Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 703500001 | Front Propeller Shaft Kit | ||
| 2 | 705400036 | Wear Ring | 2 |
| 705400051 | PROTECTOR | ||
| 2 | 703500002 | Unit Pack Kit | 2 |
| 705400003 | Front Differential Ass'y Includes 5 - 5. | ||
| 1 | 705400027 | Oil Seal | 1 |
| 705400004 | DIFFERENTIAL | ||
| 705400019 | OIL SEAL | ||
| 2 | 705500081 | Oil Seal | 2 |
| 705500093 | Drain Plug | ||
| 705500092 | Filler/Level Plug 7400/7401. | ||
| 705500143 | Filler/Level Plug 7413/7414. 7415/7416. 7417/7418. | ||
| 705400025 | Differential Cap | ||
| 705400026 | Differential Carrier | ||
| 2 | 705500080 | Ball Bearing | 2 |
| 705500074 | Ball Bearing | ||
| 705500077 | Needle Bearing | ||
| 705500124 | Vent Valve | ||
| 8 | 705500088 | SCREW | 8 |
| 705500091 | Seal | ||
| 8 | 705500090 | RING GEAR SCREW | 8 |
| 1 | 705500072 | Nut | 1 |
| 705500087 | Gear (36 Teeth) | ||
| 705500073 | O-Ring | ||
| 1 | 705500076 | GEAR (10 TEETH) | 1 |
| 705500102 | Retaining Ring | ||
| 703500040 | Knuckle Kit R.H Includes 26 - 34. | ||
| 703500041 | Knuckle Kit L.H | ||
| 2 | 706200024 | Ball Joint | 2 |
| 705400006 | ANGLE BEARING (7431 _ 7434) | ||
| 2 | 293250090 | Oil Seal | 2 |
| 293370003 | CIRCLIP (7431 _ 7434) | ||
| 705600003 | Brake Disk (Front) (7431 @ 7434) | ||
| 8 | 235381646 | Torx Screw M8 X 16, Scotch Grip | 8 |
| 705400011 | Front Wheel Hub(7431 @ 7434) | ||
| 293250098 | Oil Seal (7431 @ 7434) | ||
| 2 | 293370009 | Circlip 32 mm | 2 |
| 1 | 207606044 | Hex. Flange Screw M10 X 60 7400/7401. | 1 |
| 1 | 207506044 | HEX. FLANGED SCREW M10 X 60, SCOTCH GRIP 7413/7414. 7415/7416. 7417/7418. | 1 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 7400/7401. | 2 |
| 2 | 233101414 | Hex. Flange Nut M10 7413/7414. 7415/7416. 7417/7418. | 2 |
| 705400052 | Bracket, differential | ||
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 293300052 | O-Ring | ||
| 211200049 | Washer | ||
| 2 | 232291413 | Hex. Flange Castellated Nut M18 | 2 |
| 2 | 211400012 | Cotter pin | 2 |
| 1 | 219704414 | Was 415110000 Polyurethane Hose 5.2 mm | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 414554800 | Spring Clamp | 1 |
| 705400012 | WHEEL CAP | ||
| 2 | 705400009 | Front Tire | 2 |
| 705400010 | Front Rim | ||
| 2 | 705400053 | Rim valve | 2 |
| 705400013 | HEX. NUT | ||
| 1 | 211200041 | Washer | 1 |
| 1 | 207581646 | Hex. Flange Screw M8 X 16, Scotch Grip | 1 |
| 1 | 705400033 | Washer | 1 |
| 1 | 705400034 | Retainer Screw | 1 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | 1 |
| 293550018 | Therma Lube Grease, 300 ml | ||
| 250200003 | Flat Washer | ||
| 705400020 | Bracket | ||
| 211000163 | Hex. Flange Screw M10 x 200 7400/7401. | ||
| 250000024 | Flange Screw M10 X 200, Scotch Grip 7413/7414. 7415/7416. 7417/7418. | ||
| 703500021 | RH CV Joint (7431 @ 7434) Includes 62 - 67. | ||
| 703500022 | LH CV Joint(7431 @ 7434) | ||
| 1 | 705400038 | WHEEL BOOT KIT | 1 |
| 705400039 | DIFFERENTIAL BOOT KIT | ||
| 705400040 | RH Plunging Joint | ||
| 705400041 | LH Plunging Joint | ||
| 1 | 705400042 | CIRCLIP | 1 |
| 705400016 | Wear Ring | ||
| 705400037 | CV JOINT (7431 _ 7434) |
