Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5EL-14900-21-00 | CARBURETOR ASSY P 49 (5PB8) | ||
| 5EL-14900-31-00 | CARBURETOR ASSY PC CA (5PB9) | ||
| 5EL-14901-21-00 | CARBURETOR ASSY 1 (1) REAR P 49 (5PB8) | ||
| 5EL-14901-31-00 | CARBURETOR ASSY 1 (1) REAR PC CA (5PB9) | ||
| 5EL-14902-21-00 | CARBURETOR ASSY 2 (2) FRONT P 49 (5PB8) | ||
| 5EL-14902-31-00 | CARBURETOR ASSY 2 (2) FRONT PC CA (5PB9) | ||
| 1 | 5EL-14112-00-00 | VALVE, THROTTLE 1 | 1 |
| 1 | 5EL-1490J-20-00 | NEEDLE SET | 1 |
| 1 | 5EL-14107-12-00 | NEEDLE VALVE SET | 1 |
| 1 | 127-14186-00-00 | PIN, FLOAT | 1 |
| 1 | 3G2-14231-22-00 | JET, MAIN (#110) UR (1) REAR | 1 |
| 1 | 3G2-1423A-73-00 | JET, MAIN (#112.5) UR (2) FRONT | 1 |
| 1 | 583-14561-00-00 | O-RING | 1 |
| 1 | 5EL-14261-00-00 | HOLDER | 1 |
| 1 | 5DM-14561-00-00 | O-RING | 1 |
| 1 | 5EL-24411-00-00 | DIAPHRAGM | 1 |
| 1 | 4KM-14933-00-00 | SPRING, DIAPHRAGM | 1 |
| 1 | 4SV-14105-00-00 | PILOT SCREW SET | 1 |
| 1 | 90157-05M19-00 | SCREW, PAN HEAD (1) REAR | 1 |
| 1 | 1HX-14231-29-00 | JET, MAIN (#145) | 1 |
| 1 | 5EL-1410A-00-00 | STARTER SET | 1 |
| 1 | 4KM-14142-17-00 | JET, PILOT (# 17.5) | 1 |
| 1 | 5EL-14918-00-00 | RING | 1 |
| 1 | 3G2-1423A-59-00 | JET, MAIN (# 42.5) | 1 |
| 1 | 1HX-1423E-25-00 | JET, MAIN (#63.8) | 1 |
| 1 | 4KM-14194-00-00 | RING (1) REAR | 1 |
| 1 | 354-14147-00-00 | O-RING | 1 |
| 1 | 98517-04012-00 | SCREW,PANHEAD (2) FRONT | 1 |
| 1 | 5EL-14919-00-00 | CLIP (2) FRONT | 1 |
| 1 | 5DM-14985-00-00 | FLOAT | 1 |
| 1 | 98507-04008-00 | SCREW, PAN HEAD | 1 |
| 1 | 1FN-14565-00-00 | SCREW | 1 |
| 2 | 98507-04014-00 | SCREW, PAN HEAD | 2 |
| 2 | 92907-04100-00 | WASHER, SPRING | 2 |
| 1 | 5EL-1490H-00-00 | DIAPHRAGM SET 5 | 1 |
| 1 | 5DM-14141-40-00 | NOZZLE, MAIN | 1 |
| 1 | 4KM-14216-00-00 | SCREW UR (1) REAR | 1 |
| 2 | 4KM-14216-00-00 | SCREW UR (2) FRONT | 2 |
| 3 | 98507-04010-00 | SCREW, PAN HEAD UR (2) FRONT | 3 |
| 4 | 98507-04010-00 | SCREW, PAN HEAD UR (1) REAR | 4 |
| 1 | 12R-14191-00-00 | PLUG, DRAIN | 1 |
| 1 | 5EL-14561-00-00 | O-RING | 1 |
| 1 | 3F9-14118-00-00 | CAP | 1 |
| 2 | 3LN-1416A-00-00 | O-RING | 2 |
| 2 | 4SV-24453-00-00 | SCREW | 2 |
| 2 | 5EL-14935-00-00 | SPRING | 2 |
| 2 | 92990-05100-00 | WASHER, SPRING | 2 |
| 2 | 95317-05700-00 | NUT, HEXAGON SMALL | 2 |
| 2 | 11H-14991-00-00 | SCREW | 2 |
| 31H-14194-00-00 | RING | ||
| 5EL-14577-00-00 | ROD | ||
| 1 | 4YW-14987-00-00 | HOSE P 49 (5PB8) | 1 |
| 0 | 5EL-14987-10-00 | HOSE PC CA (5PB9) | 0 |
| 2 | 4WM-14565-00-00 | SCREW | 2 |
| 1 | 5EL-85885-00-00 | THROTTLE SENSOR ASSY | 1 |
| 5EL-14592-00-00 | SCREW | ||
| 4NK-14285-00-00 | WASHER | ||
| 5EL-81517-00-00 | WIRE, SUB LEAD | ||
| 2 | 5EL-14987-00-00 | HOSE | 2 |
| 5EL-14991-00-00 | SCREW | ||
| 1 | 22F-14117-00-00 | WASHER, PLUG SCREW | 1 |
| 1 | 5EL-14212-00-00 | SPRING, PILOT ADJUSTING | 1 |
| 3F7-14133-00-00 | SPRING, THROTTLE STOP | ||
| 98517-04006-00 | SCREW, PAN HEAD | ||
| 3XV-14243-00-00 | CLAMP | ||
| 0 | 127-14198-00-00 | GASKET PC CA (5PB9) | 0 |
| 2 | 127-14198-00-00 | GASKET P 49 (5PB8) | 2 |
| 0 | 3DM-14216-00-00 | SCREW PC CA (5PB9) | 0 |
| 2 | 3DM-14216-00-00 | SCREW P 49 (5PB8) | 2 |
| 2 | 5EL-14197-00-00 | PIPE | 2 |
| 1 | 4DH-82103-00-00 | TERMINAL 1 | 1 |
| 1 | 1A8-14953-00-00 | WASHER | 1 |
| 1 | 812-14137-00-00 | CLIP | 1 |
| 2 | 5FU-83790-20-00 | HEATER ASSY (30W) | 2 |
| 2 | 90201-08016-00 | WASHER, PLATE | 2 |
| 2 | 35H-14139-00-00 | CLIP, PIPE | 2 |
| 4 | 91492-10008-00 | PIN, COTTER | 4 |
| 92909-06100-00 | WASHER, SPRING | ||
| 1 | 95317-06700-00 | NUT, HEX | 1 |
| 5EL-14149-00-00 | PIPE | ||
| 1 | 5EL-14103-00-00 | THROTTLE SCREW SET | 1 |
| 5EL-14251-00-00 | NIPPLE | ||
| 1 | 98507-04010-00 | SCREW, PAN HEAD | 1 |
| 1 | 92990-06600-00 | WASHER, PLAIN (646) | 1 |
| 90201-05328-00 | WASHER, PLATE PC CA (5PB9) | ||
| 5EL-14592-10-00 | SCREW PC CA (5PB9) | ||
| 0 | 4X7-2149Y-00-00 | FILTER ASSY PC CA (5PB9) | 0 |
| 0 | 8A7-14139-00-00 | CLIP, PIPE PC CA (5PB9) | 0 |
| 0 | 895-14169-00-00 | CAP PC CA (5PB9) | 0 |
| 0 | 5EL-14987-20-00 | HOSE PC CA (5PB9) | 0 |
