Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 705600400 | FRONT BRAKE DISC | 2 |
| 8 | 250000117 | Torx Screw M8 X 20, Scotch Grip | 8 |
| 2 | 705600628 | Banjo Bolt | 2 |
| 2 | 705600609 | Banjo Bolt (M10 x 1.25 thread) | 2 |
| 1 | 705600680 | SCREW BLEEDER | 1 |
| 1 | 705600612 | Banjo Bolt | 1 |
| 17 | 705600310 | Copper Washer | 17 |
| 705600615 | FRONT LEVER BRAKE HOSE ASS'Y | ||
| 1 | 512059812 | SPACER | 1 |
| 207664034 | Hex. Flange Screw M6 X 40 | ||
| 1 | 233261434 | Flange Elastic Nut M6 | 1 |
| 705600553 | Hose Holder | ||
| 6 | 207561234 | Hex. Flange Screw M6 X 12, Scotch Grip | 6 |
| 1 | 705600409 | CYLINDER MASTER ASS'Y Includes 14 to 16 | 1 |
| 1 | 705600491 | Brake Lever Kit | 1 |
| 1 | 705600493 | CAP SET | 1 |
| 1 | 705600619 | BRACKET KIT | 1 |
| 2 | 205062534 | SOCKET HEAD SCREW M6 X 25 | 2 |
| 293600062 | BRAKE FLUID, GTLMA, DOT 4, 12 X 354 ML | ||
| 1 | 705600655 | REAR BRAKE DISC | 1 |
| 3 | 250000330 | SHOULDER SCREW M8 | 3 |
| 1 | 705600656 | REAR CALIPER SUPPORT | 1 |
| 1 | 293370045 | SNAP RING | 1 |
| 1 | 705600412 | GUIDE REAR CALIPER | 1 |
| 2 | 250000247 | Hex. Flange Screw M10 X 16 | 2 |
| 1 | 705600616 | Rear Brake Pedal Hose Ass'y | 1 |
| 2 | 210261680 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 710000853 | Brake Switch | 1 |
| 710001377 | BRAKE SWITCH | ||
| 1 | 705600737 | Rear Cylinder Master Ass'y Includes 30 to 32 | 1 |
| 1 | 705600498 | ROD SET | 1 |
| 705600739 | Reservoir Set | ||
| 1 | 207662034 | Hex. Flange Screw M6 X 20 | 1 |
| 2 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 2 |
| 2 | 232561434 | Elastic Stop Nut M6 | 2 |
| 1 | 705600538 | Hose Protector | 1 |
| 1 | 250400031 | Clevis Pin | 1 |
| 1 | 250400032 | Cotter Pin | 1 |
| 1 | 705600534 | BRAKE PEDAL | 1 |
| 2 | 705600631 | FIXATION PLATE | 2 |
| 2 | 390407200 | Pop Rivet 3/16” | 2 |
| 705600635 | BRAKE PEDAL SPRING | ||
| 2 | 705600458 | Bearing | 2 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 205404036 | SOCKET HEAD SCREW M10 X 40 | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 506152194 | Washer | 1 |
| 1 | 293900087 | Bushing | 1 |
| 705600614 | FRONT BRAKE HOSE ASS'Y Includes 50 to 51 | ||
| 4 | 705600459 | Clamp | 4 |
| 705600613 | REAR BRAKE HOSE ASS'Y Includes 52 to 53 | ||
| 2 | 705600459 | Clamp | 2 |
| 1 | 705600617 | SPLITTER | 1 |
| 705600618 | Splitter Support | ||
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 1 | 705600660 | LEVER SUPPORT | 1 |
| 1 | 250000247 | Hex. Flange Screw M10 X 16 | 1 |
| 1 | 705600661 | BRAKE CABLE | 1 |
| 3 | 705600459 | Clamp | 3 |
| 1 | 705600662 | CABLE SUPPORT | 1 |
| 705600663 | LEVER BRAKE | ||
| 1 | 705600664 | SUPPORT | 1 |
| 705600665 | LEVER PIVOT | ||
| 705600666 | Stopper | ||
| 4 | 205061660 | Socket Screw M6 X 16 | 4 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
