Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 420684220 | Drive Ass'y Includes 1 - 19. 400 H.O | ||
| 420684320 | Drive Ass'y 330 H.O., STD 2 x 4, STD 4 x 4 | ||
| 420296535 | BEVEL GEAR ASS?Y | ||
| 1 | 420281285 | Gear Wheel Set Includes 2 - 7. 400 H.O | 1 |
| 1 | 420281287 | GEAR WHEEL SET 330 H.O., STD 2 x 4, STD 4 x 4 | 1 |
| 2 | 420632070 | Needle Bearing | 2 |
| 1 | 420245850 | Retaining Ring | 1 |
| XXXX | Not Available As Spare Part - Sliding gear (44 teeth) | ||
| XXXX | Not Available As Spare Part - Gear pinion (36 teeth) | ||
| XXXX | Not Available As Spare Part - Thrust washer | ||
| XXXX | Not Available As Spare Part - Gear pinion (34 teeth) | ||
| 1 | 420620440 | COUNTERSHAFT ASS'Y, 11 TEETH Includes 8 - 15. 400 H.O | 1 |
| 1 | 420620442 | COUNTERSHAFT ASS'Y, 11 TEETH 330 H.O., STD 2 x 4, STD 4 x 4 | 1 |
| XXXX | Not Available As Spare Part - Countershaft (11 teeth) | ||
| XXXX | Not Available As Spare Part - Needle bearing K25 x 29 x 13 PA66 | ||
| XXXX | Not Available As Spare Part - Gear pinion (25 teeth) | ||
| 1 | 420445300 | Circlip | 1 |
| XXXX | Not Available As Spare Part - Shift gear (16 teeth) | ||
| 1 | 420630040 | O-Ring | 1 |
| 420247110 | Distance Ring | ||
| 1 | 420635671 | Intermediate Gear Shaft Ass'y Includes 16 - 20. | 1 |
| 1 | 420229600 | Needle Pin | 1 |
| XXXX | Not Available As Spare Part - Intermediate gear (25 teeth) | ||
| XXXX | Not Available As Spare Part - Needle cage 16 x 20 x 17 | ||
| XXXX | Not Available As Spare Part - Distance ring | ||
| 1 | 420281300 | Washer Thrust Set | 1 |
| 1 | 420632280 | Ball Bearing 6405 | 1 |
| 2 | 420430370 | O-Ring | 2 |
| 1 | 420650682 | Oil Seal | 1 |
| 1 | 420932825 | Ball Bearing | 1 |
| 1 | 420281306 | Thrust Washer Set, MAG Side | 1 |
| 1 | 420632300 | Axial Needle Bearing | 1 |
| 1 | 420281302 | Thrust Washer Set, CVT Side | 1 |
| 1 | 420229540 | Pin | 1 |
| 1 | 420257330 | Shift Fork | 1 |
| 1 | 420257340 | Shift Fork | 1 |
| 1 | 420257325 | Shift Drum Ass'y | 1 |
| 1 | 420627780 | ISOLATING WASHER | 1 |
| 1 | 420238290 | Index Spring | 1 |
| 1 | 420227710 | BUSHING | 1 |
| 1 | 420248328 | Index Lever Ass'y | 1 |
| 1 | 420241526 | Torx Screw M6 X 16 | 1 |
| 1 | 420620135 | Shift Shaft Ass'y | 1 |
| 1 | 420257315 | Parking Lock Lever Ass'y | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 293550014 | Grease, Super Lube #823-28 | 1 |
| 293600039 | ENGINE OIL 4 STROKES, 5W40, 12 X 1 LITER |
