Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 0 | 13S-2117V-00-P0 | Cover 7 UR FOR DPBMC | 0 |
| 1 | 13S-2117V-00-P3 | Cover 7 UR FOR SMX | 1 |
| 13S-2117V-00-P4 | Cover 7 UR FOR S3 | ||
| 1 | 90480-12613-00 | Grommet | 1 |
| 1 | 90387-067K8-00 | Collar | 1 |
| 1 | 90480-14003-00 | Grommet | 1 |
| 1 | 90387-06057-00 | Collar | 1 |
| 1 | 90183-05076-00 | Nut, Spring | 1 |
| 1 | 90338-06134-00 | Plug | 1 |
| 1 | 90111-05003-00 | Bolt, Hex. Socket Button | 1 |
| 1 | 90202-05180-00 | Washer, Plate | 1 |
| 1 | 90111-06063-00 | Bolt, Hex. Socket Button | 1 |
| 1 | 90111-06040-00 | Bolt, Hex. Socket Button | 1 |
| 0 | 13S-2117W-00-P4 | Cover 8 UR FOR S3 | 0 |
| 0 | 13S-2117W-00-P0 | Cover 8 UR FOR DPBMC | 0 |
| 1 | 13S-2117W-00-P3 | Cover 8 UR FOR SMX | 1 |
| 1 | 90464-20014-00 | Clamp | 1 |
| 13S-28385-00-P2 | Cover, Lower UR FOR S3 | ||
| 13S-W2838-00-P1 | Under Cover Comp 1 UR SMX FOR DPBMC | ||
| 1 | 13S-28385-00-P1 | Cover, Under UR FOR SMX | 1 |
| 1 | 13S-28301-00-00 | . Graphic Set, Lower Cover 1 FOR DPBMC | 1 |
| 2 | 90480-14003-00 | Grommet | 2 |
| 2 | 90387-06057-00 | Collar | 2 |
| 1 | 13S-2838G-00-00 | Seat 1 | 1 |
| 1 | 13S-2836U-00-00 | Damper, Locating 2 | 1 |
| 2 | 90111-06040-00 | Bolt, Hex. Socket Button | 2 |
| 13S-W283U-10-P0 | Panel Assy 1 UR FOR DPBMC | ||
| 1 | 13S-2835U-00-P3 | Panel 1 UR MBL2 FOR SMX | 1 |
| 13S-W283U-00-P4 | Panel Assy 1 UR MT1 FOR S3 | ||
| 1 | 13S-28328-30-00 | . Emblem UR FOR S3 | 1 |
| 1 | 13S-28391-30-00 | . Graphic 1 UR FOR DPBMC | 1 |
| 1 | 13S-28328-20-00 | Emblem FOR SMX | 1 |
| 1 | 13S-28219-00-00 | Cover 1 | 1 |
| 2 | 90183-05M02-00 | Nut, Spring | 2 |
| 1 | 13S-28415-00-00 | Damper 1 | 1 |
| 1 | 13S-24183-00-00 | Damper, Locating 3 | 1 |
| 1 | 97707-50016-00 | Screw, Truss Head Tapping | 1 |
| 1 | 90269-07007-00 | Rivet | 1 |
| 1 | 13S-2137U-00-00 | Guide, Air 1 | 1 |
| 1 | 13S-2137K-00-00 | Guide, Air 3 | 1 |
| 4 | 97702-50016-00 | Screw, Tapping | 4 |
| 2 | 90480-01558-00 | Grommet | 2 |
| 1 | 13S-28217-00-00 | Damper 1 | 1 |
| 2 | 90269-06008-00 | Rivet | 2 |
| 2 | 90269-06081-00 | Rivet | 2 |
| 6 | 97707-50016-00 | Screw, Truss Head Tapping | 6 |
| 2 | 97702-50020-00 | Screw, Tapping | 2 |
| 13S-W2839-00-P1 | Under Cover Comp 2 UR SMX FOR DPBMC | ||
| 0 | 13S-28395-00-P2 | Cover, Under UR FOR S3 | 0 |
| 1 | 13S-28395-00-P1 | Cover, Under 2 UR FOR SMX | 1 |
| 13S-28303-00-00 | . Graphic Set, Lower Cover 2 FOR DPBMC | ||
| 1 | 13S-2848K-00-00 | Seat 2 | 1 |
| 1 | 13S-2847R-00-00 | Damper 10 | 1 |
| 1 | 13S-2835V-00-P3 | Panel 2 UR MBL2 FOR SMX | 1 |
| 13S-W283V-10-P0 | Panel 2 UR SMX FOR DPBMC | ||
| 0 | 13S-W283V-00-P4 | Panel 2 UR MT1 FOR S3 | 0 |
| 0 | 13S-28392-30-00 | . Graphic 2 UR FOR DPBMC | 0 |
| 0 | 13S-28338-30-00 | . Emblem UR FOR S3 | 0 |
| 1 | 13S-28338-20-00 | Emblem FOR SMX | 1 |
| 1 | 13S-28229-00-00 | Cover 2 | 1 |
| 2 | 97707-50016-00 | Screw, Truss Head Tapping | 2 |
| 1 | 90109-06207-00 | Bolt | 1 |
| 1 | 90202-10024-00 | Washer, Plate | 1 |
| 1 | 13S-2836G-00-00 | Bracket 4 | 1 |
| 1 | 90179-06059-00 | . .Nut | 1 |
| 1 | 90105-06020-00 | Bolt, Flange | 1 |
| 1 | 13S-2137V-00-00 | Guide, Air 2 | 1 |
| 1 | 13S-2137L-00-00 | Guide, Air 4 | 1 |
| 1 | 13S-2836L-00-00 | Panel, Inner 2 | 1 |
| 5 | 90269-06008-00 | Rivet | 5 |
| 2 | 90269-06002-00 | Rivet | 2 |
| 1 | 13S-2836M-00-00 | Panel, Inner 3 | 1 |
| 1 | 90269-06008-00 | Rivet | 1 |
| 2 | 13S-2153A-00-00 | Emblem, Yamaha UR FOR SMX | 2 |
| 13S-2153E-30-00 | Emblem, Yamaha UR FOR DPBMC | ||
| 0 | 13S-2153E-40-00 | Emblem, Yamaha UR FOR S3 | 0 |
| 1 | 13S-2834C-00-00 | Emblem 1 FOR SMX | 1 |
| 13S-2835C-00-00 | Emblem 2 FOR SMX | ||
| 2 | 4P6-28338-00-00 | Emblem FOR SMX | 2 |
| 4P6-28328-00-00 | Emblem FOR SMX | ||
| 1 | 13S-21737-00-00 | Emblem FOR SMX | 1 |
| 13S-21737-10-00 | Emblem FOR SMX |
