Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 703500229 | Front fender kit Includes 1 - 7. (viper red) | ||
| 703500237 | Front fender kit (yellow) | ||
| 703500298 | Front fender kit (camo) | ||
| 703500315 | Front Fender, Green Includes 1 - 8. (Laurentian green) | ||
| XXXX | Not Available As Spare Part - Front fender ass'y Includes 2 - 4. (viper red, yellow, camo) | ||
| XXXX | Not Available As Spare Part - Front fender ass'y Includes 2 - 5. (Laurentian green) | ||
| 704900001 | Warning Decal, Death And Injuries (injuries and death) | ||
| 1 | 704900011 | Warning Decal, Under 16 Years Old (Under 16 years old) | 1 |
| 1 | 704900007 | Caution Decal, Transmission Selector (transmission selector) | 1 |
| 704900002 | Warning Decal, Death And Injuries (injuries and death) | ||
| 1 | 704900012 | Warning Decal, Under 16 Years Old (Under 16 years old) | 1 |
| 704900008 | Caution Decal, Transmission Selector (transmission selector) | ||
| 705000708 | Front Fascia, Slate Gray | ||
| 4 | 293730011 | Black, Dart | 4 |
| 2 | 211000123 | Phillips Screw M6 X 20 | 2 |
| 4 | 211000123 | Phillips Screw M6 X 20 | 4 |
| 4 | 224060201 | Flat Washer | 4 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 705001052 | Console | ||
| 705000369 | HOOK, BLACK | ||
| 705000975 | LH Panel, camo (camo) | ||
| 705000837 | LH Panel, green (Laurentian green) | ||
| 705000405 | LH Panel, yellow (yellow) | ||
| 705000570 | LH Panel, red (viper red) | ||
| 703500333 | RH panel (Laurentian green) | ||
| 703500223 | RH Panel, Red (viper red) | ||
| 703500156 | RH panel (yellow) | ||
| 703500304 | RH panel (camo) | ||
| 6 | 570023800 | Windshield Latch | 6 |
| 705000827 | LH Front Mudguard | ||
| 705000828 | RH Front Mudguard | ||
| 12 | 207162044 | Hex. Screw M6 X 20 | 12 |
| 12 | 224060201 | Flat Washer | 12 |
| 12 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 12 |
| 1 | 705000133 | LH TANK PROTECTOR 4 X 4 | 1 |
| 1 | 705000134 | RH TANK PROTECTOR 4 X 4 | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 224061201 | Flat Washer | 4 |
| 1 | 705000713 | PROTECTOR PLATE, SLATE GRAY | 1 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207602544 | Hex. Flange Screw M10 X 25 STD Quest Std. | 2 |
| 250000042 | Socket Screw 5/16-18 X 1 1/2" XT Quest XT. | ||
| 2 | 233201414 | Hex. Flange Elastic Nut M10 STD Quest Std. | 2 |
| 1 | 705200536 | SKID PLATE | 1 |
| 4 | 705200533 | CUP | 4 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 2 | 414745900 | Tuflock Phillips Plastic Screw | 2 |
| 570041600 | Rubber Cover | ||
| 705000994 | Mounting Plate XT Quest XT. | ||
| 705000839 | WINCH XT Quest XT. | ||
| 1 | 705000194 | CABLE GUIDE XT Quest XT. | 1 |
| 1 | 705000618 | Hook XT Quest XT. | 1 |
| 1 | 250400022 | Cotter Pin XT Quest XT. | 1 |
| 2 | 250000041 | SOCKET SCREW 5/16-18 X 1 XT Quest XT. | 2 |
| 4 | 234081410 | Flat Washer 8 mm XT Quest XT. | 4 |
| 4 | 234181401 | Lock Washer 8 mm XT Quest XT. | 4 |
| 1 | 250400021 | Clevis Pin XT Quest XT. | 1 |
| 705000311 | Bracket, Black | ||
| 2 | 210261080 | Hex. Flange Screw M6 X 10 | 2 |
| 705000367 | LH Rear Grill, Black | ||
| 705000366 | RH Rear Grill, Black | ||
| 705000368 | LH Front Grill | ||
| 10 | 517302785 | Edge Clip | 10 |
