Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 707200230 | CARBURATOR, MIKUNI BSR33-56 Includes 1 - 71, 330 H.O., STD 2 x 4, STD 4 x 4 | 1 |
| 707200190 | Carburator, Mikuni BSR33-49 Includes 1 - 71. 400 H.O. | ||
| XXXX | Not Available As Spare Part - Mixing body ass'y | ||
| XXXX | Not Available As Spare Part - Screw | ||
| XXXX | Not Available As Spare Part - Throttle valve | ||
| 1 | 707200064 | WASHER | 1 |
| 1 | 707200065 | RING | 1 |
| 1 | 404152200 | E-Ring | 1 |
| 404162040 | Spring | ||
| 1 | 270500144 | O-RING | 1 |
| 1 | 707200067 | HOLDER | 1 |
| 707200068 | DIAPHRAGM | ||
| 404162039 | PISTON VALVE | ||
| 707200070 | Ring | ||
| 707200071 | SPRING | ||
| 1 | 707200072 | WASHER | 1 |
| 404162052 | NEEDLE J8-5HGY75-53 330 H.O., STD 2 x 4, STD 4 x 4 | ||
| 1 | 707200109 | NEEDLE J8-5FEY01-3 400 H.O. | 1 |
| 1 | 707200144 | SPRING | 1 |
| 404162038 | PLUNGER ASS'Y | ||
| 707200009 | Holder Guide | ||
| 404140200 | O-Ring | ||
| 1 | 707200010 | CAP | 1 |
| 707200004 | CAP | ||
| 1 | 707200077 | ADJUSTER | 1 |
| 707200078 | Spring | ||
| 1 | 707200018 | WASHER | 1 |
| 1 | 404139900 | O-RING | 1 |
| 707200079 | RING | ||
| 1 | 270500148 | MAIN JET 127.5 330 H.O., STD 2 x 4, STD 4 x 4 | 1 |
| 404162037 | MAIN JET 133.8 400 H.O. | ||
| 707200080 | Jet Holder | ||
| 270500119 | O-RING | ||
| 707200119 | FLOAT BODY ASS?Y | ||
| 404123400 | Pin | ||
| 1 | 707200082 | Needle Valve 1.0 | 1 |
| 1 | 707200083 | O-Ring | 1 |
| 404162053 | Needle Jet 330 H.O., STD 2 x 4, STD 4 x 4 | ||
| 404162036 | NEEDLE JET 400 H.O. | ||
| 2 | 707200085 | SCREW | 2 |
| 1 | 707200086 | DIAPHRAGM COVER | 1 |
| 707200177 | PILOT JET 80.0 330 H.O., STD 2 x 4, STD 4 x 4 | ||
| 707200188 | PILOT JET 50.0 400 H.O. | ||
| 4 | 404159300 | SCREW | 4 |
| 404162035 | Plate | ||
| 1 | 404154900 | CAP | 1 |
| XXXX | Not Available As Spare Part - Bolt | ||
| 707200091 | SCREW | ||
| 1 | 707200092 | O-RING | 1 |
| 707200093 | COVER | ||
| XXXX | Not Available As Spare Part - Throttle shaft ass'y | ||
| XXXX | Not Available As Spare Part - Ring | ||
| XXXX | Not Available As Spare Part - Seal | ||
| XXXX | Not Available As Spare Part - Case | ||
| XXXX | Not Available As Spare Part - Torsion spring | ||
| XXXX | Not Available As Spare Part - O-ring | ||
| XXXX | Not Available As Spare Part - Cap | ||
| XXXX | Not Available As Spare Part - E-ring | ||
| XXXX | Not Available As Spare Part - Packing | ||
| 707200100 | PILOT JET 32.5 | ||
| 707200180 | Adjuster Screw | ||
| 1 | 707200020 | O-RING | 1 |
| 1 | 404162034 | HOSE | 1 |
| 1 | 404138600 | SCREW | 1 |
| 1 | 404161861 | SCREW | 1 |
| 1 | 707200103 | FLOAT ASS?Y | 1 |
| 707200179 | Hose | ||
| 707200105 | Cover Ass’y | ||
| 1 | 707200106 | DIAPHRAGM ASS?Y | 1 |
| 707200160 | Richer Spring | ||
| 2 | 404901400 | SCREW | 2 |
| 404145800 | MAIN JET PWJ 80 | ||
| 707200024 | SCREW | ||
| 1 | 707200058 | CABLE GUIDE | 1 |
| 1 | 404101700 | Spring | 1 |
| 1 | 707200164 | TERMINAL | 1 |
| 707200163 | HEATER ELEMENT | ||
| 404112000 | TOOL KIT |
