Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5XC-14101-90-00 | Carburetor Assy 1 | ||
| 1 | 5JG-14959-00-00 | . .Gasket | 1 |
| 6 | 91316-04012-00 | . .Bolt | 6 |
| 3 | 688-14592-00-00 | . .Screw | 3 |
| 1 | 90202-08045-00 | . .Washer, Plate | 1 |
| 1 | 5JG-14951-00-00 | . .Washer | 1 |
| 1 | 5JG-14522-00-00 | . .Screw, Adjust | 1 |
| 5JG-14388-10-00 | . Valve, Vacuum Control | ||
| 1 | 3TJ-14267-40-00 | . .Roller | 1 |
| 1 | 5JG-14546-01-00 | . .Valve, Needle | 1 |
| 1 | 4FN-14997-00-00 | . .Seal | 1 |
| 5NL-14916-EP-00 | . Needle (#Obelp) AP | ||
| 5NL-14916-EM-00 | . Needle (#Obelm) AP | ||
| 5NL-14916-EN-00 | . Needle (#Obeln) AP | ||
| 5NL-14916-E1-00 | . Needle (#Obelq) STD | ||
| 5NL-14916-ER-00 | . Needle (#Obelr) AP | ||
| 5NL-14916-ES-00 | . Needle (#Obels) AP | ||
| 5NL-14916-ET-00 | . .Needle (#Obelt) AP | ||
| 1 | 3TJ-14159-40-00 | . .Clip | 1 |
| 1 | 5JG-14521-00-00 | . .Screw, Adjust | 1 |
| 1 | 5JG-14275-00-00 | . .Spring | 1 |
| 1 | 5JG-14264-00-00 | . .Collar | 1 |
| 1 | 5JG-14947-00-00 | . Nozzle, Main | 1 |
| 1 | 4MX-14943-42-00 | . .Jet, Main (#175) AP | 1 |
| 1 | 4MX-14943-43-00 | . .Jet, Main (#180) AP | 1 |
| 1 | 4MX-14943-40-00 | . .Jet, Main (#165) AP | 1 |
| 1 | 4MX-14943-91-00 | . .Jet, Main (#168) AP | 1 |
| 1 | 4MX-14943-41-00 | . .Jet, Main (#170) AP | 1 |
| 1 | 4MX-14943-92-00 | . .Jet, Main (#172) AP | 1 |
| 1 | 4MX-14943-93-00 | . .Jet, Main (#178) STD | 1 |
| 1 | 4MX-14943-94-00 | . .Jet, Main (#182) AP | 1 |
| 1 | 4MX-14943-44-00 | . .Jet, Main (#185) AP | 1 |
| 1 | 4MX-14943-95-00 | . .Jet, Main (#188) AP | 1 |
| 1 | 4MX-14948-06-00 | . .Jet, Slow (#48) AP | 1 |
| 1 | 4MX-14948-04-00 | . .Jet, Slow (#42) STD | 1 |
| 1 | 4MX-14948-05-00 | . .Jet, Slow (#45) AP | 1 |
| 1 | 4MX-14948-02-00 | . .Jet, Slow (#38) AP | 1 |
| 1 | 4MX-14948-03-00 | . .Jet, Slow (#40) AP | 1 |
| 1 | 3TJ-1494F-13-00 | . .Jet (#65) AP | 1 |
| 1 | 3TJ-1494F-14-00 | . .Jet (#68) AP | 1 |
| 1 | 3TJ-1494F-15-00 | . .Jet (#70) AP | 1 |
| 1 | 3TJ-1494F-16-00 | . .Jet (#72) STD | 1 |
| 1 | 3TJ-1494F-17-00 | . .Jet (#75) AP | 1 |
| 1 | 3TJ-1494F-18-00 | . .Jet (#78) AP | 1 |
| 1 | 3TJ-1494F-19-00 | . .Jet (#80) AP | 1 |
| 1 | 5TA-14943-28-00 | . .Jet, Main (#105) | 1 |
| 1 | 4JT-1494F-19-00 | . .Jet (#80) STD | 1 |
| 1 | 4JT-1494F-15-00 | . .Jet (#70) AP | 1 |
| 1 | 4JT-1494F-23-00 | . .Jet (#90) AP | 1 |
| 1 | 4JT-1494F-07-00 | . .Jet (#50) AP | 1 |
| 1 | 4JT-1494F-11-00 | . .Jet (#60) AP | 1 |
| 1 | 4JT-1494F-27-00 | . . Jet (#100) AP | 1 |
| 1 | 4JT-1494F-29-00 | . . Jet (#110) AP | 1 |
| 3 | 3TJ-14564-40-00 | . . O-Ring | 3 |
| 1 | 4SR-14985-00-00 | . .Float | 1 |
| 1 | 676-14548-00-00 | . ..Pin, Float Arm | 1 |
| 1 | 4MX-14392-00-00 | . .Valve, Needle | 1 |
| 1 | 633-14159-00-00 | . .Clip | 1 |
| 1 | 5JG-14984-00-00 | . .Gasket, Float Chamber | 1 |
| 1 | 3TJ-14191-40-00 | . ..Plug, Drain | 1 |
| 1 | 3TJ-14293-40-00 | . .Cover 1 | 1 |
| 1 | 5JG-14940-18-00 | . .Diaphragm, Acc Pump (Dph#25) AP | 1 |
| 1 | 5JG-14940-17-00 | . .Diaphragm, Acc Pump (Dph#35) AP | 1 |
| 1 | 5JG-14940-76-00 | . .Diaphragm, Acc Pump (Dph#30) STD | 1 |
| 1 | 5JG-14940-16-00 | . .Diaphragm, Acc Pump (Dph#45) AP | 1 |
| 1 | 3TJ-14536-40-00 | . .Gasket | 1 |
| 1 | 3TJ-14933-40-00 | . .Spring, Diaphragm | 1 |
| 1 | 6H4-14561-00-00 | . .O-Ring | 1 |
| 1 | 5XC-14171-00-00 | . .Plunger, Starter | 1 |
| 1 | 5TA-14371-00-00 | . .Plunger, Starter | 1 |
| 1 | 5TA-14335-00-00 | . .Spring, Plunger | 1 |
| 1 | 5TA-14991-00-00 | . .Screw | 1 |
| 1 | 5TA-14374-00-00 | . Cap, Plunger | 1 |
| 1 | 5TA-14155-00-00 | . .Guide, Cable | 1 |
| 1 | 5TA-14997-00-00 | . .Seal | 1 |
| 1 | 5JG-14379-00-00 | . .Rod, Starter | 1 |
| 1 | 5XC-14922-00-00 | . .Screw, Throttle | 1 |
| 1 | 90201-08410-00 | . .Washer, Plate | 1 |
| 1 | 5TA-14934-00-00 | . .Spring, Throttle Stop | 1 |
| 1 | 5XC-85885-00-00 | . .Throttle Sensor Assy | 1 |
| 1 | 5NX-14562-00-00 | . .O-Ring | 1 |
| 1 | 5NX-14216-00-00 | . .Screw | 1 |
| 1 | 4MX-14561-00-00 | . .O-Ring | 1 |
| 1 | 4MX-14115-00-00 | . .Plug, Screw | 1 |
| 5 | 3TJ-14137-40-00 | . .Clip | 5 |
| 2 | 5BE-14146-00-00 | . .Plate | 2 |
| 1 | 5TA-14261-00-00 | . .Holder | 1 |
| 2 | 5UL-14196-00-00 | . .Pipe, Over Flow 1 | 2 |
| 2 | 5TA-14197-00-00 | . .Pipe | 2 |
| 1 | 5TJ-14987-00-00 | . .Hose | 1 |
| 1 | 5JG-14346-00-00 | . .Plate | 1 |
| 1 | 5JG-14565-00-00 | . .Screw | 1 |
| 1 | 5JG-14531-00-00 | . .Spring, Adjust Screw | 1 |
| 1 | 5NL-14591-00-00 | . .Screw | 1 |
| 5PA-14146-00-00 | . . Plate | ||
| 1 | 5NL-14105-00-00 | . . Pilot Screw Set | 1 |
| 1 | 3TJ-14562-40-00 | . . .O-Ring | 1 |
| 1 | 3TJ-14952-40-00 | . . Washer | 1 |
| 1 | 3TJ-14160-40-00 | . . Coil, Spring | 1 |
