Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 64110-28001 | HUB, REAR WHEEL J,K,L; TO 64110-28002 | ||
| 64110-28002 | HUB, REAR WHEEL M | ||
| 64210-28001 | PANEL,HUB J; TO 64910-28002 | ||
| 64210-28002 | WHEEL, HUB K; TO 64210-25500 | ||
| 64210-25500 | PANEL, HUB L; TO 68210-28003 | ||
| 64210-28003 | PANEL,HUB M | ||
| 2 | 54410-08001 | SHOE,BRAKE J,K,L; TO 54410-07002 | 2 |
| 54410-07002 | SHOE,BRAKE M | ||
| 2 | 09443-07001 | SPRING (L:34) | 2 |
| 54441-20000 | CAK, BRAKE J,K; TO 34441-28001 | ||
| 54441-07001 | CAM, BRAKE L; TO 54441-01002 | ||
| 1 | 54441-01002 | CAM, BRAKE M | 1 |
| 1 | 09280-12000 | DUST SEAL | 1 |
| 64451-28000 | LEVER, BRAKE CAM | ||
| 1 | 09100-06050 | BOLT, CAM LEVER | 1 |
| 1 | 08322-21068 | WASHER | 1 |
| 1 | 08311-11068 | NUT | 1 |
| 1 | 09160-12011 | WASHER (12.5X20X1.0) | 1 |
| 64610-28001 | DRUM, SPROKET MOUNTING | ||
| 64650-28000 | ASBORBER, HUB DRUM J,K; TO 64650-28001 | ||
| 64650-28001 | ASBORBER, HUB DRUM L; TO 64650-28002 | ||
| 64650-28002 | ASBORBER, HUB DRUM M | ||
| 64711-28000 | AXLE, REAR J,K; TO 64711-28001 | ||
| 64711-28001 | AXLE, REAR L,M | ||
| 1 | 09180-15010 | SPACER, REAR AXLE RH | 1 |
| 64750-28000 | SPACER, REAR AXLE LH | ||
| 1 | 08314-31128 | NUT | 1 |
| 64730-28000 | SPACER, BEARING FROM 64730-34000 | ||
| 1 | 08143-62020 | BEARING | 1 |
| 1 | 08123-63020 | BEARING | 1 |
| 1 | 08331-11558 | CIRCLIP | 1 |
| 09448-27003 | SPRING, CAM LEVER | ||
| 1 | 04111-30308 | COTTER PIN | 1 |
| 1 | 64791-28001 | SPACER, CHAIN ADJUSTER RH L:27 | 1 |
| 64791-28000 | SPACER, CHAIN ADJUSTER LH J,K; L:25 | ||
| 1 | 09140-18001 | NUT, CHAIN ADJUSTER SPACER | 1 |
| 64511-29720 | SPROCKET, REAR NT:37 | ||
| 6 | 09105-08001 | BOLT, SPROCKET J,K,L | 6 |
| 09105-08006 | BOLT, SPROCKET M | ||
| 3 | 09169-08013 | WASHER, REAR SPROCKET | 3 |
| 09140-08010 | NUT | ||
| 1 | 61410-28002 | ADJUSTER, CHAIN RH 8SCREW | 1 |
| 61410-28001 | ADJUSTER, CHAIN RH J,K; 6SCREW | ||
| 1 | 61420-28002 | ADJUSTER, CHAIN LH 8SCREW | 1 |
| 61420-28001 | ADJUSTER, CHAIN LH J,K; 6SCREW | ||
| 2 | 09100-08099 | BOLT, CHAIN ADJUSTER 8x40 | 2 |
| 2 | 09100-06065 | BOLT, CHAIN ADJUSTER J,K; 6x37 | 2 |
| 2 | 08312-31088 | NUT | 2 |
| 2 | 08311-11068 | NUT J,K | 2 |
| 65100-28211 | TIRE, REAR J,K; 3.25-18, OPT KNOBBYL,M; 3.25-18, OPT KNOBBY | ||
| 65100-28031 | TIRE, REAR L,M; 3.25~18 KNOBBY | ||
| 1 | 65200-18010 | TUBE, INNER J,K; 3.25~18 | 1 |
| 65200-28030 | TUBE, INNER L,M; 3.25-18 | ||
| 1 | 55261-11010 | PROTECTOR, INNER TUBE J,K | 1 |
| 55261-28030 | PROTECTOR, INNER TUBE L,M | ||
| 65311-29601 | RIM, REAR WHEEL J,K,L; BOLD-TIPPED TYPE | ||
| 65311-29602 | RIM, REAR WHEEL L; STREIGHT TYPE | ||
| 65311-29022 | RIM, REAR WHEEL M | ||
| 65300-28807 | SPOKE SET, REAR J,K,L; BOLD-TIPPED TYPE | ||
| 1 | 65300-28880 | SPOKE SET, REAR L,M; STRAIGHT TYPE | 1 |
| 1 | 65270-28600 | STOPPER, HEAD J,K,L | 1 |
| 1 | 08322-11068 | WASHER J,K,L | 1 |
| 1 | 08312-11088 | NUT J,K,L | 1 |
| 1 | 55412-11000 | BALANCER, WHEEL J,K,L; 30G BOLD-TIPPED TYPE | 1 |
| 55412-37000 | BALANCER, WHEEL L; 30G STRAIGHT TYPE | ||
| 55411-28000 | BALANCER, WHEEL J,K,L; 50G BOLD-TIPPED TYPE | ||
| 55411-30000 | BALANCER, WHEEL L; 50G STRAIGHT TYPE |
