Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Continuously Variable Transmission (CVT) Includes 1 To 42 | ||
| 7 | 420440307 | Hex. Distance Screw M6 X 30.5 | 7 |
| 420610421 | CVT COVER | ||
| 1 | 420630290 | CVT Cover Gasket | 1 |
| 1 | 420641812 | Hex. Screw M12 X 140 | 1 |
| 1 | 420627760 | Spring Washer | 1 |
| 420684400 | CVT Drive Ass'y Includes 6 to 24 | ||
| 1 | 420280155 | Governor Cup Ass'y Includes 6 to 9 | 1 |
| XXXX | Not Available As Spare Part - Governor Cup | ||
| 1 | 420281290 | Shoe Slider Set | 1 |
| 6 | 420233890 | Roller Sleeve | 6 |
| 6 | 420229585 | Roller | 6 |
| 420280310 | Outer Half Ass'y Includes 10 to 16 | ||
| XXXX | Not Available As Spare Part - Outer Half | ||
| XXXX | Not Available As Spare Part - Bushing | ||
| XXXX | Not Available As Spare Part - Retaining Ring | ||
| 1 | 420248428 | Centrifugal Lever Set Includes 14 to 16 | 1 |
| XXXX | Not Available As Spare Part - Bearing Screw M5 | ||
| XXXX | Not Available As Spare Part - Lever | ||
| XXXX | Not Available As Spare Part - Lock Nut M5 | ||
| 1 | 420238161 | Compression Spring | 1 |
| 1 | 420627574 | Spring Seat | 1 |
| 420281390 | Inner Half Set Ass'y Includes 19 to 24 | ||
| 1 | 420257437 | Clutch | 1 |
| 2 | 420632371 | Ball Bearing 6808 | 2 |
| 1 | 420245950 | Retaining Ring | 1 |
| XXXX | Not Available As Spare Part - Inner Half Ass'y | ||
| 2 | 420229576 | Spring Sleeve | 2 |
| 2 | 420239132 | Compression Spring | 2 |
| 1 | 420941906 | Hex. Screw M10 X 110 | 1 |
| 1 | 420627590 | Thrust Washer | 1 |
| 420684450 | CVT DRIVEN PULLEY ASS'Y Includes 27 to 40 | ||
| 1 | 420280176 | Outer Half Ass’y Includes 27 to 32 | 1 |
| 1 | 420932426 | Ball Bearing 6205 | 1 |
| 420660120 | TORQUE GEAR | ||
| 1 | 420245910 | Retaining Ring | 1 |
| 1 | 420280235 | Sliding Pulley Ass'y Includes 33 to 35 | 1 |
| XXXX | Not Available As Spare Part - Inner Half | ||
| 1 | 420238340 | COMPRESSION SPRING | 1 |
| 1 | 420220911 | Driven Shaft | 1 |
| 1 | 420280250 | Cam | 1 |
| 1 | 420627582 | Cam Plate | 1 |
| 1 | 715900024 | V-Belt | 1 |
| 1 | 420627920 | Thrust Washer | 1 |
| 1 | 293550021 | Isoflex Grease, TOPAS NB52, 50 g | 1 |
| XXXX | Not Available As Spare Part - Continuously Variable Transmission (CVT) Includes 43 To 86 | ||
| 7 | 420440567 | Hex. Distance Screw M6 X 30.5 | 7 |
| 420684401 | CVT Drive Ass'y Includes 48 to 67 | ||
| 1 | 420280155 | Governor Cup Ass'y Includes 48 to 51 | 1 |
| 420280316 | Outer Half Ass'y Includes 52 to 59 | ||
| 1 | 420248424 | Centrifugal Lever Set Includes 56 to 59 | 1 |
| XXXX | Not Available As Spare Part - Thrust Washer | ||
| 420281390 | Inner Half Set Ass'y Includes 62 to 67 | ||
| 420684669 | CVT DRIVEN PULLEY ASS'Y Includes 70 to 81 | ||
| 1 | 420280173 | Outer Half Pulley Ass'y Includes 70 to 75 | 1 |
| 1 | 420660121 | Torque Gear | 1 |
| 1 | 420280235 | Sliding Pulley Ass'y Includes 76 to 79 | 1 |
