Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1D7-21110-01-00 | FRAME COMP. | |
| 2 | 1D7-21779-00-00 | DAMPER, LOCATING 2 | 1 |
| 3 | 1D7-24141-00-00 | PROTECTOR, FUEL TANK | 1 |
| 4 | 1D7-2639G-00-00 | SEAL | 1 |
| 5 | 5PX-21268-00-00 | SEAL | 1 |
| 6 | 90105-126A6-00 | BOLT, FLANGE | 1 |
| 7 | 95607-12200-00 | NUT, SELF-LOCKING | 3 |
| 8 | 5PX-21495-00-00 | BOLT, ENGINE ADJUSTING | 1 |
| 9 | 1D7-21315-00-00 | STAY, ENGINE 1 | 1 |
| 10 | 5PX-21316-00-00 | STAY, ENGINE 3 | 1 |
| 11 | 90105-10170-00 | BOLT, WASHER BASED | 2 |
| 12 | 95607-10200-00 | NUT, U FLANGE | 2 |
| 13 | 90105-12309-00 | BOLT, FLANGE | 1 |
| 14 | 1D7-21317-00-00 | STAY, ENGINE 3 | 1 |
| 15 | 90111-10003-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 16 | 90105-12041-00 | BOLT, FLANGE | 2 |
| 17 | 1D7-21319-00-00 | STAY, ENGINE 6 | 1 |
| 18 | 1D7-21669-00-00 | SEAL | 1 |
| 19 | 90105-12025-00 | BOLT, FLANGE | 2 |
| 20 | 90111-10003-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 21 | 1D7-21318-00-00 | STAY, ENGINE 5 | 1 |
| 22 | 95817-10030-00 | BOLT, FLANGE | 3 |
| 23 | 95607-10200-00 | NUT, U FLANGE | 3 |
| 24 | 1D7-2142G-00-00 | STAY 1 | 1 |
| 25 | 90387-12033-00 | COLLAR | 1 |
| 26 | 1D7-21387-00-00 | STAY, ENGINE 7 | 1 |
| 27 | 95817-10045-00 | BOLT, WASHER BASED | 2 |
| 28 | 90101-12025-00 | BOLT | 1 |
| 29 | 90201-126A7-00 | WASHER, PLATE | 1 |
| 30 | 1D7-2142H-01-00 | STAY 2 | |
| 31 | 1D7-2142J-01-00 | STAY 3 | |
| 32 | 90105-10049-00 | BOLT, FLANGE | 1 |
| 33 | 90105-10060-00 | BOLT, FLANGE | 1 |
| 34 | 90105-10167-00 | BOLT, FLANGE | 2 |
| 35 | 90185-10008-00 | NUT, SELF-LOCKING | 4 |
| 36 | 1D7-2115L-00-00 | BRACKET, MEMBER 1 | 1 |
| 37 | 90111-08039-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 38 | 90105-12016-00 | BOLT, FLANGE | 1 |
| 39 | 90185-12002-00 | NUT, SELF-LOCKING | 1 |
| 40 | 1D7-2137F-00-00 | STAY 1 | 1 |
| 41 | 90111-10009-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 42 | 95817-10075-00 | BOLT, FLANGE | 2 |
| 43 | 1D7-21116-01-00 | COLLAR | 2 |
| 44 | 90105-10165-00 | BOLT, FLANGE | 2 |
| 45 | 4YR-24183-01-00 | DAMPER, LOCATING 3 | 2 |
| 46 | 3MA-82591-00-00 | CLAMP | 3 |
| 47 | 1D7-21359-00-00 | BRACKET, COIL | 1 |
| 48 | 92017-06014-00 | BOLT, BUTTON HEAD | 4 |
| 49 | 90201-06045-00 | WASHER, PLATE | 2 |
| 50 | 91317-06020-00 | BOLT, HEX. SOCKET HEAD | 2 |
| 51 | 91380-06020-00 | BOLT | 4 |
| 52 | 1D7-2139X-00-00 | DAMPER | 1 |
| 53 | 1D7-21598-00-00 | HOLDER, WIRE 2 | 1 |
| 54 | 1D7-21269-00-00 | SEAL | 1 |
| 55 | 90111-06010-00 | BOLT, HEX. SOCKET BUTTON | 1 |
| 56 | 1D7-21343-00-00 | BRACKET, HORN | 1 |
| 57 | 90111-08027-00 | BOLT, HEX. SOCKET BUTTON | 2 |
| 58 | 1D7-27114-00-00 | STOPPER, MAIN STAND | 1 |
| 59 | 1D7-21453-00-00 | BRACKET, SWITCH | 1 |
| 60 | 95027-06016-00 | BOLT, FLANGE | 1 |
| 61 | 1D7-2136H-00-00 | STAY, OIL COOLER | 1 |
| 62 | 92017-06020-00 | BOLT, BUTTON HEAD | 2 |
