Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705000017 | RH Footboard, Black | ||
| 1 | 705000018 | LH FOOTBOARD, BLACK | 1 |
| 3 | 293730011 | Black, Dart | 3 |
| 705000029 | Foot Peg | ||
| 2 | 415018100 | Rubber Stopper | 2 |
| 2 | 390400700 | Pop Rivet 1/8", Black | 2 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 703500009 | Front Fender Kit Includes 8 - 12. 7400/7401. 7413/7414. 7415/7416. | ||
| 703500051 | Front Fender Kit (Green) 7417/7418. | ||
| 704900034 | Warning Label Includes 9 - 10. | ||
| XXXX | Not Available As Spare Part - Warning Label (Injuries/Death) | ||
| XXXX | Not Available As Spare Part - Warning Label (16 Years) | ||
| 1 | 704900007 | Caution Decal, Transmission Selector | 1 |
| 704900028 | RH Rear Label (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900068 | Front Label RH 7417/7418. | ||
| 8 | 211000123 | Phillips Screw M6 X 20 | 8 |
| 8 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 8 |
| 703500010 | Rear Fender Kit Includes 15 - 20. 7400/7401. 7413/7414. 7415/7416. | ||
| 703500052 | Rear Fender Kit(Green) 7417/7418. | ||
| 704900035 | Warning Label Includes 16 - 17. | ||
| XXXX | Not Available As Spare Part - Warning Label (Passenger) | ||
| XXXX | Not Available As Spare Part - Tire Pressure Warning Label | ||
| 704900020 | RH Rear Fender <<ROTAX>> Decal (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900063 | Rotax Label 7417/7418. | ||
| 704900022 | LH Lateral Label (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900065 | Lateral Label LH 7417/7418. | ||
| 704900023 | RH Lateral Label (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900066 | Lateral Label RH 7417/7418. | ||
| 704900029 | RH Fender Decal (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900062 | RH Fender Decal (Green) 7417/7418. | ||
| 704900030 | LH Fender Decal (Red) 7400/7401. 7413/7414. 7415/7416. | ||
| 704900064 | LH Fender Decal (Green) 7417/7418. | ||
| 1 | 207661244 | Hex. Flange Screw M6 X 12 | 1 |
| 703500011 | Front Fascia Ass'y, black Includes 22 - 23. | ||
| 1 | 704900027 | Bombardier Logo 7400/7401. 7413/7414. | 1 |
| 1 | 704900087 | Bombardier Logo 7415/7416. 7417/7418. | 1 |
| 211000121 | TRUSS PHILLIPS SCREW M6 X 16 | ||
| 4 | 224060201 | Flat Washer | 4 |
| 1 | 703500012 | REAR FASCIA ASS'Y, BLACK Includes 28 - 29. | 1 |
| 705000077 | Rear Reflector Band (Red) R.H 7400/7401. 7413/7414. | ||
| 705000085 | Rear Reflector Band (Red) R.H 7415/7416. 7417/7418. | ||
| 705000027 | Rear Reflector Band (Red) L.H 7400/7401. 7413/7414. | ||
| 705000086 | RH Foot Protector 7415/7416. 7417/7418. | ||
| 6 | 224060201 | Flat Washer | 6 |
| 705000010 | Tank Cover | ||
| 16 | 570023800 | Windshield Latch | 16 |
| 703500014 | LH Front Mudguard Kit Includes 35 - 36. | ||
| 703500015 | RH Front Mudguard Kit | ||
| 1 | 705000083 | LH FRONT REFLECTOR | 1 |
| 705000026 | RH FRONT REFLECTOR | ||
| 32 | 207162044 | Hex. Screw M6 X 20 | 32 |
| 32 | 224060201 | Flat Washer | 32 |
| 32 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 32 |
| 703500016 | LH Rear Mudguard Includes 40 - 41. | ||
| 703500017 | RH Rear Mudguard | ||
| 704900026 | Bombardier label 7400/7401. 7413/7414. | ||
| 704900076 | Bombardier Label 7415/7416. 7417/7418. | ||
| 705000020 | Protector L.H | ||
| 705000137 | Protector R.H | ||
| 6 | 210261680 | Hex. Flange Screw M6 X 16 | 6 |
| 705000025 | Protection Plate | ||
| 2 | 207602544 | Hex. Flange Screw M10 X 25 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 705000072 | Fender Cover (Green) | ||
| 705000028 | Fender Cover (Red) | ||
| 705000082 | Plate Ass'y Includes 48 - 50. 7400/7401. | ||
| 705000138 | Plate Ass'y 7413/7414. 7415/7416. 7417/7418. | ||
| 293830068 | Rubber Protector | ||
| 293830079 | Rubber Protector | ||
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 705000046 | Grill L.H 7400/7401. 7415/7416. | ||
| 705000073 | Grill LH (Green) 7413/7414. 7417/7418. | ||
| 705000047 | Grill R.H 7400/7401. 7415/7416. | ||
| 705000074 | Grill RH (Green) 7413/7414. 7417/7418. | ||
| 6 | 250100000 | PUSH NUT | 6 |
| 705000076 | Cap Cover 7400/7401. 7413/7414. | ||
| 1 | 705000132 | COVER, BLACK 7415/7416. 7417/7418. | 1 |
| 705000081 | Lever Indicator | ||
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 570277400 | Bottom Pan Cap | ||
| 570041600 | Rubber Cover | ||
| 6 | 224061201 | Flat Washer | 6 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 732600009 | PAN HEAD FORMING SCREW M6 X 18 |
