Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705000017 | RH Footboard, Black | ||
| 1 | 705000018 | LH FOOTBOARD, BLACK | 1 |
| 1 | 293730011 | Black, Dart | 1 |
| 705000279 | Foot Pegs | ||
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 703500140 | Front Fender Kit (Yellow) Includes 6 - 12. | ||
| 703500142 | Front Fender Kit (Green) | ||
| 704900034 | Warning Label Includes 7 - 8. | ||
| XXXX | Not Available As Spare Part - Warning Label (English) (Injuries/Death) | ||
| XXXX | Not Available As Spare Part - Warning Label (English) (Under 16) | ||
| 1 | 704900007 | Caution Decal, Transmission Selector (Drive Select Lever) | 1 |
| 704900002 | Warning Decal, Death And Injuries (Injuries/Death) | ||
| 1 | 704900012 | Warning Decal, Under 16 Years Old (Under 16) | 1 |
| 704900008 | Caution Decal, Transmission Selector (Drive Select Lever) | ||
| 10 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 10 |
| 10 | 211000123 | Phillips Screw M6 X 20 | 10 |
| 1 | 207661244 | Hex. Flange Screw M6 X 12 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 703500011 | Front Fascia Ass'y, black Includes 17 - 18. | ||
| 1 | 704900130 | Bombardier Logo 68 mm | 1 |
| 4 | 224060201 | Flat Washer | 4 |
| 705000010 | Tank Cover | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 703500014 | LH Front Mudguard Kit Includes 22 - 23. | ||
| 703500015 | RH Front Mudguard Kit | ||
| 1 | 705000083 | LH FRONT REFLECTOR | 1 |
| 705000026 | RH FRONT REFLECTOR | ||
| 16 | 207162044 | Hex. Screw M6 X 20 | 16 |
| 16 | 224060201 | Flat Washer | 16 |
| 16 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 16 |
| 1 | 705000133 | LH TANK PROTECTOR | 1 |
| 1 | 705000134 | RH TANK PROTECTOR | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 705000135 | Front Protection Plate, black | ||
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" | ||
| 4 | 234181401 | Lock Washer 8 mm | 4 |
| 705000196 | Plate Ass'y Includes 34 - 35. | ||
| 293830084 | Rubber Protector | ||
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip (Scotch Grip) | 2 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip (Scotch Grip) | 4 |
| 705000081 | Lever Indicator | ||
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 570041600 | Rubber Cover | ||
| 705000184 | Mouting plate | ||
| 705000185 | WINCH | ||
| 1 | 705000194 | CABLE GUIDE | 1 |
| 1 | 705000195 | Winch Hook | 1 |
| 1 | 250400018 | Cotter Pin | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 | 2 |
| 4 | 234081410 | Flat Washer 8 mm | 4 |
