Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 710000001 | HEADLAMP | ||
| 705000023 | Protector | ||
| 705000182 | Headlamp Support | ||
| 4 | 572106600 | Handle | 4 |
| 6 | 250000008 | HEX. SCREW K40 X 40 | 6 |
| 4 | 517168600 | Spring | 4 |
| 4 | 241641040 | PHILLIPS SCREW K40 X 10 | 4 |
| 4 | 293720053 | Grommet | 4 |
| 293830088 | Rubber Pad | ||
| 710000102 | Tail Light Housing Includes 10 - 13. | ||
| 710000055 | TAIL LIGHT LENS, RED | ||
| 1 | 410504100 | Bulb | 1 |
| 1 | 710000129 | GASKET | 1 |
| 2 | 208656091 | PAN HEAD PHILLIPS SCREW M5 X 60 | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 | 2 |
| 1 | 710000024 | Dc Outlet, 12 Volts | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 390402400 | Pop Rivet 3/16" | 1 |
| 1 | 414227300 | Clip | 1 |
| 1 | 293730018 | Mount Dart | 1 |
| 710000042 | Ignition Switch Ass'y Includes 21 - 24. | ||
| 3 | 278000223 | Female Terminal | 3 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 3 | 278000218 | Wire Seal | 3 |
| 710000171 | Protector Tube | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 710000021 | Speedometer (MPH) (US) | ||
| 710000037 | Speedometer (KM/H) | ||
| 710000089 | RH Warning Lamp Includes 29 - 32. | ||
| 6 | 409014800 | MALE TERMINAL | 6 |
| 409014600 | Male Lock, 6 Circuits | ||
| 409015200 | Male Terminal Housing, 6 Circuits | ||
| 710000008 | LH Warning Lamp Includes 33 - 36. | ||
| 710000088 | Multi-function Switch Ass'y Includes 37 - 41. | ||
| 1 | 710000173 | BACK COVER | 1 |
| 710000035 | Female Housing (8 Circuits) | ||
| 710000036 | Female Terminal | ||
| 1 | 710000038 | Female Terminal | 1 |
| 1 | 278001007 | Insulated Sheath | 1 |
| 1 | 278000770 | Insulated Sheath | 1 |
| 1 | 278001009 | Female Terminal | 1 |
| 2 | 710000082 | Female Terminal (7461 / 7462 / 7469 / 7470 / 7471 / 7480) | 2 |
| 1 | 409015400 | FEMALE HOUSING, 6 CIRCUITS | 1 |
| 1 | 409014900 | FEMALE LOCK, 6 CIRCUITS | 1 |
| 1 | 409015100 | FEMALE TERMINAL | 1 |
| 2 | 409015400 | FEMALE HOUSING, 6 CIRCUITS | 2 |
| 2 | 409014900 | FEMALE LOCK, 6 CIRCUITS | 2 |
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 1 | 409004300 | Male Terminal | 1 |
| 1 | 278000218 | Wire Seal | 1 |
| 710000027 | Female Terminal | ||
| 710000028 | Female Lock, 2 Circuits | ||
| 2 | 710000026 | FEMALE TERMINAL HOUSING, 2 CIRCUITS | 2 |
| 1 | 710000044 | MALE HOUSING, 3 CIRCUITS | 1 |
| 1 | 710000043 | MALE LOCK, 3 CIRCUITS | 1 |
| 1 | 409014800 | MALE TERMINAL | 1 |
| 1 | 515175249 | FEMALE TERMINAL HOUSING, 3 CIRC. | 1 |
| 515175248 | Female Lock, 3 Circuits | ||
| 1 | 515175303 | PLUG | 1 |
| 409204300 | Female Housing | ||
| 1 | 561503100 | FEMALE TERMINAL | 1 |
| 1 | 409012600 | Terminal Ring | 1 |
| 1 | 710000101 | BLANK KEY (B TYPE) | 1 |
| 710000137 | BLANK KEY (A TYPE) | ||
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704399 | Was 409901700 Tubing (9 mm) | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 1 | 219704408 | Tubing 16 Mm 1000Mm Long | 1 |
| 1 | 219704398 | Was 409901600 Tubing 19mm | 1 |
| 710000152 | Harness Ass'y (Not Shown) |
