 | Dowell Pin 4X4 | 1 |
| 1 | 705400249 | Ball Bearing 4X4 | 1 |
| 1 | 705400175 | Slider 4X4 | 1 |
| 1 | 293370029 | Circlip 4X4 | 1 |
| 1 | 293370030 | Circlip 4X4 | 1 |
| 1 | 710000324 | SWITCH 4X4 | 1 |
| 1 | 705400389 | Coupling Sleeve 4X4 | 1 |
| 1 | 293250138 | Oil Seal 4X4 | 1 |
| 1 | 705400387 | Shifter Plate 4X4 | 1 |
| 1 | 705600310 | Copper Washer 4X4 | 1 |
| 1 | 705400186 | COVER 2X4 | 1 |
| 3 | 250000136 | Socket Head Screw M8 X 20, Scotch Grip | 3 |
| 1 | 293300091 | O-Ring | 1 |
