Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 710000588 | Electronic Module | ||
| 278001166 | MODULE PROTECTOR | ||
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 278001756 | Battery YUASA YB16CL-B Includes 5 to 8 | 1 |
| 2 | 211000045 | Battery Screw | 2 |
| 211200018 | FLAT WASHER 6 MM | ||
| 2 | 211100022 | Battery Nut M6 | 2 |
| 1 | 219704414 | Was 415110000 Polyurethane Hose 5.2 mm | 1 |
| 710000022 | Battery Ground Cable | ||
| 1 | 278001976 | LOWER BATTERY PAD | 1 |
| 2 | 293850080 | Rubber Strap | 2 |
| 278001680 | Ground Cable Battery, no 6, meter) | ||
| 278001690 | Cable Battery, no 6, meter) | ||
| 278001682 | Terminal 45°, Small Hole | ||
| 278001683 | TERMINAL 45, SMALL HOLE | ||
| 278001684 | TERMINAL 90, SMALL HOLE | ||
| 278001685 | FLAT TERMINAL, BIG HOLE | ||
| 278001686 | TERMINAL 45, BIG HOLE | ||
| 278001687 | TERMINAL 90, BIG HOLE | ||
| 278001688 | FLAT TERMINAL | ||
| 278001776 | Terminal 30°, 2 Holes | ||
| 1 | 219704447 | Was 710000483 Heat Shrink Tubing | 1 |
| 529035730 | Crimp Plier | ||
| 710000100 | VOLT REGULATOR ASS'Y Includes 18 to 26 | ||
| 1 | 278000222 | Male Terminal | 1 |
| 1 | 278000223 | Female Terminal | 1 |
| 1 | 278000161 | Female Housing, 1 Circuit | 1 |
| 278000219 | CONNECTOR_MALE 1 CAVITY | ||
| 2 | 278000218 | Wire Seal | 2 |
| 409901300 | LOW TEMPERATURE VINYL TUBING | ||
| 710000034 | FEMALE TERMINAL | ||
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 1 | 278001546 | Ignition Coil | 1 |
| 1 | 710000073 | Insulator Pad | 1 |
| 1 | 207665044 | Hex. Flange Screw M6 X 50 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 710000211 | Engine Ground Cable | ||
| 1 | 710000136 | STARTER POSITIVE CABLE | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 515176011 | Starter Relay | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 2 | 232061414 | Hex. Nut M6 | 2 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 2 | 210261080 | Hex. Flange Screw M6 X 10 | 2 |
| 250000061 | Hex. Self-threaded Screw 1/4"-20 X 3/4" | ||
| 1 | 710000579 | FUSE HOLDER ASS'Y Includes 42 to 53 | 1 |
| 1 | 278001392 | Open Barrel Terminal | 1 |
| 1 | 410917200 | Fuse, 30 Amperes | 1 |
| 1 | 409003900 | Fuse, 20 Amperes | 1 |
| 1 | 409004300 | Male Terminal | 1 |
| 5 | 409007300 | Female Terminal | 5 |
| 4 | 278000218 | Wire Seal | 4 |
| 2 | 710000048 | Wire Seal | 2 |
| 4 | 278000343 | Fuse, 15 Amperes | 4 |
| 710000106 | Female Housing, 5 Circuit | ||
| 710000482 | SHRINK TUBING | ||
| 2 | 710000039 | Spark Wire Ass'y Includes 54 to 57 | 2 |
| 2 | 710000041 | Spark Plug Cap, Black | 2 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278000737 | MALE LOCK, 6 CIRCUITS | 1 |
| 1 | 207162044 | Hex. Screw M6 X 20 | 1 |
| 3 | 234461608 | External Serrated Lock Washer 6 mm | 3 |
| 1 | 232061414 | Hex. Nut M6 | 1 |
