Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 705000592 | Footwell R.H | ||
| 705000593 | Footwell L.H | ||
| 7 | 293730011 | Black, Dart | 7 |
| 705000631 | Footrest, Black | ||
| 1 | 207661244 | Hex. Flange Screw M6 X 12 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 703500140 | Front Fender Kit (Yellow) Includes 8 - 13. P-XT. | ||
| 703500137 | Front Fender, Yellow P-STD. | ||
| 703500227 | Front Fender, Red P-STD. | ||
| 703500142 | Front Fender Kit (Green) P-XT. | ||
| 703500241 | Front Fender Kit (Green) P-STD. | ||
| 704900034 | Warning Label | ||
| 1 | 704900007 | Caution Decal, Transmission Selector | 1 |
| 704900002 | Warning Decal, Death And Injuries | ||
| 1 | 704900012 | Warning Decal, Under 16 Years Old | 1 |
| 704900008 | Caution Decal, Transmission Selector | ||
| 16 | 211000123 | Phillips Screw M6 X 20 | 16 |
| 703500217 | Rear Fender, Red Includes 15 - 18. P-STD. | ||
| 703500114 | Rear Fender Kit (Green) (English) P-STD. | ||
| 703500141 | Rear Fender Kit (Green) (English) P-XT. | ||
| 703500112 | Rear Fender, Yellow P-STD. | ||
| 703500139 | Rear Fender Kit (Yellow) (English) P-XT. | ||
| 704900116 | Warning Label Ass'y P-STD. | ||
| 704900119 | Warning Label (Passenger) (English) P-XT. | ||
| 704900006 | Warning Decal, Passenger, French | ||
| 704900120 | Warning Label, Tire Pressure (Tire Pressure) (French) P-STD. | ||
| 704900121 | Warning Label (Tire Pressure) (French) P-XT. | ||
| 705000594 | Front fascia | ||
| 4 | 234181401 | Lock Washer 8 mm P-XT. | 4 |
| 4 | 224060201 | Flat Washer | 4 |
| 703500208 | Rear fascia Includes 22 - 23. | ||
| 704900085 | RH Rear Reflector | ||
| 704900086 | LH Rear Reflector | ||
| 8 | 211000123 | Phillips Screw M6 X 20 | 8 |
| 6 | 224060201 | Flat Washer | 6 |
| 705000596 | Tank Cover | ||
| 16 | 570023800 | Windshield Latch | 16 |
| 705000597 | LH Front Mudguard | ||
| 705000598 | RH Front Mudguard | ||
| 1 | 705000083 | LH FRONT REFLECTOR | 1 |
| 705000026 | RH FRONT REFLECTOR | ||
| 28 | 207162044 | Hex. Screw M6 X 20 | 28 |
| 28 | 224060201 | Flat Washer | 28 |
| 28 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 28 |
| 705000599 | LH rear Mudguard | ||
| 705000600 | RH rear mudguard | ||
| 704900026 | Bombardier label | ||
| 1 | 705000133 | LH TANK PROTECTOR | 1 |
| 1 | 705000134 | RH TANK PROTECTOR | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 705000601 | Protector plate | ||
| 4 | 224061201 | Flat Washer | 4 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 P-STD. | 2 |
| 705000576 | Fender Cover, Viper Red | ||
| 705000193 | Fender cover | ||
| 705000179 | Fender Cover, Yellow | ||
| 705200535 | Skid Plate | ||
| 1 | 250400021 | Clevis Pin P-XT. | 1 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" P-XT. | ||
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 705000180 | LH Grill, Black | ||
| 705000181 | RH Grill, Black | ||
| 6 | 250100000 | PUSH NUT | 6 |
| 1 | 705000132 | COVER, BLACK | 1 |
| 705000081 | Lever Indicator | ||
| 3 | 414745900 | Tuflock Phillips Plastic Screw | 3 |
| 1 | 705000207 | CAP | 1 |
| 570041600 | Rubber Cover | ||
| 732600009 | PAN HEAD FORMING SCREW M6 X 18 | ||
| 4 | 705200533 | CUP | 4 |
| 705000184 | Mouting plate P-XT. | ||
| 705000185 | WINCH P-XT. | ||
| 1 | 705000194 | CABLE GUIDE P-XT. | 1 |
| 1 | 705000618 | Hook P-XT. | 1 |
| 1 | 250400022 | Cotter Pin P-XT. | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 P-XT. | 2 |
| 4 | 234081410 | Flat Washer 8 mm P-XT. | 4 |
