Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 709401545 | Black, Upper Main Tube Package STD | 1 |
| 1 | 709401750 | Black, Upper Main Tube Except Package STD | 1 |
| 1 | 709401542 | Pitman Arm Package STD | 1 |
| 1 | 709401240 | Black, Handlebar | 1 |
| 1 | 709401748 | Pitman Arm Except Package STD | 1 |
| XXX | Not Available As Spare Parts Package XMR | ||
| 2 | 709400493 | Handle Grip Package STD, PRO & DPS | 2 |
| 2 | 710005038 | Heated Hand Grip With Connector Package PRO Nordic & Hunting Edition | 2 |
| 2 | 709400449 | End Piece | 2 |
| 4 | 709401799 | Steering Support | 4 |
| 2 | 709400509 | Stiffner | 2 |
| 4 | 207086046 | Hex. Screw M8 X 60 | 4 |
| 4 | 233281416 | Hex. Elastic Flange Nut M8 | 4 |
| 1 | 250200086 | Flat Washer Package STD | 1 |
| 1 | 250000047 | Hex. Flange Elastic Nut M12 Package STD | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 1 | 503190396 | Ball Bearing Package STD | 1 |
| 4 | 709400783 | Spherical Half Bushing | 4 |
| 2 | 709401370 | Spherical Half Bushing Package STD | 2 |
| 1 | 293250177 | Seal Package STD | 1 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 709400827 | Upper Column Attachment | 1 |
| 1 | 709401428 | Column Attachment | 1 |
| 2 | 703500922 | Tie Rod Ass'y Includes 180 to 180a | 2 |
| 1 | 709401837 | Ball Joint, LH Thread | 1 |
| 2 | 709401839 | Ball Joint, RH Thread | 2 |
| 4 | 293300068 | O-Ring | 4 |
| 8 | 250200086 | Flat Washer | 8 |
| 4 | 250100099 | Nut M12 | 4 |
| 4 | 211400013 | Cotter Pin | 4 |
| 1 | 250400034 | Cotter Pin Package STD | 1 |
| 1 | 709400939 | Cover Except Package Hunting Edition | 1 |
| 1 | 709402230 | Power Steering Except Package STD | 1 |
| 1 | 709402184 | LH Power Steering Bracket Except ABS & Except Package STD | 1 |
| 1 | 709402192 | Power Steering Module Bracket ABS | 1 |
| 1 | 709402185 | RH Bracket Except Package STD | 1 |
| 1 | 709401743 | Power Steering Support Except Package STD | 1 |
| 11 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip Except Package STD | 11 |
| XXX | Not Available As Spare Parts | ||
| 2 | 250000986 | Hex. Flange Screw M8 X 35 Except Package STD | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 Except Package STD | 2 |
| 4 | 233081416 | Hex. Flange Nut M8 Except Package STD | 4 |
| 1 | 703100813 | Handle Guard Ass'y Package Hunting Edition | 1 |
| 1 | 709400822 | Handle Bar Protector Package XT | 1 |
| 1 | 704902966 | DPS Decal Packages XT & Hunting Edition | 1 |
| 4 | 241142560 | Hex. Flange Screw K40 X 25 Packages XT & Hunting Edition | 4 |
| 4 | 211200035 | Flat Washer Packages XT & Hunting Edition | 4 |
| 2 | 517303264 | U-Clamp Packages XT & Hunting Edition | 2 |
