Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 364-11412-02-00 | . Crank 1 DT250A | ||
| 365-11412-01-00 | . Crank 1 DT360A | ||
| 365-11422-00-00 | . Crank 2 DT360A | ||
| 364-11422-01-00 | . Crank 2 DT250A | ||
| 311-11651-01-00 | . Rod, Connecting DT250A | ||
| 431-11651-00-00 | . Rod, Connecting DT360A | ||
| 1 | 2X4-11681-00-00 | . Pin, Crank 1 | 1 |
| 1 | 93310-42541-00 | . Bearing, Cylindrical | 1 |
| 2 | 90209-25085-00 | . Washer, Special Shape | 2 |
| 438-11631-02-96 | Piston Std (.96Mm Std) (311-116 DT250A | ||
| 438-11636-01-00 | Piston 2 O/S 0.50 (0.50Mm 2Nd O ALT. PART DT250A | ||
| 438-11635-01-00 | Piston 1 O/S 0.25 (0.25Mm 1St O ALT. PART DT250A | ||
| 438-11637-02-00 | Piston 3 O/S 0.75 ALT. PART DT250A | ||
| 438-11638-02-00 | Piston 4 O/S 1.00 ALT. PART DT250A | ||
| 445-11631-00-96 | Piston Std (79.96Mm) DT360A | ||
| 445-11635-00-00 | Piston 1 O/S 0.25 ALT. PART DT360A | ||
| 445-11638-00-00 | Piston 4 O/S 1.00 ALT. PART DT360A | ||
| 445-11637-00-00 | Piston 3 O/S 0.75 ALT. PART DT360A | ||
| 445-11636-02-00 | Piston 2 O/S 0.50 ALT. PART DT360A | ||
| 93310-21876-00 | . Bearing | ||
| 1 | 275-11633-00-00 | Pin, Piston DT360A | 1 |
| 1 | 214-11633-00-00 | Pin, Piston DT250A | 1 |
| 2 | 93450-20026-00 | Circlip | 2 |
| 438-11610-10-00 | Piston Ringset 1St ALT. PART DT250A | ||
| 445-11610-20-00 | Piston Ringset 2Nd ALT. PART DT360A | ||
| 445-11610-10-00 | Piston Ringset 1St ALT. PART DT360A | ||
| 445-11610-00-00 | Piston Ringset Std DT360A | ||
| 438-11610-00-00 | Piston Ringset Std DT250A | ||
| 445-11610-40-00 | Piston Ringset 4Th ALT. PART DT360A | ||
| 438-11610-20-00 | Piston Ringset 2Nd ALT. PART DT250A | ||
| 438-11610-30-00 | Piston Ringset 3Rd ALT. PART DT250A | ||
| 438-11610-40-00 | Piston Ringset 4Th ALT. PART DT250A | ||
| 445-11610-30-00 | Piston Ringset 3Rd ALT. PART DT360A | ||
| 2 | 93306-30610-00 | Bearing | 2 |
| 93103-30072-00 | Oil Seal (38W) | ||
| 1 | 90201-12535-00 | Washer, Plate | 1 |
| 92901-12100-00 | Washer, Spring | ||
| 1 | 90170-12067-00 | Nut, Crankshaft | 1 |
| 93103-38086-00 | Oil Seal DT360A | ||
| 93103-40058-00 | Oil Seal DT250A | ||
| 1 | 93210-25070-00 | O-Ring | 1 |
| 364-16111-01-00 | Gear, Pri Drive (23T) DT250A | ||
| 445-16111-00-00 | Gear, Pri Drive (24T) DT360A | ||
| 1 | 214-16119-00-00 | Spring, Belleville | 1 |
| 1 | 90170-18086-00 | Nut, Crankshaft | 1 |
| 1 | 90280-05013-00 | Key, Woodruff | 1 |
| 364-11400-01-00 | Crankshaft Assembly DT250A | ||
| 365-11400-00-00 | Crankshaft Assembly DT360A | ||
| 438-11630-30-00 | Piston Kit 3Rd REF NO 8.9.11.12 | ||
| 438-11630-00-00 | Piston Kit Std REF NO 8.9.11.12 | ||
| 438-11636-01-00 | Piston 2 O/S 0.50 (0.50Mm 2Nd O REF NO 8.9.11.12 | ||
| 438-11635-01-00 | Piston 1 O/S 0.25 (0.25Mm 1St O REF NO 8.9.11.12 | ||
| 438-11630-40-00 | Piston Kit 4Th REF NO 8.9.11.12 | ||
| 1M2-11630-00-00 | Piston Kit Std REF NO 8.9.11.12 | ||
| 1M2-11630-10-00 | Piston Kit 1St REF NO 8.9.11.12 | ||
| 1M2-11630-40-00 | Piston Kit 4Th REF NO 8.9.11.12 | ||
| 1M2-11630-30-00 | Piston Kit 3Rd REF NO 8.9.11.12 | ||
| 1M2-11630-20-00 | Piston Kit 2Nd REF NO 8.9.11.12 |
