Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Front Coupling Device Ass'y Includes 1 To 5 | ||
| 1 | 705204970 | Front Coupling Device | 1 |
| 605456511 | Pin | ||
| 2 | 605456518 | Pin | 2 |
| 2 | 207682046 | Hex. Flange Screw M8 X 20 | 2 |
| XXXX | Not Available As Spare Part - Coupling Ball Ass'y Includes 6 To 9 | ||
| 1 | 705204974 | Coupling Ball Ass'y | 1 |
| 1 | 250100104 | Elastic Flange Nut M20 | 1 |
| 250200161 | LOCK WASHER | ||
| 860200927 | Trailer Plug Ass'y Includes 10 To 17 | ||
| XXXX | Not Available As Spare Part - Rear Light Harness | ||
| 605356523 | Plug Support Plate | ||
| 3 | 205053588 | Socket Head Screw M5 X 35 | 3 |
| 3 | 233251414 | Hex. Flange Elastic Nut M5 | 3 |
| 5 | 414115200 | Tie-Rap 180 mm | 5 |
| 1 | 207661644 | Hex. Flange Screw M6 X 16 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 708002208 | Seat Ass'y | ||
| 605456520 | Front Bottom Support | ||
| 510005986 | Support Central Cushion | ||
| 510005988 | Support Rear Cushion | ||
| 605456546 | RUBBER DAMPER | ||
| 10 | 293150067 | Rivet | 10 |
| 1 | 708000909 | Latch | 1 |
| 705005761 | HEAT SHIELD | ||
| 705204621 | Support Rear Seat | ||
| 2 | 708000760 | Bumper Rubber | 2 |
| 605456593 | Decal | ||
| XXXX | Not Available As Spare Part - Backrest Ass'y Includes 29 To 36 | ||
| 708001794 | Backrest | ||
| 605454799 | Rubber | ||
| 705205026 | Support | ||
| 3 | 250000675 | Torx Truss Screw M6 x 12 | 3 |
| 1 | 708002039 | BACK REST FIXING BODY PAINT | 1 |
| 1 | 510003533 | Handle M8 X 35 | 1 |
| 1 | 708002168 | Sleeve | 1 |
| 605356244 | P-Decal, T3 | ||
| 605456594 | Cabin Decal, T3 | ||
| 605356505 | Warning Decal | ||
| XXXX | Not Available As Spare Part - LH Rear Light Support Ass'y Includes 40 To 46 | ||
| XXXX | Not Available As Spare Part - RH Rear Light Support Ass'y Includes 40 To 46 | ||
| 1 | 705010329 | REAR LIGHT SUPPORT LH | 1 |
| 1 | 705010330 | REAR LIGHT SUPPORT RH | 1 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 | 2 |
| 1 | 250000722 | Torx Screw M6 X 20 | 1 |
| 1 | 710001645 | Tail Light Ass'y | 1 |
| 1 | 710002047 | Flasher | 1 |
| 1 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 1 |
| XXXX | Not Available As Spare Part - Licence Plate Support Ass'y Includes 47 To 54 | ||
| 1 | 708002040 | License Plate Support | 1 |
| 2 | 705011221 | Red Reflector | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 1 | 710002721 | Licence Light | 1 |
| 4 | 250000761 | Torx Truss Screw M8 X 50 | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 708002041 | CABLE HOUSING Includes 55 To 56 | ||
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 515178093 | REAR LIGHT HARNESS | ||
| 704904333 | WARNING DECAL, TIRE PRESSURE |
