Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 14B-Y283P-10-00 | SCREEN | 1 |
| 14B-2832P-00-00 | GRAPHIC, 18 | ||
| 14B-28428-00-00 | SEAL 1 | ||
| 14B-28429-00-00 | SEAL 2 | ||
| 1 | 14B-2844E-00-00 | SEAL 3 | 1 |
| 1 | 14B-2846F-00-00 | SEAL 4 | 1 |
| 1 | 14B-2847F-00-00 | SEAL 5 | 1 |
| 1 | 14B-2848F-00-00 | SEAL 6 | 1 |
| 1 | 4B5-2815K-00-00 | LABEL, NOTICE WINDSHIELD 1 | 1 |
| 1 | 14B-Y283G-00-P3 | BODY, FRONT UPPER 1 UR FOR SMX | 1 |
| 0 | 14B-Y283G-70-P1 | BODY, FRONT UPPER 1 UR FOR BWC1 | 0 |
| 0 | 14B-Y283G-00-P2 | BODY, FRONT UPPER 1 UR FOR DPBMC | 0 |
| 4 | 5PW-2177L-00-00 | PLATE, SPRING | 4 |
| 1 | 14B-28219-00-P0 | COVER 1 UR FOR SMX | 1 |
| 0 | 14B-28219-00-P3 | COVER 1 UR FOR BWC1, DPBMC | 0 |
| 1 | 14B-28229-00-P0 | COVER 2 UR FOR SMX | 1 |
| 0 | 14B-28229-00-P3 | COVER 2 UR FOR BWC1, DPBMC | 0 |
| 6 | 90183-05M02-00 | NUT, SPRING | 6 |
| 2 | 90183-05076-00 | NUT, SPRING | 2 |
| 0 | 14B-2832L-70-00 | GRAPHIC, 13 FOR BWC1 | 0 |
| 1 | 14B-28356-00-00 | STAY 1 | 1 |
| 7 | 4XV-83513-00-00 | DAMPER | 7 |
| 2 | 90105-08052-00 | BOLT, FLANGE | 2 |
| 1 | 14B-2838B-00-00 | GRILL ASSY | 1 |
| 1 | 14B-28372-00-00 | DAMPER | 1 |
| 1 | J44-78248-00-00 | SEAL 4 | 1 |
| 1 | 90520-03001-00 | DAMPER, PLATE | 1 |
| 1 | 1TX-28267-00-00 | DAMPER 5 | 1 |
| 1 | 14B-2838B-10-00 | GRILL ASSY | 1 |
| 4 | 90160-05007-00 | SCREW, ROUND TAPPING | 4 |
| 2 | 97707-50012-00 | SCREW, TRUSS HEAD TAPPING | 2 |
| 4 | 90160-05006-00 | SCREW, ROUND TAPPING | 4 |
| 1 | 14B-2838N-00-P5 | DUCT 1 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2838N-00-P6 | DUCT 1 UR FOR DPBMC | 0 |
| 1 | 14B-2838T-00-00 | DUCT 3 | 1 |
| 2 | 97702-50012-00 | SCREW, TAPPING | 2 |
| 2 | 90480-08005-00 | GROMMET | 2 |
| 1 | 14B-2839K-00-P5 | LID 1 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2839K-00-P6 | LID 1 UR FOR DPBMC | 0 |
| 1 | 14B-2838V-00-00 | BOX 3 | 1 |
| 2 | 90179-05523-00 | NUT | 2 |
| 2 | 90111-05034-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 2 | 90202-05180-00 | WASHER, PLATE | 2 |
| 1 | 5PW-2177L-00-00 | PLATE, SPRING | 1 |
| 1 | 90269-07077-00 | RIVET | 1 |
| 1 | 90520-01001-00 | DAMPER, PLATE | 1 |
| 1 | 90520-03005-00 | DAMPER, PLATE | 1 |
| 1 | 90179-05523-00 | NUT | 1 |
| 1 | 14B-2838R-00-P5 | DUCT 2 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2838R-00-P6 | DUCT 2 UR FOR DPBMC | 0 |
| 1 | 14B-2838U-00-00 | DUCT 4 | 1 |
| 1 | 14B-2839L-00-P5 | LID 2 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2839L-00-P6 | LID 2 UR FOR DPBMC | 0 |
| 1 | 14B-2838W-00-00 | BOX 4 | 1 |
| 1 | 14B-2838J-00-00 | DUCT 5 | 1 |
| 14B-2838P-00-00 | DUCT 6 | ||
| 1 | 14B-2837L-00-P5 | PANEL, CONSOLE 1 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2837L-00-P6 | PANEL, CONSOLE 1 UR FOR DPBMC | 0 |
| 4C8-2112D-00-00 | DAMPER, 3 | ||
| 1 | 2S3-2111D-00-00 | SEAL 1 | 1 |
| 1 | 14B-2837M-00-P5 | PANEL, CONSOLE 2 UR FOR SMX, BWC1 | 1 |
| 0 | 14B-2837M-00-P6 | PANEL, CONSOLE 2 UR FOR DPBMC | 0 |
| 1 | 14B-26280-00-00 | REAR VIEW MIRROR ASSY (LEFT) | 1 |
| 1 | 14B-26290-00-00 | REAR VIEW MIRROR ASSY (RIGHT) | 1 |
| 2 | 4C8-26298-00-00 | PLATE, MIRROR FITTING 1 | 2 |
| 1 | 14B-2628N-00-00 | BASE, MIRROR (LEFT) | 1 |
| 1 | 14B-2628R-00-00 | BASE, MIRROR (RIGHT) | 1 |
| 4 | 90176-06055-00 | NUT, CROWN | 4 |
| 4 | 90387-064T3-00 | COLLAR | 4 |
| 1 | 14B-2846C-00-00 | BOX, SIDE 1 | 1 |
| 1 | 14B-2846D-00-00 | BOX, SIDE 2 | 1 |
| 1 | 14B-2845D-10-00 | BOX, FRONT | 1 |
| 1 | 90480-13567-00 | GROMMET | 1 |
