Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 707000041 | Rotax 4 Strokes Engine «511» Includes 1 - 7. | ||
| 2 | 707000008 | Spark Plug NGK DR8EA | 2 |
| 707000031 | Adaptor Ass'y Includes 3 - 7. | ||
| 1 | 270000137 | Female Connector, 6 Circuits | 1 |
| XXXX | Not Available As Spare Part - Adaptor | ||
| 293300033 | Gasket | ||
| 293200055` | Gasket | ||
| 707000094 | Anti-Vibration Mount | ||
| 707000019 | ENGINE SUPPORT BUSHING | ||
| 707000030 | Support Bushing Includes 10 - 11. | ||
| 2 | 707000004 | RH LOWER BUSHING | 2 |
| 707000082 | Front Engine Bracket, Black | ||
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 705200197 | Engine Bracket | ||
| 1 | 230604044 | Hex. Flange Screw M10 X 140 | 1 |
| 2 | 207609544 | HEX. FLANGED SCREW M10 X 95 | 2 |
| 3 | 233201414 | Hex. Flange Elastic Nut M10 | 3 |
| 5 | 207682044 | Hex. Flange Screw M8 X 20 | 5 |
| 5 | 233281414 | Hex. Flange Elastic Nut M8 | 5 |
| 1 | 705600232 | Hose Retainer 13 mm | 1 |
| 707000351 | Throttle Handle | ||
| 3 | 205052588 | Socket Head Screw M5 X 25 | 3 |
| 707000313 | THROTTLE CABLE | ||
| 293600041 | CABLE LUBRICANT, 400 G | ||
| 707000247 | CARBURATOR ADAPTOR | ||
| 293650157 | Gemi Clamp | ||
| 707000366 | Carburator Ass'y | ||
| 1 | 275500398 | Check Valve | 1 |
| 1 | 413708300 | Glue Tube, Loctite 454, 20 G | 1 |
| 293650156 | Gemi Clamp | ||
| 707000264 | CHOKE CABLE | ||
| 1 | 707000067 | D SHAPE WASHER | 1 |
| 1 | 707000087 | HOLDER CAP | 1 |
| 707000088 | Rubber Cap | ||
| 1 | 707000089 | BUTTON | 1 |
| 250000108 | PHILLIPS SCREW M3 X 5 | ||
| 1 | 293300075 | O-RING | 1 |
| 2 | 414115200 | Tie-Rap 180 mm | 2 |
| 1 | 707000010 | LEVER ASS'Y | 1 |
| 705500022 | LEVER BUTTON | ||
| 1 | 219704458 | Was 293800041 Loctite Primer 7649 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 705500150 | BUSHING | 1 |
| 705500193 | Adjuster Bushing | ||
| 1 | 705500024 | LEVER SPRING | 1 |
| 1 | 207685044 | Hex. Flange Screw M8 X 50 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 705500358 | Upper Tube, Black | ||
| 705500135 | Lower Tube | ||
| 1 | 207663544 | Hex. Flange Screw M6 X 35 | 1 |
| 3 | 705500041 | RETAINER CLAMP | 3 |
| 707000080 | Shim 1.0 mm | ||
| 707000081 | Shim 2.0 mm | ||
| 6 | 705500033 | Half Ring | 6 |
| 4 | 207661644 | Hex. Flange Screw M6 X 16 | 4 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 7 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 7 |
| 707000068 | Tie Rod Ass'y | ||
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 707200159 | Carburator Support | ||
| 1 | 293720053 | Grommet | 1 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 207341644 | Hex. Screw M4 X 16, Scotch Grip | ||
| 707000181 | Spacer |
