Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 709401545 | Black, Upper Main Tube Model Without DPS | 1 |
| 1 | 709401750 | Black, Upper Main Tube Model With DPS | 1 |
| 1 | 709401542 | Pitman Arm Model Without DPS | 1 |
| 1 | 709401240 | Black, Handlebar | 1 |
| 1 | 709401748 | Pitman Arm Model With DPS Except XMR | 1 |
| 1 | 709401756 | Pitman Arm Model XMR | 1 |
| 2 | 709400493 | Handle Grip | 2 |
| 2 | 709400449 | End Piece | 2 |
| 4 | 709401799 | Steering Support | 4 |
| 2 | 709400509 | Stiffner | 2 |
| 4 | 207086046 | Hex. Screw M8 X 60 | 4 |
| 4 | 233281416 | Hex. Elastic Flange Nut M8 | 4 |
| 1 | 250200086 | Flat Washer Model Without DPS | 1 |
| 1 | 250000047 | Hex. Flange Elastic Nut M12 Model Without DPS | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 207682534 | Hex. Flange Screw M8 X 25 | 2 |
| 1 | 503190396 | Ball Bearing Model Without DPS | 1 |
| 4 | 709400783 | Spherical Half Bushing | 4 |
| 2 | 709401370 | Spherical Half Bushing Model Without DPS | 2 |
| 1 | 293250177 | Seal Model Without DPS | 1 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 709400827 | Upper Column Attachment | 1 |
| 1 | 709401428 | Column Attachment | 1 |
| 2 | 703500922 | Tie Rod Ass'y Except Model XMR | 2 |
| 2 | 703500923 | Tie Rod Ass'y Model XMR | 2 |
| 1 | 709401837 | Ball Joint, LH Thread | 1 |
| 2 | 709401839 | Ball Joint, RH Thread | 2 |
| 4 | 293300068 | O-Ring | 4 |
| 8 | 250200086 | Flat Washer | 8 |
| 4 | 250100099 | Nut M12 | 4 |
| 4 | 211400013 | Cotter Pin | 4 |
| 1 | 250400034 | Cotter Pin Model Without DPS | 1 |
| 1 | 709400939 | Cover Except Model XT, Hunter | 1 |
| 1 | 709401614 | Power Steering Model With DPS | 1 |
| 1 | 709402184 | LH Power Steering Bracket Model With DPS | 1 |
| 1 | 709401742 | RH Power Steering Bracket Model With DPS | 1 |
| 1 | 709401743 | Power Steering Support Model With DPS | 1 |
| 11 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip Model With DPS | 11 |
| 1 | 709400406 | LH Mirror Model Europe, T3 | 1 |
| 1 | 709400407 | RH Mirror Model Europe, T3 | 1 |
| 2 | 207683544 | Hex. Flange Screw M8 X 35 Model With DPS | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 Model With DPS | 2 |
| 4 | 233081416 | Hex. Flange Nut M8 Model With DPS | 4 |
| 1 | 703100352 | Handle Guard Ass'y, XT Model XT, Hunter | 1 |
| 1 | 709400822 | Handle Bar Protector Model XT, Hunter | 1 |
| 1 | 704902966 | DPS Decal Model XT, Hunter | 1 |
| 4 | 241142560 | Hex. Flange Screw K40 X 25 Model XT, Hunter | 4 |
| 4 | 211200035 | Flat Washer Model XT, Hunter | 4 |
| 2 | 517303264 | U-Clamp Model XT, Hunter | 2 |
