Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 703500007 | Rear Propeller Shaft Ass'y | ||
| 2 | 705400036 | Wear Ring | 2 |
| 705500097 | Sealing Ring | ||
| 705500098 | Lock Spring | ||
| 1 | 705400034 | Retainer Screw | 1 |
| 1 | 705400033 | Washer | 1 |
| XXXX | Not Available As Spare Part - Coupler | ||
| 1 | 703500002 | Unit Pack Kit | 1 |
| 205502544 | Socket Head Screw M10 x 25 (Scotch Grip) | ||
| 705500106 | Vent Hose | ||
| 1 | 414227300 | Clip | 1 |
| 1 | 414554800 | Spring Clamp | 1 |
| 705400012 | WHEEL CAP | ||
| 705500004 | Rear Tire | ||
| 705500005 | Rear Rim | ||
| 705400013 | HEX. NUT | ||
| 1 | 211200041 | Washer | 1 |
| 1 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip | 1 |
| 2 | 705400053 | Rim valve | 2 |
| 1 | 293550019 | Grease, 60 G | 1 |
| 705500003 | Rigid Axle Ass'y Includes 21 - 47. | ||
| 703500033 | Differential (Central) Includes 21 - 43. | ||
| 2 | 705500081 | Oil Seal | 2 |
| 705500092 | Filler/Level Plug 7400/7401. | ||
| 705500143 | Filler/Level Plug 7413/7414. 7415/7416. 7417/7418. | ||
| 705500093 | Drain Plug | ||
| 705500011 | Spool Propul | ||
| 705500013 | Differential Cap | ||
| 705500014 | Differential Carrier | ||
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705500076 | GEAR (10 TEETH) | 1 |
| 2 | 705500080 | Ball Bearing | 2 |
| 705500074 | Ball Bearing | ||
| 705500077 | Needle Bearing | ||
| 705500124 | Vent Valve | ||
| 2 | 705500078 | O RING | 2 |
| 8 | 705500088 | SCREW | 8 |
| 705500091 | Seal | ||
| 8 | 705500090 | RING GEAR SCREW | 8 |
| 1 | 705500072 | Nut | 1 |
| 705500087 | Gear (36 Teeth) | ||
| 705500073 | O-Ring | ||
| 705500102 | Retaining Ring | ||
| 705500075 | Pinion Gear Shim .022" | ||
| 2 | 705500079 | Differential Shim .022" | 2 |
| 703500034 | RH Tube Kit (7419 to 7422) Includes 44 - 49. | ||
| 705500084 | Ball Bearing | ||
| 705500085 | Retaining Ring | ||
| 705500086 | Screw, Axle Tube (7419 to 7422) | ||
| 705500082 | Axle Tube RH (7419 to 7422) | ||
| 1 | 705500099 | OIL SEAL | 1 |
| 703500035 | LH Tube Kit | ||
| 705500089 | Axle Tube L.H | ||
| 2 | 232291413 | Hex. Flange Castellated Nut M18 | 2 |
| 2 | 211400012 | Cotter pin | 2 |
| 705500006 | Rear Wheel Hub Ass'y Includes 58 - 9. | ||
| 705500100 | WEAR RING | ||
| 705600033 | Brake Disk 220 mm (Rear) | ||
| 205881646 | Socket Screw M8 x 16 (S. Grip) | ||
| 705500006 | Rear Wheel Hub Ass'y Includes 62 - 63. | ||
| 211200049 | Washer | ||
| 703500023 | Swing Arm Kit | ||
| 4 | 233201414 | Hex. Flange Elastic Nut M10 | 4 |
| 705500049 | RH Axle Ass'y | ||
| 705500050 | LH Axle Ass'y | ||
| 293300052 | O-Ring | ||
| 1 | 293800053 | Sealant Right Stuff 26015, 7 oz | 1 |
| 4 | 207602544 | Hex. Flange Screw M10 X 25 | 4 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz (12 x 6 oz) | 1 |
| 705000019 | Rear Differential Protector | ||
| 4 | 207581046 | Flange Screw M8 x 10, Scotch Grip | 4 |
