Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 4WM-Y2410-31-X7 | FUEL TANK COMP. UR VDBMA | |
| 1 | 4WM-Y2410-31-X8 | FUEL TANK COMP. UR NPW | |
| 2 | 5GA-24240-30-00 | GRAPHIC SET UR VDBMA | |
| 2 | 4WM-24240-90-00 | GRAPHIC SET UR NPW | |
| 3 | 2YK-24181-10-00 | DAMPER, LOCATING 1 | 2 |
| 4 | 4WM-24191-00-00 | BRACKET, FUEL TANK 1 | |
| 5 | 4WM-24192-00-00 | BRACKET, FUEL TANK 2 | |
| 6 | 2GH-24181-00-00 | DAMPER, LOCATING 1 | 2 |
| 7 | 2GH-24183-00-00 | DAMPER, LOCATING 3 | 2 |
| 8 | 2GH-24186-00-00 | WASHER, SPECIAL | 2 |
| 9 | 90387-06553-00 | COLLAR | 4 |
| 10 | 95817-06025-00 | BOLT, FLANGE | |
| 11 | 95817-06125-00 | BOLT, FLANGE | 1 |
| 12 | 90201-065F3-00 | 90201-06020-00 | 1 |
| 13 | 90176-06055-00 | NUT, CROWN | 1 |
| 14 | 90387-0615R-00 | COLLAR | |
| 15 | 4WM-24291-00-00 | BRACKET, FUEL TANK 1 | 2 |
| 16 | 4WM-24339-00-00 | GROMMET | 4 |
| 17 | 90387-050T5-00 | COLLAR | 4 |
| 18 | 95707-05500-00 | NUT, FLANGE | 4 |
| 19 | 4WM-24500-00-00 | FUEL COCK ASSY 1 | 1 |
| 20 | 3AJ-24523-00-00 | VALVE PACKING | 1 |
| 21 | 3AJ-24534-00-00 | SEAL, COCK | 1 |
| 22 | 98580-03008-00 | SCREW, PAN HEAD (98501-03008-00 | 2 |
| 23 | 4X8-24512-00-00 | O-RING | 1 |
| 24 | 90202-05187-00 | WASHER, PLATE | 2 |
| 25 | 90149-06011-00 | SCREW | 2 |
| 26 | 4WM-24311-00-00 | PIPE, FUEL 1 | 1 |
| 27 | 4WM-24393-00-00 | SPRING | |
| 28 | 90467-13133-00 | CLIP | 4 |
| 29 | 1FK-24560-10-00 | FILTER ASSY | 1 |
| 30 | 4WM-24312-00-00 | PIPE 2 | 1 |
| 31 | 4WM-24394-00-00 | SPRING | |
| 32 | 4WM-24398-00-00 | BAND 1 | 1 |
| 33 | 4WM-24217-00-00 | COVER | 1 |
| 34 | 4NK-24602-10-00 | CAP ASSY | 1 |
| 35 | 4WM-24321-00-00 | PIPE 10 (5GAD) | |
| 35 | 4WM-24321-10-00 | PIPE 10 (5GAE) | |
| 36 | 90467-10008-00 | CLIP (5GAD) | 2 |
| 36 | 90467-10008-00 | CLIP (5GAD) (5GAE) | 3 |
| 37 | 90464-15192-00 | CLAMP (5GAE) | 1 |
| 38 | 90464-25217-00 | CLAMP (5GAD) (5GAE) | 1 |
| 38 | 90464-25217-00 | CLAMP (5GAD) | 2 |
| 39 | 4WM-24180-00-00 | ROLL OVER VALVE ASSY | 1 |
| 40 | 90461-15139-00 | CLAMP | 1 |
| 41 | 4WM-2148X-00-00 | BRACKET 4 (5GAE) | 1 |
| 42 | 98507-05008-00 | SCREW, PAN HEAD (5GAE) | 2 |
| 43 | 98907-05012-00 | SCREW, BIND | 1 |
| 44 | 4WM-24662-00-00 | STAY (5GAE) | |
| 45 | 4WM-24322-00-00 | PIPE 11 (5GAE) | |
| 45 | 90445-116K9-00 | HOSE (L400) (5GAD) | 1 |
| 46 | 4WM-24323-00-00 | PIPE 12 (5GAE) | |
| 47 | 90467-10008-00 | CLIP (5GAD) | 1 |
| 48 | 4XY-14568-00-00 | JOINT (5GAE) | 1 |
| 49 | 90464-15192-00 | CLAMP (5GAE) | 1 |
| 50 | 90464-10075-00 | CLAMP (5GAE) | 1 |
| 51 | 4WM-24170-00-00 | CANISTER ASSY (5GAE) | 1 |
| 52 | 4WM-2419E-00-00 | COVER, CANISTER (5GAE) | 1 |
| 53 | 90105-06009-00 | BOLT, FLANGE (5GAE) | 2 |
| 54 | 90467-10008-00 | CLIP (5GAE) | 3 |
| 55 | 1HX-24188-01-00 | MOLD, FUELTANK (3VD-24188-00-00 | 1 |
| 56 | 4WM-24491-01-00 | BRACKET, FUEL PUMP | |
| 57 | 95817-06016-00 | BOLT, FLANGE | 2 |
| 58 | 4WM-2416B-00-00 | EMBLEM | |
| 59 | 4WM-2417B-00-00 | EMBLEM | |
| 60 | 4WM-13907-00-00 | FUEL PUMP COMP. | |
| 61 | 90464-13249-00 | CLAMP | 1 |
