Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Gear Housing Ass'y Includes 1 To 6 (See Item 58, Gear Box) | ||
| 2 | 420632010 | Center Pin 8 X 12 | 2 |
| XXXX | Not Available As Spare Part - Dowel | ||
| 1 | 420932815 | Ball Bearing 6303E | 1 |
| 1 | 420932433 | Ball Bearing 6204 | 1 |
| 2 | 420250450 | Oil Seal Included In Gasket Kit | 2 |
| 1 | 420641188 | Torx Flange Screw M8 X 35 Tightening Torque 25 Nm +/- 12% | 1 |
| 1 | 420227937 | Plain Washer | 1 |
| 1 | 420620929 | Shift Shaft Ass'y Includes 9a To 12 | 1 |
| XXXX | Not Available As Spare Part - Intermediate Gear (30 T) | ||
| XXXX | Not Available As Spare Part - Shift Shaft | ||
| XXXX | Not Available As Spare Part - Spring | ||
| XXXX | Not Available As Spare Part - Tooth Segment Ass'y | ||
| 1 | 420657235 | Shifting Drum Ass'y Includes 13 To 20 | 1 |
| XXXX | Not Available As Spare Part - Needle Pin | ||
| XXXX | Not Available As Spare Part - Compression Spring | ||
| XXXX | Not Available As Spare Part - Gear Shifting Gate | ||
| XXXX | Not Available As Spare Part - Snap Ring RETRY TORQUE 11 NM +/- 12% | ||
| XXXX | Not Available As Spare Part - Disengagement Gate | ||
| XXXX | Not Available As Spare Part - Thrust Washer | ||
| XXXX | Not Available As Spare Part - Index Washer | ||
| 1 | 420241939 | Allen Screw M6 X 20 Tightening Torque 10 Nm +/- 12% | 1 |
| 1 | 420620677 | Countershaft | 1 |
| 1 | 420831955 | Oil Seal Included In Gasket Kit | 1 |
| XXXX | Not Available As Spare Part - Ball Bearing | ||
| XXXX | Not Available As Spare Part - Bevel Gear Set | ||
| XXXX | Not Available As Spare Part - Groove Nut M32 Tightening Torque 170 Nm +/- 6% | ||
| XXXX | Not Available As Spare Part - Shim Set | ||
| XXXX | Not Available As Spare Part - Angular Ring | ||
| XXXX | Not Available As Spare Part - Half Ring | ||
| 420257676 | Shifting Sleeve Kit Includes 32 To 35 | ||
| XXXX | Not Available As Spare Part - Shifting Fork | ||
| XXXX | Not Available As Spare Part - Neelde Pin | ||
| 1 | 420841771 | SET SCREW M6 X 8 Tightening Torque 6 Nm +/- 12% | 1 |
| 2 | 420641228 | Torx Flange Screw M6 X 85 Tightening Torque 10 Nm +/- 12% | 2 |
| 5 | 420641213 | Torx Flange Screw M8 X 55 Tightening Torque 25 Nm +/- 12% | 5 |
| 8 | 420440274 | Torx Flange Screw M6 X 35 Tightening Torque 10 Nm +/- 12% | 8 |
| 2 | 420440702 | Torx Flange Screw M6 X 55 Tightening Torque 10 Nm +/- 12% | 2 |
| 1 | 420266168 | Angle Rotation Sensor | 1 |
| 2 | 420641048 | Torx Flange Screw M6 X 16 Tightening Torque 10 Nm +/- 12% | 2 |
| 1 | 420265626 | Speed Sensor | 1 |
| 1 | 420641048 | Torx Flange Screw M6 X 16 Tightening Torque 10 Nm +/- 12% | 1 |
| 1 | 420650350 | O-Ring Included In Gasket Kit | 1 |
| 1 | 420241660 | Plug Screw M14 X 1.5 Tightening Torque 5 Nm +/- 12% | 1 |
| 1 | 420250640 | Copper Washer Included In Gasket Kit | 1 |
| 1 | 420241786 | Magnetic Drain Plug Tightening Torque 20 Nm +/- 12% | 1 |
| 1 | 420640192 | Contact Screw M10 Ass'y With Cable Tightening Torque 3 Nm +/- 12% | 1 |
| 1 | 415129174 | Actuator Ass'y Includes 49 To 52 | 1 |
| 1 | 293300117 | O-Ring | 1 |
| 1 | 415129175 | Shifting Fork | 1 |
| 1 | 293370042 | Circlip | 1 |
| 3 | 420250311 | Flat Washer 8.4 mm | 3 |
| 3 | 420440372 | Torx Flange Screw M8 X 25 Tightening Torque 25 Nm +/- 12% | 3 |
| 4 | 420842619 | Hex. Nut M8 Tightening Torque 25 Nm +/- 12% | 4 |
| 1 | 420251691 | Cable Clamp | 1 |
| 1 | 420684149 | Gasket Set | 1 |
| 1 | 420685807 | Gear Box | 1 |
| XXXX | Not Available As Spare Part - Loctite 243 | ||
| XXXX | Not Available As Spare Part - Loctite 648 | ||
| XXXX | Not Available As Spare Part - Multi Purpose Grease | ||
| XXXX | Not Available As Spare Part - Engine Oil | ||
| XXXX | Not Available As Spare Part - Loctite 5910 | ||
| XXXX | Not Available As Spare Part - Copaslip | ||
| XXXX | Not Available As Spare Part - Petamo Grease | ||
| XXXX | Not Available As Spare Part - Loctite 5331 |
