Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4TR-Y2410-31-W6 | Fuel Tank Comp YB | ||
| 4TR-Y2410-11-04 | Fuel Tank Comp YB-CALIFORNIA | ||
| 4TR-Y2410-31-W9 | Fuel Tank Comp VDMC1/SM1 | ||
| 4TR-Y2410-11-01 | Fuel Tank Comp VDMC1/SM1-CALIFORNIA | ||
| 4TR-24240-90-00 | . Graphic Set UR FOR YB | ||
| 4VR-24240-30-00 | . Graphic Set UR FOR VDMC1 | ||
| 5BN-24161-00-00 | . Emblem UR FOR YB | ||
| 5FB-24161-00-00 | . Emblem 1 UR FOR VDMC1 | ||
| 5BN-24162-00-00 | . Emblem 2 UR FOR YB | ||
| 5FB-24162-00-00 | . Emblem 2 UR FOR VDMC1 | ||
| 1 | 4TR-24182-00-00 | Damper, Locating 2 | 1 |
| 1 | 4TR-2413Y-00-00 | Bracket, Tank Fitting | 1 |
| 1 | 4TR-24183-00-00 | Damper, Locating 3 | 1 |
| 1 | 90201-060S9-00 | Washer, Plate | 1 |
| 1 | 92017-06012-00 | Bolt, Button Head | 1 |
| 2 | 95817-08016-00 | Bolt, Flange | 2 |
| 2 | 4H7-24181-00-00 | Damper, Locating 1 | 2 |
| 1 | 4NK-24602-10-00 | Cap Assy CA/5FB8 | 1 |
| 1 | 5BN-24602-00-00 | Cap Assy U49/5FB7 | 1 |
| 1 | 21V-24500-10-00 | Fuel Cock Assy 1 | 1 |
| 1 | 3AJ-24534-00-00 | . Seal, Cock | 1 |
| 2 | 97801-03008-00 | . .Screw, Pan Head | 2 |
| 1 | 4X8-24512-00-00 | . O-Ring | 1 |
| 1 | 3AJ-24523-00-00 | . Valve Packing | 1 |
| 2 | 90149-06011-00 | Screw | 2 |
| 2 | 90202-05193-00 | Washer, Plate | 2 |
| 1 | 1FK-2171L-00-00 | Mole, Side Cover 1 | 1 |
| 1 | 4BP-24188-00-00 | Mold, Fuel Tank | 1 |
| 1 | 4TR-24313-00-00 | Pipe 3 | 1 |
| 1 | 90464-10075-00 | Clamp | 1 |
| 1 | 90467-10038-00 | Clip | 1 |
| 1 | 1FK-24560-00-00 | Filter Assy | 1 |
| 1 | 1FK-24566-00-00 | Bracket, Filter | 1 |
| 1 | 4EB-24398-00-00 | Band 1 | 1 |
| 1 | 90467-11032-00 | Clip | 1 |
| 2 | 90467-12053-00 | Clip | 2 |
| 1 | 4TR-24311-00-00 | Pipe, Fuel 1 | 1 |
| 1 | 90464-15192-00 | Clamp | 1 |
| 1 | 4TR-2171A-00-00 | Cover, Top | 1 |
| 3 | 90149-05299-00 | Screw | 3 |
| 3 | 90179-05523-00 | Nut | 3 |
| 2 | 4TR-2414G-00-00 | Seal | 2 |
| 1 | 3XV-21717-00-00 | Damper | 1 |
| 2 | 90467-10041-00 | Clip CALIFORNIA | 2 |
| 1 | 5BN-24312-00-00 | Pipe 2 CALIFORNIA | 1 |
| 25H-24180-00-00 | Roll Over Valve Assy CALIFORNIA | ||
| 1 | 90461-15139-00 | Clamp CALIFORNIA | 1 |
| 1 | 98907-05010-00 | Screw, Bind CALIFORNIA | 1 |
| 1 | 5BN-24314-00-00 | Pipe 4 CALIFORNIA | 1 |
| 1 | 5BN-24327-00-00 | Protector, Pipe CALIFORNIA | 1 |
| 4 | 90467-10041-00 | Clip CALIFORNIA | 4 |
| 1 | 2JU-24170-00-00 | Canister Assy CALIFORNIA | 1 |
| 1 | 5BN-2419F-00-00 | Bracket, Canistor CALIFORNIA | 1 |
| 1 | 5BN-24315-00-00 | Pipe 5 CALIFORNIA | 1 |
| 1 | 90464-15192-00 | Clamp CALIFORNIA | 1 |
| 1 | 90467-10041-00 | Clip CALIFORNIA | 1 |
| 2 | 95807-06010-00 | Bolt, Flange CALIFORNIA | 2 |
| 5BN-24313-00-00 | Pipe 3 CALIFORNIA | ||
| 1 | 90464-20191-00 | Clamp CALIFORNIA | 1 |
| 1 | 4TR-14294-00-00 | Hose | 1 |
| 1 | 3LN-13907-00-00 | Fuel Pump Comp | 1 |
| 1 | 4TR-2637G-00-00 | Holder, Wire | 1 |
| 1 | 4TR-26331-00-00 | Cable, Starter 1 | 1 |
| 1 | 1UA-82591-00-00 | Band | 1 |
| 1 | 1VJ-26333-00-00 | Nut | 1 |
