Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 98580-04008-00 | . .Screw, Pan Head USED ON ALL 211-23100-XX REF 0GRID D-10 | 2 |
| 211-23100-00-29 | Front Fork Assembly | ||
| 211-23100-40-33 | Front Fork Assembly | ||
| 211-23100-40-63 | Front Fork Assembly | ||
| 168-23136-01-00 | Tube, Outer 2 | ||
| 168-23126-01-00 | Tube, Outer 1 | ||
| 156-23147-00-00 | . O-Ring | ||
| 168-23125-01-00 | Metal, Slide 1 | ||
| 168-23124-01-00 | Tube, Inner 1 | ||
| 211-23150-00-00 | Outer Nut | ||
| 211-23150-40-00 | Outer Nut | ||
| 2 | 278-23145-51-00 | . Oil Seal | 2 |
| 168-23146-00-00 | Washer, Oil Seal | ||
| 168-23143-00-00 | Seat, Spring Lower | ||
| 211-23141-00-00 | Spring, Front Fork | ||
| 168-23142-01-00 | Seat, Spring Upper | ||
| 211-23142-40-00 | Seat, Spring Upper | ||
| 168-23149-00-00 | Washer, Spring Upr | ||
| 168-23123-01-29 | Cover, Lower 1 CANDY BLUE | ||
| 168-23123-01-63 | Cover, Lower 1 BRILLIANT RED | ||
| 211-23122-40-00 | Cover, Outer 1 | ||
| 168-23123-01-81 | Cover, Lower 1 PRIMER | ||
| 168-23163-01-00 | Gasket | ||
| 168-23116-01-00 | Guide, Cover Lower | ||
| 211-23121-00-63 | Cover, Upper 1 BRILLIANT RED | ||
| 211-23121-00-81 | Cover, Upper 1 PRIMER | ||
| 211-23131-00-81 | Cover, Upper 2 PRIMER | ||
| 211-23131-00-81 | Cover, Upper 2 CANDY BLUE | ||
| 211-23131-00-63 | Cover, Upper 2 BRILLIANT RED | ||
| 168-23115-00-00 | . Guide, Cover Upper | ||
| 168-23114-01-00 | Gasket | ||
| 156-23112-00-00 | Washer, Cap | ||
| 156-23111-01-00 | Bolt, Cap | ||
| 168-23340-00-33 | Under Bracket | ||
| 2 | 92990-10100-00 | . Washer, Spring | 2 |
| 122-23460-10-0 | . Unavailable In Price Book | ||
| 1 | 92990-08100-00 | . Washer, Spring | 1 |
| 2 | 92990-08100-00 | . Washer, Spring | 2 |
| 1 | 97313-08030-00 | . Bolt | 1 |
| 2 | 97313-08030-00 | . Bolt | 2 |
| 1 | 156-23411-00-00 | . Race, Ball 1 | 1 |
| 1 | 164-23462-00-00 | .Seal, Dust | 1 |
| 38 | 93501-04011-00 | Ball | 38 |
| 2 | 156-23412-00-00 | Race, Ball 2 | 2 |
| 1 | 156-23411-00-00 | Race, Ball 1 | 1 |
| 156-23415-00-00 | Cover, Ball Race 1 | ||
| 168-23435-00-00 | Crown, Handle | ||
| 1 | 95333-08600-00 | Nut | 1 |
| 1 | 92990-08100-00 | Washer, Spring | 1 |
| 1 | 97313-08055-00 | Bolt, Hexagon | 1 |
| 90201-16249-00 | Washer, Plate | ||
| 168-23451-00-00 | Bolt, Fitting 1 | ||
| 156-23428-00-00 | Spring | ||
| 156-23424-00-00 | Guide, Damper | ||
| 1 | 90202-06008-00 | Washer, Plate | 1 |
| 90201-06061-00 | Washer, Plate | ||
| 168-23419-00-00 | Shaft, Damper | ||
| 168-23441-00-00 | Holder, Handle Upr | ||
| 4 | 92990-08100-00 | Washer, Spring | 4 |
| 4 | 97313-08035-00 | Bolt | 4 |
| 168-23423-00-00 | Plate, Damper 3 | ||
| 156-23425-00-00 | Damper, Friction | ||
| 169-23422-01-00 | Plate, Damper 2 | ||
| 1 | 97313-08020-00 | Bolt, Hexagon | 1 |
| 169-23421-00-33 | Plate, Damper 1 | ||
| 156-23433-00-00 | Pin, Cotter | ||
| 122-23483-00-00 | Rivet | ||
| 156-23480-00-00 | Steering Lock Assembly | ||
| 156-23454-00-00 | Nut, Fitting 2 | ||
| 183-23318-00-00 | Holder, Cable 1 | ||
| 2 | 122-23129-00-00 | . Gasket, Drain Plug | 2 |
| 92503-04008-00 | Screw, Pan Head USED ON 168-23100-00-22 REF 0-GRID D-10 | ||
| 211-23191-40-00 | . Boot, Front Fork |
